MSA
MSA AUER
3.5
Desktop Mounting
(1)
Place the GALAXY GX2 on a flat, stable surface.
(2)
Insert the power supply into the GX2 power jack [see chapter 4.1 for first-time power up ini-
tialization].
The Test Stand display pivots for ease of viewing.
(3)
If using MSA Cylinder Holders, the left most Cylinder Holder should have a fresh air filter
attached to the top port.
US
GALAXY GX2
Installation
21
