1
2
3
4
1. Assembled the wooden base to the main body by the supplied screws and washers as the fig.1
above.
2. The speaker net can take out and reassemble as Fig.2 above.
SBI-9015说明书JLE-12239
3
1. Main Body
2. Base
3. Washer
4. Screw
5. Speaker Net
5
Fig.1
INSTALLATION
6. Tweeter
7. Remote Sensor
8. Loud Speakers
9. Woofer
7
6
8
Fig.2
9
3
2012-7-16
17:48:05
