Page 1: User Manual
USER MANUAL [ U - C R O W N S E R I E S ] GWH09UB-K6DNA4A (GWH09UB-K6DNA4A/I + GWH09UB-K6DNA4A/O) GWH12UB-K6DNA4A GWH09UB-K6DNA4A/O (GWH12UB-K6DNA4A/I + GWH12UB-K6DNA4A/O) GWH18UC-K6DNA4A (GWH18UC-K6DNA4A/I + GWH18UC-K6DNA4A/O) ORIGINAL INSTRUCTIONS, VER. 01 25-01-2020... - Page 2 IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
- Page 3 Specialties note Matching instructions This model adopts RF remote control. The remote controller shall be matched with the air conditioner before operation, otherwise the remote control will be invalid. Before operation, please read the instructions in this page carefully and then do the corresponding matching operation. Note Please done the following operation within 2m from the unit.
-
Page 4: Table Of Contents
Content Operation Notices The Refrigerant.....................1 Precautions......................2 Parts Name......................7 Screen Operation Guide Buttons on remote controller ................8 Introduction for icons on display screen..............8 Introduction for buttons on remote controller ............9 Function introduction for combination buttons.............15 Operation guide ....................17 Replacement of batteries in remote controller .............17 Emergency operation ..................18 Maintenance Clean and Maintenance..................18... -
Page 5: Explanation Of Symbols
Explanation of Symbols Indicates a hazardous situation that, if not avoided, will DANGER result in death or serious injury. Indicates a hazardous situation that, if not avoided, could WARNING result in death or serious injury. Indicates a hazardous situation that, if not avoided, may CAUTION result in minor or moderate injury. -
Page 6: The Refrigerant
Appliance filled with flammable gas R32. Before use the appliance, read the owner’s manual first. Before install the appliance, read the installation manual first. Before repair the appliance, read the service manual first. The Refrigerant To realize the function of the air conditioner unit, a special refrigerant circulates in the system. -
Page 7: Precautions
Precautions WARNING Operation and Maintenance This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 8 Precautions WARNING Maintenance must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Do not repair air conditioner by yourself. It may cause electric shock or damage. Please contact dealer when you need to repair air conditioner. Do not extend fingers or objects into air inlet or air outlet.
- Page 9 Precautions WARNING Attachment Installation must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Must follow the electric safety regulations when installing the unit. According to the local safety regulations, use qualified power supply circuit and circuit break. Do install the circuit break.
- Page 10 Precautions WARNING Do not put through the power before finishing installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The temperature of refrigerant circuit will be high, please keep the interconnection cable away from the copper tube.
- Page 11 Precautions WARNING For the air conditioner with plug, the plug should be reachable after finishing installation. For the air conditioner without plug, an circuit break must be installed in the line. If you need to relocate the air conditioner to another place, only the qualified person can perform the work.
-
Page 12: Parts Name
Parts name Indoor Unit air inlet panel power wire filter horizontal louver air outlet remote controller power display tem.display NOTICE: Actual product may be different from above graphics, please refer to actual products. -
Page 13: Buttons On Remote Controller
Buttons on remote controller ON/OFF button +/- button Cool button Heat button Fan button I Feel button button Mode button button T-ON/T-OFF button Clock button button Temp button X-Fan button Light button Sleep button Wifi button Introduction for icons on display screen Set fan speed Send signal Operation mode... -
Page 14: Introduction For Buttons On Remote Controller
Introduction for buttons on remote controller Note: ● This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status. - Page 15 Introduction for buttons on remote controller I FEEL button Press this button to start I FEEL function and " " will be displayed on the remote controller. After this function is set, the remote controller will send the detected ambient temperature to the controller and the unit will automatically adjust the indoor temperature according to the detected temperature.
- Page 16 Introduction for buttons on remote controller ● When selecting auto mode, air conditioner will operate automatically according to ambient temperature. Set temperature can’t be adjusted and will not be displayed as well. Press "FAN" button can adjust fan speed. Press " "...
- Page 17 Introduction for buttons on remote controller T-ON/T-OFF button ● T-ON button “T-ON” button can set the time for timer on. After pressing this button, " " icon disappears and the word “ON" on remote controller blinks. Press “+” or “-”button to adjust T-ON setting.
- Page 18 Introduction for buttons on remote controller button Press this button to activate health function with " " displayed; press this button for the second time to activate health and air in function with " " and " " displayed; press this button for the third time to activate health and air out function with " "...
- Page 19 Introduction for buttons on remote controller This function indicates that moisture on evaporator of indoor unit will be blowed after the unit is stopped to avoid mould. ● Having set X-FAN function on: After turning off the unit by pressing ON/OFF button indoor fan will continue running for about 2 min.
-
Page 20: Function Introduction For Combination Buttons
original display. If ON/OFF, MODE, TIMER, SLEEP, COOLING or HEATING button is pressed during the setting or inquiry procedure, remote controller will also exit the sleep curve setting. Sleep 4 is Siesta mode. The set temperature will change automatically according to ●... - Page 21 Function introduction for combination buttons Energy-saving function Under cooling mode, press "TEMP" and "CLOCK" buttons simultaneously to start up or turn off energy-saving function. When energy-saving function is started up, "SE" will be shown on remote controller, and air conditioner will adjust the set temperature automatically according to ex-factory setting to reach to the best energy-saving effect.
-
Page 22: Operation Guide
Operation guide After putting through the power, press "ON/OFF" button on remote controller to turn on the air conditioner. Press "MODE" button to select your required mode: AUTO, COOL, DRY, FAN, HEAT. Press "+" or " - " button to set your required temperature. (Temperature can’t be adjusted under auto mode). -
Page 23: Emergency Operation
Emergency operation If remote controller is lost or damaged, please use aux. button to turn on or turn off the air conditioner. The operation in details is as below: air conditioner. When the air conditioner is turned on, it will operate under auto mode. - Page 24 Clean and Maintenance Open panel Open the panel into a certain ● Use dust catcher or water to angle(less than 60°, do not open the panel too forcibly) along the arrow direction from the two the water (below 45℃ ) to clean sides of panel.
- Page 25 Clean and Maintenance NOTICE: Checking before use-season 1. Check whether air inlets and air outlets are blocked. 2. Check whether air switch, plug and socket are in good condition. 4. Check whether mounting bracket for outdoor unit is damaged or corroded. If yes, please contact dealer.
-
Page 26: Malfunction Analysis
Malfunction analysis General phenomenon analysis Please check below items before asking for maintenance. If the malfunction still can’t be eliminated, please contact local dealer or qualified professionals. Phenomenon Check items Solution ● Whether it's interfered severely ● Pull out the plug. Reinsert (such as static electricity, stable the plug after about 3min, and voltage)? - Page 27 Malfunction analysis Phenomenon Check items Solution ● Power failure? ● Wait until power recovery. ● Is plug loose? ● Reinsert the plug. ● Air switch trips off or fuse is ● Ask professional to replace burnt out? air switch or fuse. Air condit- ●...
- Page 28 Malfunction analysis Phenomenon Check items Solution ● Whether there’s odour source, ● Eliminate the odour source. Odours are such as furniture and cigarette, emitted etc. ● Whether there’s interference, ● Disconnect power, put back Air conditio- ner operates such as thunder, wireless power, and then turn on the abnormally devices, etc.
-
Page 29: Error Code
Malfunction analysis Error Code ● When air conditioner status is abnormal, temperature indicator on indoor unit will ation of error code. Error code Troubleshooting It can be eliminated after restarting the unit. If not , please It can be eliminated after restarting the unit. If not , please It can be eliminated after restarting the unit. - Page 30 Appliance filled with flammable gas R32. In case of quality problem or other please contact your local supplier or authorized service center. Emergency number: 112 PRODUCER GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI West Jinji Rd, Qianshan, 519070 Zhuhai China REPRESENTATIVE GREE Czech &...
- Page 31 NOTES...
