Set-up and installation

4 Set-up and installation
WARNING!
Incorrectly erected and installed gas devices may not operate
properly and are dangerous for the health and safety of
individuals.
● The ROTEX GCU compact may only be installed by heating
technicians authorised and trained by gas or energy supply
companies.

4.1 Dimensions and pipe dimensions

A Side view
B Front view
Fig. 4-1 Installation dimensions for flue gas connection on the rear (for values, see tab. 4-1)
A
t
s2
A Side view
B Front view
Fig. 4-2 Installation dimensions for flue gas connection on the side or upwards (for values, see tab. 4-1)
Incorrect set-up and installation would render the manufacturer's
guarantee void. If you have questions, please contact our Tech-
nical Customer Service.
C
B
w
C
Top view
C
s3
r1
Top view
C
s4
r1
C
s4
r1
