Wing Span:73.2in/1860mm; Radio:4Channel 5Servos;
Wing Area:62sq.dm;
Length:61in/1550mm;
CAUTION : this plane is not a toy and should be kept away
children under 16 years of age! Before use , please carefully read
this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children's reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Engine:20CC Gas
Advertisement
Related Manuals for Hobby King FALCON TRAINER
Summary of Contents for Hobby King FALCON TRAINER
- Page 1 Wing Span:73.2in/1860mm; Radio:4Channel 5Servos; Wing Area:62sq.dm; Engine:20CC Gas Length:61in/1550mm; CAUTION : this plane is not a toy and should be kept away children under 16 years of age! Before use , please carefully read this manual. ●First-time builders should seek advice from people having building experience in order to assemble the model correctly and to produce its performance to full extent .
-
Page 2: Main Wings
All the parts together Main Wings Connect the aileron and the main wing by hinges.Be sure to apply instant type glue to both sides of each hinges. Install the aileron horns in place with AB glue Align the holes in the horns... - Page 3 Cut the servo holes on the bottom of the main wings Gather servo parts as shown. Install the control horn.
- Page 4 Use screw to fixed it Install the servo.as shown Drill holes with the specified diameter(13mm) on the bottom wing...
- Page 5 Servo extension through the hole Put the servo into the hole then use screw fixed it Connect the servo arm and control horn with push rod .
- Page 6 Connect the main wings and the fuselage with hard wood. Main Landing Gear and Tail Wheel Unit Cut hole at the Original design hole of the fuselage Fix up main landing gear on the fuselage bottom with screws.
- Page 7 Use screw to connect the landing gear, wheel pant, nut and wheel in turn, and finally use a lock nut to lock them. Finished photo Drill holes with the specified diameter(2mm) Stabilizer And Rudder...
- Page 8 Use screw to lock tail landing gear on the wing bottom Stabilizer And Rudder Apply epoxy into hinge hole of the elevator Connect the vertical fin and the rudder by hinges.
- Page 9 Cut off shaded portion on the fuselage. Cut the holes on the stabilizer Install the elevator and vertail fin， as shown...
- Page 10 Install the elevator horns and fix it with screws. Finished photo Install rudder horns and push-rod.
- Page 11 Assemble the elevator servos in the fuselage Install the rudder servo and fix it with screws. Install throttle servo and push-rod...
- Page 12 Screwed to the wing.As shown. Trim fit the canopy Use screw to lock it...
- Page 13 Drill a hole use for install adjustable engine mounts Fixed with nuts Finished photo...
- Page 14 Install the engine.as shown Mount the fuel tank into the fuselage CG POSITION & CONTROL THROWS...
- Page 15 THE FINISHED PHOTO...
