Introduction

Thank you for purchasing the XCOM 760 VHF Transceiver, this manual describes
the operation and installation of this product, should you have any questions that
are not answered in this manual please contact XCOM Avionics in Australia on
+61 7 5568 7770 or by email to
The XCOM 760 VHF Transceiver is the first of several innovative avionics products
to be released by XCOM Avionics. Based on the very successful Microair and Becker
ranges, the XCOM 760 offers many advanced features previously only available in
the more expensive brands.
Designed from the ground up, the XCOM 760 offers superior performance under the
demanding and noisy conditions experienced in many amateur built aircraft. With
low power consumption, this radio is ideally suited to use in gliders, homebuilts and
ultralights.
A full 6 watt carrier output ensures that you will be heard above the general chatter
in busy airspace and the VOX intercom with muting music input will enhance your
enjoyment of the flight. With expanded receive range up to 163 MHz, the XCOM
760 provides NOAA Weather reception ensuring that you are always aware of
impending weather conditions (NOAA Weather only operates in the USA) and has
an optional MARS/CAP capability.
Additional safety enhancements such as dual watch allow the pilot to listen to the
standby frequency while still monitoring the primary frequency. The XCOM 760 also
has 99 memory channels, large volume and channel selector knobs and well spaced
buttons. This radio is extremely easy to operate even when wearing flight gloves
and you can even check the condition of your battery with the built in voltage
monitor. Even at voltages as low as 10 volts, the XCOM 760 is capable of delivering
2 watts of carrier with full modulation.
Software update capability and Internet downloads mean that you are always
provided with the latest features.

Features Overview

• Digital volume and squelch controls from front panel
• Digital volume and VOX intercom controls from front panel (same Volume
Squelch control, but activated by mode button when required).
• 2 place voice activated intercom, with pilot over ride and passenger isolate
(pax can listen to CD music whilst pilot listens to com). CD music has auto
fade, turns off if comm is receiving or reduces in volume if pilot or pax talk.
• Extra audio input (second com, VOR or GPS alert)
• Remote toggle (toggle active or standby via a push button on the stick, or
scroll memory channels)
Release 1.2
tech@xcom760.com
© XCOM Avionics 2004 www.xcom760.com Page 4
