Floto-pump E
Standard and High Pressure Models
All content in this instruction is property of the Waterous Company. Instructions subject to change without
Waterous Company 125 Hardman Avenue South, South St. Paul, Minnesota 55075 USA (651) 450-5000
Instructions subject to change without notice.
Operation & Maintenance
Form No.
F-2210
Table of Contents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Read through the safety and operating
instructions carefully before using your
Waterous Floto- pump.
Visit us at www.waterousco.com
Issue Date
Rev. Date
02/08/94
10/01/07
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . .
1
2
4
5
5
6
6
6
7
8
9
9
9
10
11
12
13
14
15
16
17
18
Advertisement
Table of Contents
Related Manuals for Waterous Floto-pump IL1330
Summary of Contents for Waterous Floto-pump IL1330
-
Page 1: Table Of Contents
........All content in this instruction is property of the Waterous Company. Instructions subject to change without... -
Page 2: Important Information
Waterous dealer, or call us at operation, maintenance and a list of repair 651-450-5000 to find out how you can get parts for your Floto-Pump. Before operating the proper training and protective clothing. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Page 2 of 18 The Floto Pump is designed and intended for use as portable firefighting equipment. DANGER Exhaust gas hazard. Can cause illness or death. Do not run the engine in an enclosed area. Exhaust gases contain carbon monoxide, an odorless, deadly poison. DANGER Fire or explosion hazard. - Page 4 SAFETY INSTRUCTIONS Page 3 of 18 WARNING Scalding Water Hazard. May result in serious burns. When operating the pump, be sure to open at least one discharge valve slightly to prevent the pump from overheating. If the pump runs for a few minutes completely closed, it may heat the water enough to scald someone when the valve is opened.
-
Page 5: Warning Decals
WARNING DECALS Page 4 of 18 Warning - Carbon Monoxide Warning - Hot Surface IL2391 Warning - Hearing Protection Required... -
Page 6: Operation
OPERATION Page 5 of 18 Pump Operating Features Throttle Arm Choke Lever (Shown in Open Position) Throttle Float Air Intake Muffler On/Off Switch Recoil Starter Fuel Tank Cap Vent IL2394 Discharge... -
Page 7: Fuel Mixture
OPERATION Page 6 of 18 Preparation Before Operation NOTE: The pressurized discharge hose will hold the running Floto Pump out from shore, but a rope may be needed to prevent wind or current from swinging it back. Symbols Open vent in fuel tank cap by turning it counterclock‐ wise. -
Page 8: Compression Release Valve
OPERATION Page 7 of 18 Compression Release Valve Prior to starting the engine, engage the compression release by depressing the black cap on top of the NOTE: This Floto Pump is equipped with a com‐ compression release valve. pression release valve to aid in starting the en‐ Start the engine by following the normal start proce‐... -
Page 9: Carburetor Adjustment
OPERATION Page 8 of 18 Carburetor Adjustment High Speed Idle Needle Low Speed Idle Needle The carburetor is factory adjusted, but may require Adjust the low speed idle needle first, and accelerate. readjustment, especially for cold weather operation or If the engine bogs down or accelerates slowly, turn the high altitudes. -
Page 10: General Operating Hints
The following pages list the repair parts for the Standard Waterous dealer or directly from Waterous. Floto, High Pressure Floto and the engine repair parts. Contact your Waterous dealer, or call a Waterous service specialist at 651-450-5200 with any questions. -
Page 11: Troubleshooting
TROUBLESHOOTING Page 10 of 18 Problem Cause What To Do No fuel in tank. Fill tank. Ignition switch off. Turn ignition switch on. Fuel tank vent closed. Open fuel tank vent. Fuel line or fuel tank screen clogged. Clean fuel line and screen. Hold throttle in fast position and crank engine or close carburetor main adjustment needle and crank until Flooded. -
Page 12: Pump Repair Parts
PUMP REPAIR PARTS Page 11 of 18 Refer to the following pages: Float and Fuel system ............Exhaust and Air Intake Prior to 7/21/06 . -
Page 13: Float And Fuel System
FLOAT AND FUEL SYSTEM Page 12 of 18 REF. DESCRIPTION REF. DESCRIPTION Float Hearing protection warning decal Self-locking nut, 3/8-16 Patent decal Plain washer, 3/8 in. Folding spanner wrench Intake screen Fuel tank subassembly (includes ref no. 41, 50 & 77) Fuel line Hex hd screw, 1/4-20 x 1/2 in. -
Page 14: Exhaust And Air Intake Prior To 7/21/06
EXHAUST AND AIR INTAKE (PRIOR TO 7/21/06) Page 13 of 18 REF. DESCRIPTION REF. DESCRIPTION Air intake stack cap Lock washer, internal tooth, 1/4 in. Wing nut, No. 10-32 Muffler Lock washer, internal tooth, no. 10 Exhaust adapter Plain washer, 3/16 in. Choke decal (prior to 05/19/03) Lifting handle Choke plate (after 05/19/03) -
Page 15: After 7/21/06
EXHAUST AND AIR INTAKE (AFTER 7/21/06) Page 14 of 18 REF. DESCRIPTION REF. DESCRIPTION Lock washer, internal tooth, 1/4 in. Air intake cover Muffler Lock washer, internal tooth, no. 10 Exhaust adapter Lifting handle Air intake base Engine Muffler bracket Socket hd screw, 5/16-18 x 1-1/2 in. -
Page 16: Pump
PUMP Page 15 of 18 STANDARD FLOTO HIGH PRESSURE FLOTO REF. DESCRIPTION REF. DESCRIPTION Engine Engine Hex hd screw, 3/8-16 x 1-1/2 in. Hex hd screw, 3/8-16 x 1-1/2 in. Self-locking nut, 3/8-16 Self-locking nut, 3/8-16 Plain washer, 3/8 in. Plain washer, 3/8 in. -
Page 17: Engine (Starter And Ignition)
ENGINE - STARTER AND IGNITION Page 16 of 18 REF. DESCRIPTION REF. DESCRIPTION Cylinder cover Hex hd screw, 1/4-20 x 5/8 in. Fan housing Hex nut, 7/16-20 Support plate Starter cup Coil wedge spring Flywheel Coil with sparkie Ground lead Ignition switch Hex slot screw with lockwasher, Starter... -
Page 18: Engine (Carburetor And Power Head)
ENGINE - CARBURETOR AND POWER HEAD Page 17 of 18 REF. DESCRIPTION REF. DESCRIPTION Complete carburetor Reed Carburetor gasket Drive end seal Manifold gasket Crankcase cover gasket Transfer port cover gasket Transfer port cover Carburetor stud Connecting rod screw Spark plug Crankpin roller set (Champion L-86C or AC R44 F) Hex hd screw with lockwasher,... -
Page 19: Warranty
WATEROUS' option: to the replacement at the agreed point of delivery of any product or part, which upon inspection by WATEROUS or its duly authorized representative, is found not to conform to the limited warranty set forth above, or to the repair of such product or part, or to the refund or crediting to buyer of the net sales price of the defective product or part. - Page 20 WATEROUS COMPANY • 125 HARDMAN AVENUE SOUTH SOUTH ST. PAUL, MINNESOTA 55075-2456 U.S.A. Phone: (651) 450-5000 • FAX: (651) 450-5090...
