Page 1 Please read this owner's manual carefully before operating, and keep it for reference. Split Air Conditioner Wall Mounted Model OWNER’S MANUAL MODELS GWH09UB-D3DNA3A/I GWH09UB-D3DNA2A/I GWH09UB-D3DNA1A/I GWH12UB-D3DNA3A/I GWH12UB-D3DNA1A/I GWH12UB-D3DNA2A/I GWH18UC-D3DNA1A/I GWH18UC-D3DNA2A/I WWW.GREE.CA St-Mathieu-de-Beloeil (Québec) Canada 1-866-680-GREE 00630-19/04/12 © Copyright, Sunrise Tradex Corp., 2012...
Page 2: Table Of Contents
Thank you for selecting a Gree product By purchasing a Gree air conditioner, you not only get comfort, but also good health. These operating instructions present the various features your unit has to offer. In addition, they provide important maintenance and service information as well as tips to operate the unit more economically.
Page 3: O P E R A T I N Ginstructions Parts And Their Functions
1 Parts and their functions OPERATING INSTRUCTIONS INDOOR UNIT Indoor unit he icons displayed: Cool Heat Power Remote controller S et temp Front panel Filter Horizontal louver Wall pipe Binding tape Connection wires Dr ain hose...
Page 4 2 How to use the remote control OPERATING INSTRUCTIONS • Remote control description ON/OFF Press to start or stop the unit. - : Press to decrease the temperature setting. + : Press to increase the temperature setting. MODE Press to select the running mode (AUTO/COOL/DRY/FAN/HEAT/).
Page 5: Remote Control Description
How to use the remote control OPERATING INSTRUCTIONS • Remote control description ON/OFF Press this button to turn the unit on. Press again to turn the unit off. Press this button to decrease the set temperature. Hold it down for longer than two seconds to decrease the set temperature at a faster rate.
Page 6 How to use the remote control OPERATING INSTRUCTIONS Press this button to select either outside or recycled air. Press once for the recycled air mode, and the LCD screen displays “ ”. Press a second time to use set both the recycled and outside air modes, and the LCD screen displays “ ”...
Page 7: Replacing The Batteries
How to use the remote control OPERATING INSTRUCTIONS LIGHT Press LIGHT to turn on the display light and press again to turn it off. If the light is turned on, “ ” is displayed. If the light is turned off, “ ”...
Page 8: Care & Cleaning
Care and cleaning OPERATING INSTRUCTIONS CAUTION Remove the front panel.Dip a piece of cloth into the water colder than 45 and dry it.Then wipe the dirty part of front panel. Disconnect the power supply before cleaning and maintenance. Do not splash water on the units for cleaning, as electric shocks may occur. Wipe the units with a dry soft cloth, or a cloth slightly moistened with water or cleaner (not with volatile liquid such as thinner or gasoline).
Page 9: Operating Guide
OPERATING GUIDE INSTRUCTIONS D’UTILISATION Working principle and special functions for cooling Principle: Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature. Anti-freezing function: If the unit is running in COOL mode and in low temperature, there will be frost formed on the heat exchanger, when indoor heat exchanger temperature decreased below 0°C , the indoor unit microcomputer will stop compressor running and protect the unit.
Page 10 Operating guide OPERATING INSTRUCTIONS The temperature should not be set lower than what To distribute cool air throughout the room, adjust you need. This will lead to increased energy costs the air flow direction as shown by the arrows (see picture).
Page 11: Precautions
Precautions OPERATING INSTRUCTIONS Check the electrical system (voltage and frequen- If electrical interference occurs while running the cy). Use the proper power supply indicated on the unit, turn the air conditioner off. If the unit will not be unit to operate the air conditioner. Only use fuses used for a long time, turn off the power supply.
Page 12: Before Contacting A Service Technician
Before contacting a service technician OPERATING INSTRUCTIONS Check the following before contacting a service technician. You may find the solution to your problem here. If the unit still does not function properly after checking this list, please contact your local dealer. PROBLEM CAUSES Not running...
Page 13: I N S T A L L A T I O N Warning & Recommendations
Installation of indoor unit INSTRUCTIONS D’INSTALLATION WARNING 1.The unit should be installed only by authorized service center according to local or government regulations and in compliance with this manual. 2.Before installing, please contact with local authorized maintenance center. If the unit is not installed by the authorized service center, the malfunction may not be solved due to inconvenient contact between the user and the service personnel.
Page 14: Instructions Installing The Indoor Unit
Installing the indoor unit INSTALLATION INSTRUCTIONS Installation dimension diagram Space to the ceiling Space to the wall above 15cm above 15cm away Space to the wall above Air outlet Space to the floor The dimensions of the space necessary for proper installation of the unit include the minimum permissible distances to adjacent parts.
Page 15 Installing the indoor unit INSTALLATION INSTRUCTIONS Installation of Mounting Plate 1. Mounting plate should be installed horizontally. As the water tray's outlet for the indoor unit is two-way type, during installation, the indoor unit should slightly slant to water tray's outlet for smooth drainage of condensate. 2.
Page 16 Installing the indoor unit INSTALLATION INSTRUCTIONS Connecting Indoor and Outdoor Electric Wires 09K,12K 1.Open the front panel. 2.Remove the wiring cover. 3.Make the power connection cord through the hole in the back of indoor unit. yellow- brown green 4.Connect and fix power connection cord to the terminal board as shown in Fig 2. 5.Reinstall the cord anchorage and wiring cover.
Page 17: Post-Installation Verification
Post-installation verification INSTALLATION INSTRUCTIONS Check after installing Items to be checked Possible malfunction Situation Is the unit firmly attached? The unit may fall, vibrate or emit noise. Has the refrigerant leakage test It may cause insufficient cooling capacity. been done? Is the heat insulation sufficient? It may cause condensation and dripping.
Page 18: Warranty
Note : The internal compressor is covered by a 5-YEAR limited warranty. During the warranty period, if this air conditioner fails under normal use, GREE will, at its option, either repair the unit or replace it, free of charge, within a reasonable period of time after the air conditioner is returned.
