Xpass S2
Intelligent IP Access Control Reader
Installation Guide
EN 101.00.XPS2 V1.11
www.supremainc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Xpass S2 and is the answer not in the manual?

Questions and answers

Related Manuals for suprema Xpass S2

Summary of Contents for suprema Xpass S2

  • Page 1 Xpass S2 Intelligent IP Access Control Reader Installation Guide EN 101.00.XPS2 V1.11 www.supremainc.com...
  • Page 2 (especially CRT), TV screens and speakers.  Use a separate power supply for Secure I/O 2, electric lock and Xpass S2 respectively. If connecting and using the power supply to these devices together, the devices may malfunction.

  • Page 3: Table Of Contents

    Reset Network Settings Product Dimension Cables and Connectors Power Connection LAN Connection RS485 Connection Relay Connection Digital Input Connection Wiegand Input/Output Installation of Wall-mount Bracket Installation of Extended Bracket Installation Reference Specification Electrical Specification FCC Rules ‹#› ⒸCopyright 2007 Suprema Inc.

  • Page 4: Product Components

    Xpass S2 Product Components Basic Components  Xpass S2 Wall Bracket Wall Mounting Screws Screw Anchors Shrinkable Tubes Software CD Diode (2 ea) (2 ea) (1 ea) ⒸCopyright 2007 Suprema Inc.

  • Page 5: Optional Accessories

    Xpass S2 Optional Accessories Extended Bracket 12VDC Adaptor Secure I/O Plastic Stand ⒸCopyright 2007 Suprema Inc.

  • Page 6: Name Of Each Part

    Xpass S2 Name of Each Part ⒸCopyright 2007 Suprema Inc.

  • Page 7: Led Status

    Security Status blinking by every 2 seconds. Terminal is used or received a packet to get IP address when Yellow LED is blinking shortly. terminal is set as Use in the Idle status or TCP/IP Setting ⒸCopyright 2007 Suprema Inc.

  • Page 8: Reset Network Settings

    Reset Network Settings When you install the Xpass S2 or forget the network setting’s value of Xpass S2 in use, can initial the network setting’s value (TCP/IP address, RS-485 setting) in the switch of Xpass S2’s back side as follows;...

  • Page 9: Product Dimension

    Xpass S2 Product Dimension (unit: mm) < Front View > < Side View > < Wall Bracket > < Extended bracket > ⒸCopyright 2007 Suprema Inc.

  • Page 10: Cables And Connectors

    ETH TXP (LAN) ENET RXN ETH RXN (LAN) ENET RXP ETH RXP (LAN) PWR GND Power Ground RLY NO Relay Normal Open RLY COM Relay Common RLY NC Relay Normal Close PWR +VDC Power In 1011121314 161718 ⒸCopyright 2007 Suprema Inc.

  • Page 11: Power Connection

    • Comply with standard IEC/EN 60950-1. • Use a separate power supply for Secure I/O, electric lock and Xpass S2 respectively. If connecting and using the power supply to these devices together, the devices may malfunction. ⒸCopyright 2007 Suprema Inc.

  • Page 12: Lan Connection

    Xpass S2 LAN Connection Ethernet Connection (Connection with HUB)  The device can be connected to a network using a regular Ethernet hub. ⒸCopyright 2007 Suprema Inc.
  • Page 13 Xpass S2 LAN Connection (Direct connection with PC) Ethernet Connection (Direct connection with PC)  Use a standard CAT-5 cable to connect the device directly to a PC. ⒸCopyright 2007 Suprema Inc.

  • Page 14: Rs485 Connection

    Adjust the communication speed as needed. The signal quality vary depending on wiring conditions, and it may be necessary to lower the Baud rate. The GND signal may be omitted if and only if the GND potential difference is less than ±5V. − ⒸCopyright 2007 Suprema Inc.
  • Page 15 RS485 Connection for Secure I/O Pin Name Color 485 TRXP Blue (White Stripe) 485 TRXN Yellow (Black Stripe) 485 GND White (Black Stripe) Max number of devices Maximum eight (8) devices (including Master) interworks in an RS485 loop. ⒸCopyright 2007 Suprema Inc.

  • Page 16: Relay Connection

    Make sure to install the diode near to the door lock. Make sure to use different power supplies for the Xpass S2 and the door lock. Make sure to install the diode at both ends of the circuit as shown in the figure left in order to protect the relay contact from the reverse current that occurs when the door lock works.
  • Page 17 Make sure to install the diode near to the door lock. Make sure to use different power supplies for the Xpass S2 and the door lock. Make sure to install the diode at both ends of the circuit as shown in the figure left in order to protect the relay contact from the reverse current that occurs when the door lock works.
  • Page 18 Xpass S2 Relay Connection – Automatic Door Pin Name Color RLY NO Gray (White Stripe) RLY COM Green (White Stripe) Xpass S2 ⒸCopyright 2007 Suprema Inc.

  • Page 19: Digital Input Connection

    Xpass S2 Digital Input Connection (Alarm, Emergency S/W) Pin Name Color TTL IN1 Brown TTL GND Gray TTL IN0 Purple Xpass S2 ⒸCopyright 2007 Suprema Inc.
  • Page 20 Xpass S2 Digital Input Connection (RTE, Door Sensor) Pin Name Color TTL IN1 Brown TTL GND Gray TTL IN0 Purple Xpass S2 ⒸCopyright 2007 Suprema Inc.

  • Page 21: Wiegand Input/Output

    Wiegand Input/Output Wiegand Input Pin Name Color  WG D0 Green WG D1 White WG GND Black Xpass S2 Wiegand Output Pin Name Color  WG D0 Green WG D1 White WG GND Black Xpass S2 ⒸCopyright 2007 Suprema Inc.

  • Page 22: Installation Of Wall-Mount Bracket

    Xpass S2 Installation of Wall-mount Bracket Fix wall mount bracket on a wall Hook Xpass S2 on the wall mount bracket   using wall mounting screws Fix Xpass S2 to the wall mounting bracket  using a wall mounting screw...

  • Page 23: Installation Of Extended Bracket

    Assemble the extended bracket Mount the extended bracket to the   using screws desired location using screws Fix Xpass S2 and the extended Hook Xpass S2 on the extended bracket   bracket using screws ⒸCopyright 2007 Suprema Inc.

  • Page 24: Installation Reference

    Xpass S2 Installation Reference 1 - Standalone Xpass S2 ⒸCopyright 2007 Suprema Inc.
  • Page 25 Xpass S2 Installation Reference 2 – Standalone (Secure) Xpass S2 ⒸCopyright 2007 Suprema Inc.
  • Page 26 Xpass S2 Installation Reference 3 – Network ⒸCopyright 2007 Suprema Inc.

  • Page 27: Specification

    Power 12VDC Operating Temperature -35°C to 65°C Xpass S2 80 x 120 x 11.4mm (W x H x D) Dimensions Wall Bracket 68.4 x 110.4mm (W x H) Certificates CE, FCC, KC, IP65, RoHS, REACH, WEEE ⒸCopyright 2007 Suprema Inc.

  • Page 28: Electrical Specification

    Xpass S2 Electrical Specification Min. Avg. Max. Notes Power Voltage (V) Use regulated DC power adaptor only Current Consumption (mA) Switch Input VIN_MAX (V) Relay Voltage 24 VDC Current 0.5 A 1.0 A ⒸCopyright 2007 Suprema Inc.

  • Page 29: Fcc Rules

    2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit difference from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help ⒸCopyright 2007 Suprema Inc.
  • Page 30 ㈜슈프리마 경기도 성남시 분당구 정자동 파크뷰 오피스타워 16층 Tel : 031-783-4510 Fax : 031-783-4503 온라인고객지원 : sales@suprema.co.kr 회사홈페이지 : www.suprema.co.kr 제품홈페이지 : www.biostation.co.kr BioEntry Plus의 기능 및 사양은 제품의 품질 향상이나 기능 수정 등으로 인해 예고 없이 변경될 수 있습니다.
