Swim Spas
Owner's Manual
O
M
R
2016/03
revised 2017/06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SYNERGY Series FX15 and is the answer not in the manual?

Questions and answers

Summary of Contents for PDC spas SYNERGY Series FX15

  • Page 1 Swim Spas Owner’s Manual  2016/03 revised 2017/06...
  • Page 3: Table Of Contents

    Swim Spa Owner’s Manual   Record of Ownership                    1  Safety Warning                       2  Safety Instruc ons                   3‐6  Safety Signage                        7  Glossary of Terms and Parts     ...
  • Page 4 At the me of prin ng, this manual was deemed as accurate as possible. PDC Spas reserves the right to change product in an effort to enhance and improve, without prior no ce. To be aware of any of these possible changes, log on to www.pdcspas.com, referring to the Customer Care sec on, or contact your retailer directly.
  • Page 5 Swim Spa Owner’s Manual 2  DO NOT REMOVE WARNING LABEL FROM SPA.  ALWAYS ATTACH & LOCK YOUR COVER AFTER USE.  WARNING  Do NOT sit, stand or dive from the TruSwim propulsion surface. The propulsion end is for   opera onal purposes ONLY. WARNING  This unit is a professional‐grade product. A knowledge of construc on techniques, plumbing and electrical installa on according to codes are required for proper installa on and user sa sfac on.
  • Page 6 Safety Instruc ons 3  READ AND FOLLOW ALL IMPORTANT SAFETY INSTRUCTIONS    When installing and using this equipment basic safety precau ons should always be taken to reduce the risk of electrical shock,              to ensure safe usage, and to safeguard the user’s health.  ALL INSTRUCTIONS!!  READ AND FOLLOW    This unit is a professional‐grade product. A knowledge of construc on techniques, plumbing and electrical installa on            according to codes are required for proper installa on and user sa sfac on. It is recommended that a licensed contractor  perform the installa on. Warranty is voided for improper Installa on related issues.    It is the responsibility of the home owner to ensure that all users of the swim spa are adequately informed of all precau ons.                      Use the swim spa only as described in this manual. The swim spa is intended for home use only.  Do not use the swim spa in a                     commercial or rental se ng. All warran es will be voided.    GROUND ALL METAL ELECTRICAL EQUIPMENT     A green colored terminal or a terminal marked G, GR, Ground, or Grounding,  is located inside the supply terminal box  or              compartment.  This terminal must be connected to the grounding means provided in the electric supply service panel, using a            con nuous copper wire equivalent in size to the circuit conductors supplying this equipment.   * according to, but not limited to: NEC,             ...
  • Page 7: Safety Instruc Ons

    Safety Instruc ons 4  DANGER:  TO REDUCE THE RISK OF DROWNING     Prolonged immersion in the swim spa may cause hyperthermia.  The causes, symptoms and effects of hyperthermia may be              described as follows:  Hyperthermia occurs  when the  internal temperature of the body reaches a level several degrees above the  normal body temperature of 98.6 °F (37°C).   The symptoms of hyperthermia include an increase in the internal temperature of the  body, dizziness, lethargy, drowsiness, and fain ng.  The effects of hyperthermia include:        1.  Failure to perceive heat    2.  Failure to recognize the need to exit the swim spa    3.  Unawareness of impending hazard    4.  Fetal damage in pregnant women    5.  Physical inability to exit the swim spa    6.  Unconsciousness resul ng in the danger of drowning    DANGER:  RISK OF INJURY     Do not remove the suc on fi ngs.  The suc on fi ng in this swim spa is sized to match the specific water flow created by the  pump.  Should the need arise to replace the suc on fi ng or the pump, be sure that the flow rates are compa ble.  Never operate  the swim spa if the suc on fi...
  • Page 8 Safety Instruc ons 5   Persons using medica on should consult a physician before using a swim spa since some medica on may induce drowsiness while  other medica on may affect heart rate, blood pressure, and circula on.      Enter and leave swim spa slowly and with cau on.  Surfaces around swim spa will be wet and slippery.    WARNING      1. Never use the swim spa alone.    2. Do not bring any object into the swim spa that could damage the swim spa shell.    3. Do not sit on swim spa cover or place objects on it; it is not designed to support weight.    4. Remove any water or debris that may collect on the swim spa cover.    5. Keep all chemicals away from children and pets.    6. The PH and chemical balance of the water must be maintained as explained in this manual.  Failure to do so may cause    injury to users or damage to the swim spa, and will void your warranty.    WARNING:  HEALTH CONSIDERATIONS     The use of alcohol, drugs, medica on can greatly increase risk of fatal hyperthermia.      ...
  • Page 9 Safety Instruc ons 6        5.   These units are not provided with an outdoor antennae; when provided, it should be installed in accordance with Ar cle  810  of the U.S. Na onal Electrical Code, ANSI/NFPA 70.        6.   Do not service this product yourself as opening or removing covers may expose you to dangerous voltage or other risk of   i n‐ jury.  Refer all servicing to qualified service personnel.        7.   When the power supply connec on or power supply cord(s) are damaged; if water is entering the audio/video compart   ment or any electrical equipment compartment area; if the protec ve shields or barriers are showing signs of deteriora on;  or if  there are signs of other poten al damage to the unit, turn off the unit and refer servicing to qualified service personnel.        8.   This unit should be subjected to periodic rou ne maintenance (for example, once every 3 months) to make sure that the  unit  is opera ng properly.    ADDITIONAL SAFETY CONSIDERATIONS     Install the swim spa to provide drainage for compartments of electrical components. ...
  • Page 10 Safety Signs 7  Warning Danger Signs  Cabinet Installed: For your referral, safety and convenience, a weather resistant sign has been mounted on the end cabinet side of your portable swim spa. Become familiar with the precau ons, exercise safety and care while enjoying your swim spa. No fy the factory or your retailer should you require addi onal signs or replacements.  ...
  • Page 11 Parts Descrip on and Func on 8    Hydrotherapy Jets:     Various sized fi ngs mix water with air to produce localized therapy, in a straight stream, circular mo on, or in random pa erns for massage. Posi oned in massage seats from neck to feet, RX6 massage columns (Synergy™...
  • Page 12 Parts Descrip on and Func on 9  Ozone Jets: All swim spas are equipped with ozone jets for sanita on. The filter cycle should cir‐ culate 8‐10 hours daily for proper ozona on. Use the programmable electronic control center to program this opera on.  ...
  • Page 13 Parts Descrip on and Func on 10  Secondary pump: A single speed secondary pump has been added to the spa zone of the FX219, FX219s and TSX219 for addi onal enjoyment Fitness pumps:   Two single speed pumps designed for use with the swim jets. Bu on 2 and bu on 3 will ac vate the fitness pumps.
  • Page 14 Swim Spa Specifica ons—FX15 Model 11  GENERAL rev. 2016/11 Seating Capacity 2 seats, 2 RX6, fitness area Shell Material Acrylic Fitness Length 112” approx. Dimensions (Domestic) 180” x 92” x 56” Dimensions (Export) 427 cm. x 234 cm x 142 cm. Water Capacity 2,140 gallons (8,100 liters) Dry Weight...
  • Page 15 Swim Spa Specifica ons—FX15s Model 12  GENERAL rev. 2017/05 Seating Capacity 2 seats, 2 RX6, fitness area Shell Material Acrylic Fitness Length 130” approx. Dimensions (Domestic) 180” x 92” x 56” Dimensions (Export) 427 cm. x 234 cm x 142 cm. Water Capacity 2,240 gallons (8,479 liters) Dry Weight...
  • Page 16 Swim Spa Specifica ons—FX17 Model 13  GENERAL rev. 2016/11 Seating Capacity 2 seats, 2 RX6, fitness area Shell Material Acrylic Fitness Length 136” Dimensions (Domestic) 204” x 92” x 56” Dimensions (Export) 518 cm. x 234 cm x 142 cm. Water Capacity 2,420 gallons (9,161 liters) Dry Weight...
  • Page 17 Swim Spa Specifica ons—FX19 Model 14  GENERAL rev. 2016/11 Seating Capacity 2 seats, 2 RX6, fitness area Shell Material Acrylic Fitness Length 160” approx. Dimensions (Domestic) 227” x 92” x 56” Dimensions (Export) 578 cm. x 234 cm x 142 cm. Water Capacity 2,700 gallons (10,221 liters) Dry Weight...
  • Page 18 Swim Spa Specifica ons—FX219 Model 15  GENERAL rev. 2016/11 Seating Capacity 6 seats, 2 RX6, fitness area Shell Material Acrylic Fitness Length 100” approx. Dimensions (Domestic) 227” x 92” x 56” Dimensions (Export) 578 cm. x 234 cm x 142 cm. Water Capacity 2,425 gallons (9,180 liters) Dry Weight...
  • Page 19 Swim Spa Specifica ons—FX219s Model 16  GENERAL rev. 2016/11 Seating Capacity 6 seats, 2 RX6, fitness area Shell Material Acrylic 6 H1 Fitness Length 118” approx. Dimensions (Domestic) 227” x 92” x 56” Dimensions (Export) 578 cm. x 234 cm x 142 cm. Water Capacity 2,525 gallons (9,558 liters) Dry Weight...
  • Page 20 Swim Spa Specifica ons—TSX15 Model 17  6 H 1 GENERAL rev. 2016/11 Seating Capacity 2 seats, fitness area Shell Material Acrylic Fitness Length 114” approx. Dimensions (Domestic) 180” x 92” x 56” Dimensions (Export) 457 cm. x 234 cm x 142 cm. Water Capacity 2,240 gallons (8,479 liters) Dry Weight...
  • Page 21 Swim Spa Specifica ons—TSX17 Model 18  6 H1 GENERAL rev. 2016/11 Seating Capacity 1 seat, fitness area Shell Material Acrylic Fitness Length 124” approx. Dimensions (Domestic) 204” x 92” x 56” Dimensions (Export) 518 cm. x 234 cm x 142 cm. Water Capacity 2,420 gallons (9,160 liters) Dry Weight...
  • Page 22 Swim Spa Specifica ons—TSX19 Model 19  6 H1 GENERAL rev. 2016/11 Seating Capacity 1 seat, fitness area Shell Material Acrylic Fitness Length 148” approx. Dimensions (Domestic) 227” x 92” x 56” Dimensions (Export) 577 cm. x 234 cm x 142 cm. Water Capacity 2,700 gallons (10,220 liters) Dry Weight...
  • Page 23 Swim Spa Specifica ons—TSX219 Model 20  GENERAL rev. 2016/11 Seating Capacity 5 seats, fitness area Shell Material Acrylic Fitness Length 102” approx. Dimensions (Domestic) 227” x 92” x 56” 6 H1 Dimensions (Export) 577 cm. x 234 cm x 142 cm. Water Capacity 2,525 gallons (9,558 liters) Dry Weight...
  • Page 24: Installa On And Site Prepara On

    Installa on Guidelines and Site Prepara on 21  Swim Spa installa on can be quick and simple if these guidelines are considered in planning the site. Please read the following informa on carefully. Proper planning will make the delivery and install more economical and efficient and the proper site selec on will increase your year‐round enjoyment.
  • Page 25 Installa on Guidelines and Site Prepara on 22  Important:  All swim spa sides must be accessible for regular maintenance or in the event that service is required. General maintenance will require entry to equipment behind cabinet panels. It is recommended to allow 3 feet of access to all sides of the swim spa for rou ne and service maintenance.
  • Page 26 Par ally or Fully Recessed Installa ons:      PDC Spas does not recommend this type of installa on, although if this is what you have chosen for your new swim spa, please review the following considera ons. 1. A system for preven ng collec on and pooling of water must be designed in accordance to local authori es.
  • Page 27 Due to the nature of water flow and hydrotherapy pumps, please be advised that air locking of pumps may occur. PDC Spas has taken measures to reduce the possibility of this, but it s ll may occur, especially a er refilling a swim spa.
  • Page 28 Installa on and Ini al Start‐Up Instruc ons 25  12. Refer to Waterway Neo 2100 Control sec on for hea ng, filtra on cycles and func on 13. Adjust water chemistry according to the instruc ons provided in water chemistry guidelines sec on. 14.
  • Page 29 All swim spa systems require the installa on of a ground fault circuit interrupter (GFCI) protector or equivalent; (RCD, for export installs), at the power source (NOT SUPPLIED BY PDC SPAS) by a qualified electrician in accordance with all codes and regula ons. Refer to typical GFCI installa on photos and illustra ons on the following pages.
  • Page 30 Electrical Guidelines—State ‐Side Installa ons 27  ATTENTION ELECTRICIAN: All PDC Swim Spa Units must be installed with an approved G.F.C.I. in accordance with all applicable codes. Installa on of G.F.C.I. varies among those manufacturers. Follow each manufacturer’s guidelines to ensure proper opera on and protec on of swim spa occupants. This diagram is a “Typical”...
  • Page 31: Electrical Guidelines

    28  Electrical Guidelines—Export Installa ons Electrical Guidelines (60Hz) North America 15  FOR QUALIFIED ELECTRICIAN REFERENCE ONLY!     All installa ons and connec ons are to be performed by a qualified, licensed electrician only   and in accordance with the Na onal electric code and all applicable local regula ons.     Ensure power is turned off prior to making any electrical connec ons.  ATTENTION ELECTRICIAN:  Swim Spa Units must be installed with a Class A 50 Amp Ground Fault Circuit Interrupter (not supplied) in accordance with the Na onal Electric Code and all applicable local codes.
  • Page 32 Wiring Guidelines—Op onal for TruSwim Propulsion System (60 Hz) North America 29  FOR QUALIFIED ELECTRICIAN REFERENCE ONLY!     All installa ons and connec ons are to be performed by a qualified, licensed electrician only   and in accordance with the Na onal electric code and all applicable local regula ons.     Ensure power is turned off prior to making any electrical connec ons.  Your new TruSwim Swim Spa will arrive from the factory wired to operate with a single 120/240 volt 50 Amp Ground Fault Circuit Interrupter Type A circuit breaker (not included from PDC) supplied from the homeowner’s power source.
  • Page 33 Electrical Guidelines—Export Installa ons 30  FOR QUALIFIED ELECTRICIAN REFERENCE ONLY!     All installa ons and connec ons are to be performed by a qualified, licensed electrician only   and in accordance with the Na onal electric code and all applicable local regula ons.     Ensure power is turned off prior to making any electrical connec ons.  ATTENTION ELECTRICIAN:  Swim Spa Units must be installed with a Residual Current Device, RCD, (not supplied) Having a rated opera ng residual current not seceding 30 mA in accordance with all applicable local codes. Installa on of RCD varies among those manufacturers.
  • Page 34: Export

    Wiring Guidelines—Op onal for TruSwim® Propulsion System (50 Hz) Export 31  FOR QUALIFIED ELECTRICIAN REFERENCE ONLY!     All installa ons and connec ons are to be performed by a qualified, licensed electrician only   and in accordance with the Na onal electric code and all applicable local regula ons.     Ensure power is turned off prior to making any electrical connec ons.  Your new TruSwim Swim Spa will arrive from the factory wired to operate with a single phase 230 Volt 32 Amp Residual Current Device, RCD current device (not supplied by PDC) from the homeowner’s power source.
  • Page 35 32  WARNING: Read all instruc ons before using the spa. PDC Spas, PDC Interna onal assumes no responsibility for personal injury or property damage sustained by or through the use of this product. When installing and using this equipment basic safety precau ons should always be taken to reduce risk of electrical shock, ensure safe usage, and safeguard the user’s health.
  • Page 36 Opera on Systems—Waterway Neo 2100 Series Control, Synergy™ Models 33  Priming Mode  When power is ON, the system will enter a priming mode with priming screen display on the panel. In this mode, all devices such as JETS, or LIGHT are operable. JETS can be turned an and off to prime the pump.
  • Page 37 Opera on Systems—Waterway Neo 2100 Series Control, Synergy Models 34  Se ng Screens        Rotate View:  rotate the view 180°, the UP and DOWN bu on also swap when rotated. With ROTATE VIEW highlighted press MENU to enter ROTATE VIEW se ng. Use UP/DOWN to select the desired se ng and RETURN to exit and confirm the se ng. Special Temp: ...
  • Page 38 Opera on Systems—Waterway Neo 2100 Series Control, Synergy Models 35  Error Codes  Error caused when SENSOR 1 and SENSOR 2 have been plugged in incorrectly. Swap the SENSOR 1 and SENSOR 2 plug in controller to correct this problem. Clean filter. Check SENSOR 1 connec on.
  • Page 39 36  WARNING: Read all instruc ons before using the spa. PDC Spas, PDC Interna onal assumes no responsibility for personal injury or property damage sustained by or through the use of this product. When installing and using this equipment basic safety precau ons should always be taken to reduce risk of electrical shock, ensure safe usage, and safeguard the user’s health.
  • Page 40 Opera on Systems— Waterway Neo 2100 Series Control, TruSwim® Models 37  Priming Mode  When power is ON, the system will enter a priming mode with priming screen display on the panel. In this mode, all devices such as JETS, or LIGHT are operable. JETS can be turned an and off to prime the pump.
  • Page 41 Opera on Systems— Waterway Neo 2100 Series Control, TruSwim® Models 38  Swim Bu on  3.  Press the SWIM bu on 1.  2.  Press the SWIM bu on to Then press UP or DOWN again to turn OFF the pump bu on to select your desired turn the pump ON—the blue (the pump will con nue to SWIM icon on the LCD screen...
  • Page 42 Opera on Systems— Waterway Neo 2100 Series Control, TruSwim® Models 39  Se ng Screens        Rotate View:  rotate the view 180°, the UP and DOWN bu on also swap when rotated. With ROTATE VIEW highlighted press MENU to enter ROTATE VIEW se ng. Use UP/DOWN to select the desired se ng and RETURN to exit and confirm the se ng. Special Temp: ...
  • Page 43 Opera on Systems— Waterway Neo 2100 Series Control, TruSwim® Models 40  Error Codes  Error caused when SENSOR 1 and SENSOR 2 have been plugged in incorrectly. Swap the SENSOR 1 and SENSOR 2 plug in controller to Clean filter. correct this problem. Check SENSOR 1 connec on.
  • Page 44 Wi‐Fi Opera on Instruc ons—Waterway Neo 2100 Series Control 41  1.  Download and install the app from App Store or 7.  Go back to the App, press Next. Google Store. 8.  Select your home network from the list (If your network name is not on the listed, it can be entered 2.  Click on Create an Account.
  • Page 45 Fitness and Workout Programs 42  Swim, walk, run, use weights for upper and lower body fitness or choose any underwater fitness machine;  treadmill or ellip cal, for the most natural, proven, health and well‐being program.  Aqua c exercise promotes  balance, is easy on joints and enjoyed by any age group, all in the convenience and privacy of your own home.  Patent Pending Technology with TruSwim® dual propulsion system provides the widest, smoothest and   strongest exercise current of any swim spa in the market. Congratula ons in your choice to add the   very best swim spa and the benefits of aqua c exercise to your lifestyle.       Personalized Workout Programs      It is up to you. You may choose a leisurely jog or swim benefi ng from the buoyancy of aqua c exercise, or for the athlete in training, the added challenge of our prop strengths from 5% to a full 100% will keep you in shape and compe Refer to the Control sec on of this guide for simple programming of up to 10 speeds, each at a maximum of...
  • Page 46 Aqua c Exercise Equipment 43  Pulley and Rope Exercise System for upper body and core fitness. Pulley‐Rope Swim Spa Exercise System Review these safety precau ons before installing and using the AquaForce™ exercise System.      Rope intended for use with AquaForce™ ONLY, in swim spas equipped for the System.   : ...
  • Page 47 Aqua c Exercise Equipment 44  Swim Tether Exercise System Tether System increases resistance for aqua c exercising; swimming, walking, jogging. Review these safety precau ons before installing and using the AquaCross™ exercise System to assure it will  be used properly and will eliminate any possibility of breakage or rod failure. This system is engineered to  provide resistance technique and aerobic exercise in water.  IMPORTANT SAFETY & CARE INSTRUCTIONS ‐ PLEASE READ  1. Do not mount your Swim Tether™ more than 24” above the waterline for safety. 2.
  • Page 48 Fitness and Workout Programs Fitness and Workout Programs 42  45  Product Disclaimer. Read all instruc ons before using the Swim Tether® device. The Swim Tether® device is specifically designed to maximize water exercise and safety. The components of the Swim Tether device (i.e., the best, tether, and fully assembled pole) are specifically designed to work, in tandem, to achieve the safety and results Swim Tether is proud to promote for its product.
  • Page 49: Water Chemistry Basics

    Water Chemistry Basics 46  The Importance of Proper Water Chemistry      Evapora on:   Only pure water evaporates leaving a higher concentra on of salts, metals, minerals and unused chemicals in the remaining swim spa water. Over me, the water can become saturated with these impuri es causing stand and scales to build up on the spa walls and equipment components.
  • Page 50 Water Maintenance and Care 47  Water Care Ini al Start‐Up         Improper use of swim spa chemicals may be dangerous and could damage your swim spa and cover. Since this damage is not covered by the warranty, it is extremely important to take precau ons when using these products. Only use chemicals and cleaning agents designed for swim spas.
  • Page 51 Water Maintenance and Care 48  Water Care Schedule       Before Use:  Each me before the unit is used, check the water with a test strip for proper sanita on levels and adjust accordingly achieving the op mum 2‐4 ppm level. The unit should not be used if the level is 5 ppm or higher.  ...
  • Page 52: Maintenance

    Regular Maintenance 49  Regular Swim Spa Maintenance Procedures    There is some basic maintenance that will need to be performed on your swim spa. By following these basic maintenance suggested procedures, you will insure that your spa provides years of service. These basic maintenance procedures are not covered under warranty.
  • Page 53 Regular Maintenance 50    Thermal Cover Care       Always use the locking thermal cover when not in use to reduce heat‐up me, opera ng costs and keep unwanted out. To prolong the life of the cover, handle it with care and clean it regularly using mild soap and water. Periodic treatments with a vinyl condi oner will help protect against deteriora on caused by UV rays from the sun.
  • Page 54: Winterizing

    8. It may be necessary to bleed air from the pump or pumps on your swim spa, if a er start up your swim spa pumps do not operate. Due to the nature of water flow and hydrotherapy pumps, please be advised that air locking of pumps may occur. PDC Spas has taken measures to reduce the possibility of this, but it s ll may occur, especially a er refilling a swim spa.
  • Page 55 For TruSwim® Series models, remove the end cabinet panel and check the hydraulic oil level of the hydraulic oil reservoir. Oil reservoir should be 3/4 full. If oil is needed, add biodegradable oil supplied by PDC Spas for TruSwim® propulsion systems only. Use of any other fluid will void warranty.
  • Page 56: Troubleshoo Ng

    Basic Troubleshoo ng 53  A good general rule is to visually inspect your swim spa and equipment area frequently. If anything looks broken, worn, or incorrect, contact your electrician or spa retailer. A simple repair may prevent an injury or more serious problems requiring expensive repairs.
  • Page 57 Swim Spa Care and Record of Maintenance 54  Date Date Date Date Date Date Date Test GFCI Test GFCI Test GFCI Test GFCI Change All Suc on Fi ngs (every 7 years) Clean and Drain Swim Spa Change / Clean Filter Clean / Condi on Cover Miscellaneous Miscellaneous...
  • Page 58 Swim Spa Care and Record of Maintenance 55  Date Date Date Date Date Date Date Test GFCI Test GFCI Test GFCI Test GFCI Change All Suc on Fi ngs (every 7 years) Clean and Drain Swim Spa Change / Clean Filter Clean / Condi on Cover Miscellaneous Miscellaneous...
  • Page 59 Swim Spa Care and Record of Maintenance 56  Date Date Date Date Date Date Date Test GFCI Test GFCI Test GFCI Test GFCI Change All Suc on Fi ngs (every 7 years) Clean and Drain Swim Spa Change / Clean Filter Clean / Condi on Cover Miscellaneous Miscellaneous...
  • Page 60 The manufacturer reserves the right to change product as deemed necessary without no fica on. As a manufacturer we stand behind our products in accordance to our wri en limited warranty. Your retailer is an independent business operator not employed by the manufacturer. PDC Spas, Plas c Development Co, Inc., can not accept responsibility for any representa ons, statements, or contracts made by any retailer beyond the parameters of our warranty.
