LOCATION OF CONTROLS

1. POWER ON/OFF Switch
2. ANT (Antenna for FM Radio)
3. VIDEO OUT Jack
4. AUX IN 1 (Audio Input )Jacks
5. AUX IN 2 (Audio Input) Jack
6. STANDBY Indicator
7. Standby ON/OFF Button
8. VOL (Volume) - Button
9. VOL (Volume) + Button
10. /TUNE - Button
11. / Button
12. /TUNE + Button
13. SOURCE Button
