Warmington Nouveau Maintenance And Operating Manual

Outdoor nouveau cooking fires
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
16 October 2014
Warmington Outdoor Nouveau Cooking Fires
Maintenance &

Operating Instructions

How to light and maintain an outdoor cooking fire.
Please 'Keep these instructions for future reference'
Manufactured by Warmington Industries, 47 Sir William Ave, East Tamaki, Auckland.
P O Box, 58 652, Botany 2163.
Telephone: 09 273 9227 Fax: 09 271 0892 email: www.warmington.co.nz
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nouveau and is the answer not in the manual?

Questions and answers

Related Manuals for Warmington Nouveau

Summary of Contents for Warmington Nouveau

  • Page 1: Operating Instructions

    How to light and maintain an outdoor cooking fire. Please ‘Keep these instructions for future reference’ Manufactured by Warmington Industries, 47 Sir William Ave, East Tamaki, Auckland. P O Box, 58 652, Botany 2163. Telephone: 09 273 9227 Fax: 09 271 0892 email: www.warmington.co.nz...
  • Page 2 . Ensure that the cavity is vented to Outside fresh Air and the Warmington will take care of the rest. 2 x 100mm Diameter vent are required (Or equivalent to that.) “Warmington’s CAITEC” room replacement air (for internal fires only)

  • Page 3: Lighting The Fire

    16 October 2014 Burn Control and Operation of your Warmington Fire LIGHTING THE FIRE To start and maintain a good fire, you need the following:  Newspaper (not coloured or coated).  Box of Matches  Packet of firelighters (optional) ...
  • Page 4 16 October 2014 FOR CORRECT OPERATION OF YOUR OUTDOOR WOOD FIRE—Follow These Guidelines These are guidelines only—each Installation will operate with it’s unique aspects: Place generous amount of crumpled newspaper in the Firebox. Place 10-15 pieces of finely split, dry kindling on top and behind the paper, say 20cms.

  • Page 5: Fuel Loads

     Most firewood will spit sparks from time to time. It is strongly recommended you use a sparkguard. NEVER leave a lit fire unattended. Warmington have a range of sparkguards, either fitted or freestanding for safety and peace of mind.

  • Page 6: Fitting Of Accessories

    16 October 2014 FITTING OF ACCESSORIES WEATHER SHIELD: (comes with the fire) Removal of shield: Twist the two handles to release the top of the shield. Taking hold of the handles, pull the top of the shield towards you. The shield will now be sitting on two clips which are hooked over the bottom rail. Lift the shield up to clear the bottom rail and remove the shield.
  • Page 7 16 October 2014 PIZZA OVEN INSTRUCTIONS IMPORTANT: Your new wood fired oven needs curing before you start using it for the first time! Access to the Pizza Oven:  Insert the Pizza door handle into the slot and turn to release the door—diagram 1 below. ...
  • Page 8 16 October 2014 DAVIT: (Optional Extra POA) The use of the davit is to allow a pot to be swung in over the ember bed for boiling water or cooking in. The Height of the Davit can be set by the pin in the side of the rod on the left or right of the fire.
  • Page 9 16 October 2014 HELL ROTISSERIE 240 volt powered: (Optional Extra POA) This is a 240 Volt powered and operated unit and is mounted on a rack at the left and right hand sides of the fire. A Stainless steel Drip tray catches the juices and fat from the rotisserie and also allows the operator to carry the rotisserie to and from the main fire.

  • Page 10: Troubleshooting

    The fire will be performing poorly as the fire will not heat up and circulate the convection air.  Cowls : A different style of cowl may make a difference in some situations, but seek the advice of a Warmington Agent as some cowls are not suitable for some applications.

  • Page 11: Important Notes

    The installation and construction of the flue system must comply with ASNZS 2918. The Warmington Open fires requires a Warmington Tested and approved flue system only, as tested to ASNZS 2918. The tested flue system should not be modified in any way without the written approval of the manufacturer .Any additional flue components to the flue system must comply with ASNZS 2918.

  • Page 12: Installation

    Not included in warranty: (List of Warmington Genuine Replacement Parts) Racks, grills and plates Ash Pan Bricks Total Flue System Paint (Stovebright) Accessories Replacement fire back Installation The Warmington unit is to be installed by a certified Warmington installer or an Approved NZHHA Installation Technician.

  • Page 13: Warranty

    (30) days from the date of purchase of the product. Except as set forth herein, Warmington Industries ’94 Ltd makes no warranty, express or implied as to the merchantability of the product or the fitness of the product for a particular purpose.
