Waterous CM Series Overhaul Instructions

CM/CMU Series Fire Pumps
Waterous Company 125 Hardman Avenue South, South St. Paul, Minnesota 55075 USA (651) 450-5000
Type of Overhaul
Complete Disassembly of Pump
Replacement of Packing or Mechanical
Seals Without Disassembling the Pump
Removal and Installation of Transfer
Valve
Instructions subject to change without notice.
Overhaul Instructions
Form No. Section
F-1031 4212
Table of Contents
Pump Drive
Transmission Mounted Directly to the Rear
of the Pump
Transmission Mounted Directly to the Front
of the Pump
Direct Drive (The pump is driven by a
remotely mounted transmission or P.T.O.,
the pump is turned by an end yoke on the
impeller shaft.)
Direct Drive or Transmission Mounted
Directly to the Pump
Direct Drive or Transmission Mounted
Directly to the Pump
Visit us at www.waterousco.com
Issue Date Rev. Date
06/30/95 5/11/18
See
Table Page
1 3
2 4
3 5
4 6
5 7
