PEARL
SERIES DRUMS
Instruction Manual
Congratulations on your purchase! To get optimum performance from your Pearl drum set,
please read this Instruction Manual first before playing.
Hi-Hat Cymbal
Tom Holder
Ride Cymbal
Tom Tom
Tom Tom
Cymbal Stand
Snare Drum
Hi-Hat Stand
Bass Drum
Snare Stand
Floor Tom
Drum Pedal
Set-Up Example
*Cymbals and Throne come only in the "with Cymbal" sets.
Advertisement
Related Manuals for Pearl TGX Series
Summary of Contents for Pearl TGX Series
- Page 1 PEARL SERIES DRUMS Instruction Manual Congratulations on your purchase! To get optimum performance from your Pearl drum set, please read this Instruction Manual first before playing. Hi-Hat Cymbal Tom Holder Ride Cymbal Tom Tom Tom Tom Cymbal Stand Snare Drum...
- Page 2 PRECAUTIONS WHEN INSTALLING EQUIPMENT USING YOUR PRODUCT SAFELY Warning Thank you for choosing Pearl! For proper and safe operation of your drums, stands, pedals, and accessories please follow Make Sure Screws are Tightened Securely these instructions carefully before using. Please keep these Screws should be tightened securely to keep hardware from falling instructions in a safe place for future reference.
- Page 3 Earthquake Precautions Be Careful Using Sticks and Wire Brushes A strong vibration such as an earthquake can cause your drums Sticks and wire brushes are intended for and hardware to shift and tip over. Stay well clear of falling objects playing the drums and should never be to avoid injury.
- Page 4 Tom Holder Bracket assembly instructions below. 1. Place the shell with the bass drum spurs facing upward on a clean, solid surface. Put the Pearl logo head on Tension Rod the shell followed by the hoop, flat side down (Fig.1).
- Page 5 Floor Tom Assembly Hi-Hat Stand Assembly The floor tom is shipped unassembled. Please follow the Open the legs of the hi-hat to form a stable tripod. Insert assembly instructions below. the ends of the radius rod into the holes near the bottom of the hi-hat base (Fig.8).
- Page 6 Drum Pedal Assembly Basic Tuning Hook the spring to the cam roller as shown. Here is the basic tuning method using the snare drum as Insert the beater into the beater holder link and secure it an example. Gradually tighten the tension bolts using a crisscross pattern as shown.
