1.2 Install Device Installer

1. Insert the product CD into your CD-ROM drive. The CD will automatically start and display the main
window.
If the CD does not launch automatically:
a) Click the Start button on the Task Bar and select Run.
b) Enter your CD drive letter, colon, backslash, autorun.exe (e.g., D:\autorun.exe).
2. Click the Go to Software Page button.
3. Click the Device Installer button.
4. Respond to the installation wizard prompts.
5. Restart your system.

1.2.1 RUN Device Installer

1. Click Start/Programs/DeviceInstaller 4.4/DeviceInstaller.
2. Apply power to the NET485. Wait for a few seconds while the unit connects to the network.
3. Click the Search icon. The list of device servers displays.
You can identify your device by matching the Hardware (MAC) Address printed on the bottom of the
NET485 to those listed on the Device Installer window. If you cannot locate it, try Search again.
4. The Device Installer main dialog box appears.
5. Double-click your device in the list. The window will expand to display three tabs.
6. Click the Web Configuration tab.
7. To view the Web-Manager in the current DeviceInstaller window, click the Navigate icon
the Web-Manager in a web browser, click the External Browser icon
8. When a password window appears, press Enter.
NET485 Quick Start
. To open
.
