- Page 1 307 161-50 2004.xx TA-CMI User Manual...
-
Page 2: Table Of Contents
TA-CMI Contents Contents Guarantee FCC Notification and ETL markings General Unpacking Important information Radio frequency communication Storage recommendations Charging of batteries Keyboard and display Keyboard Symbols Valve setting Starting the instrument Starting the instrument for the first time Normal start of the instrument... -
Page 3: Guarantee
Guarantee General TA-CMI is guaranteed to be free of material or performance defects in normal use and service. The guarantee period is five years, starting from and including the day of delivery. A guarantee period of 180 days applies for repairs and service. -
Page 4: Unpacking
Radio frequency communication Check that these items are delivered. TA-CMI uses radio frequency to communicate wirelessly between the instrument and sensor units. Always turn off radio communication when there is risk that TA-CMI disturbs other vital electronic devices, i.e. near medical equipment... -
Page 5: Keyboard And Display
Valve setting Keyboard This section shows how you set or determine the number of valve turns on a TA valve. (two keys) Functions according to text in display (see picture) The valve’s opening position can be read on the digital handwheel. -
Page 6: Starting The Instrument
1. Start the instrument by pressing the start key 6. Select Functions. The main function menu of for at least 2 seconds. the TA-CMI is displayed. 2. Navigate to the line corresponding to your You select different functions from the main... -
Page 7: Connection To Measuring Points
Connection to measuring points TA-CMI TA-CMI Connection to measuring points Note! The connections with the red markings on the sensor unit and the measuring hose shall Connection to measuring points be connected to the pressure test point with the red marking (the test point with the highest pressure). -
Page 8: Disconnection From Measuring Points
Disconnection from measuring points TA-CMI TA-CMI Disconnection from measuring points Disconnection from measuring points Risk of burn if the media is hot! Always disconnect the measuring needles from the measuring points (1) before disconnecting the bayonet couplings at the measuring hoses and the sensor unit (2 –... -
Page 9: Measure Valve
(or up) key repeatedly, then pressing Enter on the desired valve. If you are measuring on a non TA valve, see section “Entering the valve factor (Kv value) for If you enter an invalid valve setting, e.g. 9 turns for STAF 125, this error other valve types”... - Page 10 Done. 12. Press the calibration button on the sensor unit. Measurement now begins. TA-CMI displays the differential pressure and flow. It is important that the correct media type (e.g. water or glycol) is specified, so that the instrument will display the appropriate flow value.
-
Page 11: Entering The Valve Factor (Kv Value) For Other Valve Types 1
Entering the valve factor (Kv value) for other valve types 6. To enter a name for the valve, select Functions. This section applies only to non TA valves. 1. Select valve type “Other”. 7. Then select Add Valve. 2. Confirm. -
Page 12: Define Media 2
Note! This section is only applicable to TA valve types STAD, STAF and TBV. 6. Enter the appropriate media temperature, by using the up and down keys. Use the right key to move the cursor to the next digit. -
Page 13: Freezing Measurements 2
TA-CMI TA-CMI Measure Valve If the selected valve is any other than TA valve types STAD, STAF or TBV 17. Confirm the entered value. and you try to set the media to anything other than water, this error message is displayed and the media setting is automatically changed to water. -
Page 14: Measure Temperature
Measure Temperature TA-CMI TA-CMI Measure Temperature Measure Temperature 3. Press Enter. 1. Connect the temperature sensor to one of the measuring points on the valve. The actual temperature is displayed. If you try to measure the temperature without having connected the temperature sensor, the value will be displayed as “–... -
Page 15: Handwheel Setting Calculation
Enter. If you want to calculate the valve factor for a non TA valve, see section “Calculation of the 11. Confirm the entered value. valve factor (Kv value) for other valve types” on page 29. Otherwise continue below. -
Page 16: Calculation Of The Valve Factor (Kv Value) For Other Valve Types 2
If an error message is displayed, press OK. Calculation of the valve factor (Kv value) for other valve types This section applies only to non TA valves. The valve factor that corresponds to a given flow and differential pressure will be calculated. -
Page 17: Instrument Setup And Information
Setting the LCD contrast for optimal reading Sleep TA-CMI will go into sleep mode after a period when the keys are not pressed. Here you can set 3. Leave the Instrument Setup menu and save the period from 1 to 10 minutes. If Sleep delay is set to “OFF” the instrument will not go into your settings by pressing Done. -
Page 18: Clearing Faults, Service And Calibration
Ambient humidity (not condensing) ............... max. 90%RH Calibration Sealing A calibration certificate for TA-CMI is issued after the delivery control. The equipment used is traceable to national standards according to ISO 9001 or equivalent. Customers, who want a Class ............................IP 54 regular calibration of the TA-CMI can order that from Tour&Andersson AB. -
Page 19: Accessories
Accessories TA-CMI TA-CMI Accessories TA No Measuring hoses 3 m extension, red with shut off valve 52 197-093 3 m extension, blue 52 197-094 150 mm with twin needle 52 198-801 Chucks Chuck, red for old valves 52 198-802 Chuck, blue for old valves... - Page 20 TA-CMI...
- Page 21 Certification of Registration Number 2125 and 2125 M Certified by SP Sweden Tour & Andersson AB Norra Gubberogatan 32 Box 6281, SE-400 60 Göteborg Tel +46 31 338 73 30 Fax +46 31 338 73 49 www.tourandersson.com...
