- Page 1 WEBtec-4X Suprema Internet Access Control System with Proximity Card / Key Tag / Bracelet Entry Product Overview & Installation Instructions WEBtec-4X Suprema Internet Access Control System Keyless Entry Locks For current prices, please visit our website. www.KeylessEntryLocks.com 46 Danada Sq West #4133...
-
Page 2: Table Of Contents
WEBtec-4X Suprema Internet Access Control System Section: Table of Contents WEBtec-4X Suprema Internet Access Control System Table of Contents Table of Contents........................2 Product Overview........................4 Features............................4 Options.............................. 4 PC Software..............................4 Secure I/O..............................5 Complete Door Hardware..........................5 Specifications............................ 5 Quick Guide..........................6... - Page 3 WEBtec-4X Suprema Internet Access Control System Section: Table of Contents Weigand Input/Output........................27 Output............................. 28 Wall Mount Bracket......................... 29 Installation Reference......................30 Stand Alone............................. 30 Stand Alone (Secure)........................31 Network............................32 Electrical Specifications......................33 FCC Rules..........................34 Warranty Information......................35 Contact Information........................35 The Keyless Locks Store For current prices, please visit our website.
-
Page 4: Product Overview
Featuring next generation IP access control system structure, the WEBtec-4X Suprema acts as a smart reader and controller with distributed intelligence concept. With its RS485 and Wiegand interfaces, it can also fit in your legacy systems. -
Page 5: Secure I/O
The Secure I/O is a separate controller for door control and I/O expansion. With encrypted communication, it provides a secure and cost effective access control system. It is easy to install and can be used with Suprema Products, such as the BioStation, BioLite Net and the BioEntry Plus. Secure I/O Complete Door Hardware One-Stop-Shop for complete door hardware solutions. -
Page 6: Quick Guide
WEBtec-4X Suprema Internet Access Control System Section: Quick Guide Quick Guide The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189 Page 6 of 35 FAX: (630) 447-3635 orders@KeylessLocksStore.com... - Page 7 WEBtec-4X Suprema Internet Access Control System Section: Quick Guide The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189 Page 7 of 35 FAX: (630) 447-3635 orders@KeylessLocksStore.com...
- Page 8 WEBtec-4X Suprema Internet Access Control System Section: Quick Guide The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189 Page 8 of 35 FAX: (630) 447-3635 orders@KeylessLocksStore.com...
-
Page 9: Safety Precautions
WEBtec-4X Suprema Internet Access Control System Section: Safety Precautions Safety Precautions The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189 Page 9 of 35 FAX: (630) 447-3635 orders@KeylessLocksStore.com... -
Page 10: Installation Instructions
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Installation Instructions Basic Components Extended Ethernet Cable Main Body Bracket Software CD Shrinkable Knife Blocks Tubes Wall (2 each) Mounting Screws (2 each) The Keyless Locks Store For current prices, please visit our website. -
Page 11: Optional Components
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Optional Components Secure I/O Plastic Stand Adapter Extended Bracket The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189... -
Page 12: Parts Name/Descriptions
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Parts Name/Descriptions The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189 Page 12 of 35 FAX: (630) 447-3635 orders@KeylessLocksStore.com... - Page 13 WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189 Page 13 of 35 FAX: (630) 447-3635 orders@KeylessLocksStore.com...
-
Page 14: Product Dimensions
(not to scale) Initialization of Network Setting When you install the Suprema or forget the network setting's value of Suprema in use, can initial the network setting's value (TCP/IP address, RS-485 setting) in the switch of Suprema's back side as follows: 1. -
Page 15: Cables & Connections
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Cables & Connections (See table on the next page) The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189... - Page 16 WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions (See picture from the previous page) Pin Name Full Name Color 485 GND 485 GND White (black string) WGD GND Wiegand - GND Black 485 - 485 - Yellow (black string)
-
Page 17: Cable Specification
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Cable Specification Cable Pin Name Color RLY NC Orange (black string) Relay RLY COM Green (white string) RLY NO Gray (white string) WGD D0 Green Weigand WGD D1 White WGD GND... -
Page 18: Lan Cable
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions LAN Cable LAN Connector Pin Name Color Yellow Blue Orange Pink Green (black string) Green (black string) Brown (white string) Brown (white string) Ethernet Extension Cable Modular Jack (A) Connector (B) -
Page 19: Power Connection 1
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Power Connection 1 Pin Name Color PWR IN+ PWR IN- Black (white string) Recommended Power Supply: 12V ±10%, at least 1500mA. Comply with standard IEC/EN 60950-1. To share the power with other devices, use a power supply with higher current ratings. -
Page 20: Power Connection 2
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Power Connection 2 Please read below carefully before you install this product. This is essential steps for stable operation. Please make sure to turn on the power of PSE only after connect all cables related to PoE. -
Page 21: Lan Connection
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions LAN Connection LAN Connection with PC The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189 Page 21 of 35 FAX: (630) 447-3635 orders@KeylessLocksStore.com... -
Page 22: Rs485 Connection For Host Communication
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions RS485 Connection for Host Communication Pin Name Color 485 GND White (black string) 485 - Yellow (black string) 485 + Blue (white string) RS485 Connection for Host Communication (option 2) Pin Name... -
Page 23: Relay Connection - Fail Safe Lock
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Relay Connection – Fail Safe Lock Pin Name Color RLY COM Green (white string) RLY NC Orange (black string) Relay Connection – Fail Secure Lock Pin Name Color RLY NO Gray (white string) -
Page 24: Relay Connection - Automatic Door
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Relay Connection – Automatic Door Pin Name Color RLY NO Gray (white string) RLY COM Green (white string) The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133... -
Page 25: Digital Input Connection (Alarm, Emergency S/W)
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Digital Input Connection (Alarm, Emergency S/W) Pin Name Color IN 1 Brown IN GND Gray IN 0 Purple The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133... -
Page 26: Digital Input Connection (Rte, Door Sensor)
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Digital Input Connection (RTE, Door Sensor) Pin Name Color IN 1 Brown IN GND Gray IN 0 Purple The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133... -
Page 27: Weigand Input/Output
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Weigand Input/Output Wiegand Input: Pin Name Color WGD GND Black WGD D1 White WGD D0 Green Wiegand Output: Pin Name Color WGD GND Black WGD D1 White WGD D0 Green The Keyless Locks Store For current prices, please visit our website. -
Page 28: Output
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Output Pin Name Color RLY COM Green (white string) RLY NC Orange (black string) PWR OUT + Light Blue PWR OUT - Black (white string) Caution: Max. 700mA is supplied using adapter for the external output. -
Page 29: Wall Mount Bracket
WEBtec-4X Suprema Internet Access Control System Section: Installation Instructions Wall Mount Bracket 1. Fix mount bracket on a wall using wall mounting screws. 2. Hook Suprema body on the wall mount bracket. 3. Fix Suprema body and wall mounting bracket using a wall mounting screw. -
Page 30: Installation Reference
WEBtec-4X Suprema Internet Access Control System Section: Installation Reference Installation Reference Stand Alone The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189 Page 30 of 35 FAX: (630) 447-3635 orders@KeylessLocksStore.com... -
Page 31: Stand Alone (Secure)
WEBtec-4X Suprema Internet Access Control System Section: Installation Reference Stand Alone (Secure) The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189 Page 31 of 35 FAX: (630) 447-3635 orders@KeylessLocksStore.com... -
Page 32: Network
WEBtec-4X Suprema Internet Access Control System Section: Installation Reference Network The Keyless Locks Store For current prices, please visit our website. www.KeylessLocksStore.com 46 Danada Sq West #4133 Phone: (630) 909-9504 Wheaton, IL 60189 Page 32 of 35 FAX: (630) 447-3635 orders@KeylessLocksStore.com... -
Page 33: Electrical Specifications
WEBtec-4X Suprema Internet Access Control System Section: Electrical Specifications Electrical Specifications Min. Typ. Max. Notes Power Voltage (V) 10.8 13.2 Use regulated DC power adapter only. Current (mA) Switch Input VIH (V) VIL (V) Ω) 4.7k The input ports are pulled up with 4.7k resistors. -
Page 34: Fcc Rules
WEBtec-4X Suprema Internet Access Control System Section: FCC Rules FCC Rules Caution Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment. Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interface, and (2) this device must accept any interface received, including interference that may cause undesired operation. -
Page 35: Warranty Information
WEBtec-4X Suprema Internet Access Control System Section: Warranty Information Warranty Information ACTAtek provides a one year warranty on most products, with extended warranty available for purchase (24 and 36 months) from ACTAtek and authorized dealers. An extended warranty is offered on hardware only or on both hardware and software. With the hardware and software warranty, customers have access to software updates and upgrades.
