Command Groups

Miscellaneous Command Group

2-30
Table 2-26: Measurement Commands (cont.)
Command
MEASUrement:STATIstics
MEASUrement:STATIstics:MODE
MEASUrement:STATIstics:WEIghting
Use the commands in the Miscellaneous Command Group to perform actions that
do not fit into other categories.
Several commands and queries are common to all 488.2-1987 devices. The
488.2-1987 standard defines these commands. The common commands begin
with an asterisk (*) character.

Table 2-27: Miscellaneous Commands

Command
AUTOSet
AUTOSet:ENAble
CLEARMenu
DATE
*DDT
DESkew
DESkew:DISPlay
FPAnel:PRESS
FPAnel:TURN
GPIBUsb:ADDress?
GPIBUsb:ID?
Description
Clears or returns all of the statistics
accumulated for all period measurements
(MEAS1 through MEAS4)
Turns measurement statistics on or off
Controls the responsiveness of the mean
and standard deviation to waveform changes
Description
Sets the vertical, horizontal and trigger
controls to provide a stable display of the
appropriate waveform. This is equivalent to
pressing the front panel Autoset button
Enables or disables the autoset feature
Clears the current menu from the display
Sets or returns the date displayed by the
oscilloscope
Sets or returns the commands that will be
executed by the group execute trigger
Causes the deskew values for all channels
to be set to the recommended values
Sets or returns the state of the deskew table
display
Simulates the action of pressing a specified
front-panel button
Duplicates the action of turning a specified
front-panel control knob
Returns the current GPIB address
Returns the identification string of the
connected adaptor module and firmware
version
MSO4000 and DPO4000 Series Programmer Manual
