LECTRIC 2-C & 4-C

FLUSH CEILING MOUNT WITH SERVICE DOOR
SELF-SUPPORTED (shown) and TAB-TENSIONED screens
Figure 1

SCREEN TYPE

LENGTH
DIM. A
SELF-SUPPORTED
VIEWING WIDTH + 15 1/2
7 3/4
TAB-TENSIONED
VIEWING WIDTH + 22 1/2
11 1/4
VUTEC CORPORATION
www.vutec.com
2
TEL: (954)-545-9006
FAX: (954)-545-9011
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
EMAIL: info@vutec.com
