FLIGHT PRACTICE

To master flying your aircraft try practicing the excersizes shown below.Start with simple vertical takeoffs,
landings,and left/right turning and rotating.Once those are mastered move on to square and cross
maneuvers.Good luck and have fun!
Fixed-point landing Square Pattern Maneuver
PERFORMING 360º STUNT FLIPS
After you have mastered flying the Falcon™ you are ready to try flips.Once the Falcon™ is hovering at least
3 meters (about 10 feet) off the ground click the 360º Flip Button (see diagram O1) and push the right lever
forward slightly and let go.The Falcon™ will instantly perform a forward flip.To perform a backwards or
side flip click the 360º Flip Button and push the right lever in the direction you wish to flip just as you did
for the forward flip (see diagram O2 & O3).
O1
O3 Flip Forward
Flip Right
7
Cross Pattern Maneuver
O2
Flip Backward
Flip Left
TROUBLESHOOTING YOUR FALCON™
PROBLEM POSSIBLE REASON
1.Power switched off
No Power 2.Polarity is reversed
3.Batteries may be dead
1.Remote is switched off
Remote Not 2.Falcon™ battery is not connected
Responding 3.Too windy
4.The remote is not synced
Aircraft Won't 1.Rotor speed too slow
lift off 2.Aircraft not fully charged
Aircraft
Descends 1.Moving the throttle too quickly
Too Fast
Aircraft Not 1.Gyroscopes not functioning
Responding
Loss of
Falcon™ 1.Aircraft is out of range of remote
Control

ATTACHING THE CAMERA

You have the option of attaching the included wide-angle 5 mega pixel 30 FPS camera with precision
stabilizer to your Falcon™ quadrocopter.
1. Install the stabilizer to the battery cover panel on the under side of the Falcon™ with the 4
screws provided (see diagram P).
2. Snap the camera to the stabilizer and connect the camera lead to the Falcon™ base (see diagram Q).
P
Stabilizer
Camera
SOLUTION
1.Switch the ON/OFF switch to ON
2.Make sure all batteries are installed
correctly (see diagram B)
3.Replace batteries
1.Switch the ON/OFF switch to ON
2.Switch the ON/OFF switch to ON
3.Windy conditions severely impair the
operation of the Falcon™
4.Re-sync the remote
1.Push throttle lever forward
2.Recharge your Falcon™
1.Control the throttle slower and
smoother
1.Turn of the Falcon™ and
Reset the Gyros (see diagram L)
1.Keep the aircraft within a 500
Feet radius of the remote
Q
