8 - Approvals
Maximum Constructional Flamepath Gaps
Flamepath
Electrical Cover / Back Housing
Terminal Cover / Back Housing
ATEX / IECEx
Terminal Cover / Back Housing for FM & CSA
Transfer Loom Bush for FM & CSA
Transfer Loom Bush Flamepath
ATEX / IEC / CSA / Certified RHS
SPECIAL CONDITIONS
This Remote Hand Station must only be located in areas
where the risk of impact to the viewing window is low.
This equipment includes some exterior non-metallic paints
including the protective coating. To avoid the possibility of
static build up, cleaning must only be carried out with a water
dampened cloth.
For CAN / CSA C22.2 No. 61010-1-12 compliance the RHS
must be connected to an IQ3 or IQT3 actuator.
THREAD DETAILS FOR ATEX AND IECEx APPROVAL
Threaded
Thread
Flamepath
Size
Cable Entry
M25x1.5
EXTERNAL ENCLOSURE FASTENERS
Enclosure fasteners are stainless steel grade A4-80 M8 for the
main display cover and 12.9 M5 for the terminal cover.
12
Max. Gap
Min. Length
(mm)
(mm)
0.15
26.00
0.15
12.50
0.115
12.50
0.115
25.00
0.15
25.00
Thread
Equipment Type
Length
20.00
All Types and Sizes
Equipment Type
All Types and Sizes
RHS
RHS
RHS
RHS
Vibration, Shock and Noise
Standard IQ remote hand stations are suitable for applications
where vibration and shock severity does not exceed the
following:
Type
Level
Plant induced
1g rms total for all vibration within the frequency
vibration
range of 10 to 1000 Hz
Shock
5g peak acceleration
2g acceleration over a frequency range of 1 to
Seismic
50 Hz if it is to operate during and after the event
Independent tests have shown that at 1m
Emitted noise
generated noise does not exceed 65 db(A)
