PEARL

MARCHING TENOR DRUMS

Instruction Manual

Congratulations on your purchase!

To get optimum performance of your Marching Tenor Drums,

please read this Instruction Manual before playing.

Quad

The Tenor Back Bar is pre-set for a

Quad setup and no adjustments are

necessary. If you prefer to position

the Quads further away from your

body please move the Side Bars to

the "B" or "C" positions using the

provided wrench.

Table of Contents

Do you have a question about the MARCHING TENOR and is the answer not in the manual?

Page 1 PEARL MARCHING TENOR DRUMS Instruction Manual Congratulations on your purchase! To get optimum performance of your Marching Tenor Drums, please read this Instruction Manual before playing. Quad Optional Parts The Tenor Back Bar is pre-set for a Quad setup and no adjustments are necessary.
Page 2 Quint The 6" tom can also be attached to the Back Bar with a BBS-6S/B Attachment (sold separately) in the 3rd/4th Quint 6+8+10+12+13 position as shown. Set the Side Bars to the "C" Position as shown. For Quints (6+8+10+12+13), the 6” tom can be mounted directly to the Back Bar in the center (3rd position) or in the offset position (4th position).
Page 3 Sextet 6+6+10+12+13+14 Using BBS-6S/B The 6” toms in the 6+6+10+12+13+14 Sextet can be mounted directly to the Back Bar or with BBS-6S/B attachments. When mounting directly to the Back Bar, mount the 6” toms to the Back Bar in the 1st and 5th positions.
Page 4 Quint 6+10+12+13+14 Sextet 6+8+10+12+13+14 For Quints (6+10+12+13+14), mount the 6" tom to the Back For Sextets (6+8+10+12+13+14), mount the BBS-68S/B Bar with a BBS-6S/B Attachment (sold separately) in the 3rd Attachments on the 3rd/5th position and attach the 6" and 8" / 4th position as shown.
