F A L C O N
WORLD CLASS SE CURITY
FALCON PHASER2
Advanced Keyless Entry System
NATIONWIDE INSTALLATION SERVICE
0800 622 474
HELPLINE: 0906 700 10 20
(All calls charged at 50p/min)
Internet: http://www.falcon-security.com
Email: support@falcon-security.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PHASER2 and is the answer not in the manual?

Questions and answers

Related Manuals for Falcon PHASER2

Summary of Contents for Falcon PHASER2

  • Page 1 F A L C O N WORLD CLASS SE CURITY FALCON PHASER2 Advanced Keyless Entry System NATIONWIDE INSTALLATION SERVICE 0800 622 474 HELPLINE: 0906 700 10 20 (All calls charged at 50p/min) Internet: http://www.falcon-security.com Email: support@falcon-security.com...
  • Page 2 1. Features Remote lock and unlock Car finder Total closure Remote boot release Code learning (up to 4 remotes) Flashes hazard lights Universal Central Locking Siren/horn output 2. Button Function Table button door lock door unlock ignition on button #1 once lock lock lock...
  • Page 3 - Lights flash once then stay on again to confirm the 1 remote is programmed to the system - Follow the same procedure as above to program the 2 remote. You have up to 10 sec. for the learning of each remote The system will quit the learning mode as follows and the indicator lights will turn off to confirm:...
  • Page 4 4.02 Door unlock - Press the unlock button once - Doors unlock - Lights flash twice - The siren/horn chirps twice (if connected) 4.03 Boot release - Press the boot release button (#) for 2 sec. will operate the boot release output.
  • Page 5 4.06 Wiring diagram - C1-1 and C1-3 White -> Lights flash outputs[+] Connect C1-1 and C1-3 to indicator lights. - C1-2 White/Red -> Polarity input for C1-1 & C1-3[+ or -] Connect C1-2 to positive or negative depending on the polarity of the cars indicator wires.
  • Page 6 - C1-6 Brown -> Siren/Horn output [1A] Connect the red (+) wire of an optional siren for confirmation chirps. An additional relay will be required when connecting this output to the car horn instead of a siren; see the wiring below: - C1-7 Yellow <- Ignition input [+] Connect to an ignition wire that shows +12V when the key is in both [on] and [start] positions...
  • Page 7 4.07 Lock & unlock wiring...
