SUPER NOVA INSERT RF
INSTALLATION & OPERATING INSTRUCTIONS
IMPORTANT:
INSTALLER, PLEASE LEAVE THESE INSTRUCTIONS WITH THE UNIT ON COMPLETION.
10 YEAR FIREBOX WARRANTY
The firebox is covered by a 10 year warranty.
Other parts are covered by a one year limited warranty.
Head Office – 13 French Avenue, Brendale, Queensland 4500
Telephone – PH: (07) 3490 5500
Facsimile – FAX: (07) 3490 5520
Website: -
www.kemlan.com.au
Business hours: - Monday to Thursday 7:30am-4:00pm. Friday 7:30am-2:00pm
1
Email: -
sales@kemlan.com.au
03/07/2017
Ver.7
Advertisement
Table of Contents
Related Manuals for Jetmaster kemlan supernova rf insert
Summary of Contents for Jetmaster kemlan supernova rf insert
- Page 1 Specialists in fireplace design and manufacture SUPER NOVA INSERT RF INSTALLATION & OPERATING INSTRUCTIONS IMPORTANT: INSTALLER, PLEASE LEAVE THESE INSTRUCTIONS WITH THE UNIT ON COMPLETION. 10 YEAR FIREBOX WARRANTY The firebox is covered by a 10 year warranty. Other parts are covered by a one year limited warranty. Head Office –...
- Page 2 DIMENSIONS SUPER NOVA INSERT RF – STANDARD FASCIA/CAST IRON FASCIA C / IRON C / IRON MEASUREMENT 1000 • Denotes measurement from standard and cast iron fascia, measurement is also dependent on fascia position placement. 03/07/2017 Ver.7...
-
Page 3: Technical Specifications
TECHNICAL SPECIFICATIONS PERFORMANCE: Average peak heat output – 11.6 kW Average Fuel consumption - 1.9 kg/hr. Average efficiency – 66% Weight – 128 kg. *Average dry fuel (hardwood) consumption rate in kilogram/hour when heater is used normally and safely. FIREBOX IS DESIGNED TO BE INSTALLED IN A MASONRY (BRICKWORK OR HEBEL BLOCK) CAVITY CAUTION –... -
Page 4: Installation Instruction
INSTALLATION INSTRUCTION SUPER NOVA MASONRY/TIMBER CAVITY INSTALLATION 25mm min. clearance between Flue system to be installed 10” flue and framing to suit AS/NZS 2918.2001 Ceiling Triple skin flue system (10”, 8” and 6”) Register plate with vented upstands Minimum 600mm below ceiling. ------------------------------------------------ Insul wool (supplied by installer) can be placed on top of register plate... - Page 5 MANTLE DIMENSIONS Mantle 350mm above hot air outlet deflector Mantle upright to be no closer than 150mm from the fuel loading door opening and extend into the room by no more than 100mm. Fore hearth is 9mm thick and consisted of Bellis board and must extend a minimum of 200mm either side of the fuel loading door opening.
- Page 6 INSTALLATION INSTRUCTION SUPER NOVA FULL MASONRY CHIMNEY INSTALLATION Improved heating efficiency is achieved by admitting cool air into the brick cavity where it is heated by the outer skin of the firebox and active flues, then released back into the room via hot air outlet vents. NOTE: - Top of brick chimney can be left open, where no trees can cause a build up of leaves etc.
- Page 7 INSTALLATION INSTRUCTION SUPER NOVA METAL CHIMNEY INSTALLATION Improved heating efficiency is achieved by admitting cool air into the brick cavity where it is heated by the outer skin of the firebox and active flues, then released back into the room via hot air outlet vents. plain crimped Run a bead of silicone down...
- Page 8 INSTALLATION INSTRUCTION Alternate finish to full masonry chimney S/steel Cowl S/steel weather tray With upstand Run a bead of silicone down the vertical seam of the outer casing to the weather tray. 03/07/2017 Ver.7...
-
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS MINIMUM HEIGHT OF FLUE SYSTEM EXIT INSTALLATION TO COMPLY WITH AS/NZS 2918 ANY NEARBY STRUCTURE 3000 3000 OR LESS MORE THAN 3000 600 MIN 3000 INCREASE AS NECESSARY UNTIL NOTHING WITHIN 3000 OF FLUE TOP 1000 MIN IF CLEAR WITHIN 3000 OF TOP OF FLUE 3000 OR LESS 3000... - Page 10 ABOUT CURING Your stove has been painted with the highest quality silicone stove paint and has special break-in procedures to cure it with heat and make it hard. VENTILATE WELL Ventilate the house during the first three times the stove is used. The paint on the stove will give off smoke heavy with carbon dioxide and has an odor.
- Page 11 03/07/2017 Ver.7...
- Page 12 INSTRUCTIONS FOR OPERATING YOUR KEMLAN SLOW COMBUSTION WOOD BURNING HEATER Open the air inlet fully by sliding the air inlet control to high. Crumple at least three double pages of newspaper into loose balls and place them into the centre of the firebox.
-
Page 13: Operating Hints
OPERATING HINTS To get the best from your Kemlan heater it is essential that you use good firewood, and use it correctly Many people do not understand the principle of using a wood burning appliance and we suggest that it will be worth your while to study the following extract from a well known American publication. -
Page 14: This Warranty Does Not Cover
WARRANTY Kemlan wood heaters carry a warranty on the 6mm firebox for a period of ten (10) years. This warranty also covers other components of the heater for a period of one (1) year. These components include the baffle plate, handle assembly, secondary air tubes and fan. Kemlan’s warranty covers the wood heaters against defects in materials and manufacture.
