HARDWARE IDENTIFICATION CHART

25 1/4-20 X 1-1/4in Bolt - Qty 2
1/4-20 X 1 1/2in Bolt - Qty 6
26
1/4-20 x 2-1/2in Bolt - Qty 2
27
28 1/4-20 x 3in Bolt - Qty 12
5/16 x 18 x 2-1/4in Bolt - Qty 6
29
5/16-18 x 2-1/2in Bolt - Qty 6
30
5/16 x 18 x 3-1/4in Bolt - Qty 6
31

TOOLS NEEDED

2 - 1/2" Wrenches
Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5
Bolts shown are for size reference.
Extra hardware may be included in the parts bag.
38
M6 Yellow Washer M8 Yellow Washer
Qty 6 Qty 8
34
1/4in Flange
Locknut Qty 22
40
Silent Knob
Qty 14
2 - 7/16" Wrenches
LOCKDOWN 21 2-MAN Ladder Stand
39
35
5/16in Locknut
Qty 18
32
1/4-20 x
1-3/4in
Wing
Screw
Qty 1
