Basic Operation; Turning The Power On And Off; Switching Audio Modes - Eclipse CD5030 Reference Manual

Turning the power on and off

When the power is turned on, the state used when the power
was turned off such as CD and tuner playback is restored.
When the vehicle has no ACC position on the ignition
switch, care is needed when turning off the main unit.
Follow Step 2 or Step 3 when turning off the power.
1 Press the [SOURCE/PWR] button
while the power is OFF.
The power will come ON.
ATTENTION
When the main unit's power is turned on for the first
time or if the battery terminals have been disconnected
because of a reason such as vehicle maintenance and
the power is then turned back on, the main unit will start
up in FM1 mode. After this, the broadcast stations will be
searched for automatically and stored in buttons [1] to [6].
2 Press the [SOURCE/PWR] button
while the power is ON, for more than
one second, until you hear a beep.
The power will go OFF and the main unit will
be in Standby.
4

Basic Operation

English

Switching Audio Modes

1 Press the [SOURCE/PWR] button for
less than one second.
Press the button to switch mode in the
following sequence:
*1
*1
*2
*1
*5
or
*5
*3
*4
*1: This cannot be selected if the CD changer is
not connected to the main unit.
*2: Not displayed if no disc is inserted.
*3: Cannot be selected if the AUX mode is not set to
ON. For details, refer to the ECLIPSE Website
given below and download the operation manual.
(URL:www.eclipse-web.com/us-index.html)
*4: Cannot be selected if the BT-Audio mode is not
set to ON. For details, refer to "Switching the
Bluetooth audio mode on and off" on page 12.
*5: You can select either the iPod or the USB
device once it has been connected and the
main unit has recognized it.
