U l t r a s o n i c s e n s o r s
Instruction manual Trans-O-Prox III
The content of this document is subject to technical changes. Specifications in this document are presented in a descriptive way
only. They do not warrant any product features.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Trans-O-Prox III and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microsonic Trans-O-Prox III

Summary of Contents for Microsonic Trans-O-Prox III

  • Page 1 U l t r a s o n i c s e n s o r s Instruction manual Trans-O-Prox III The content of this document is subject to technical changes. Specifications in this document are presented in a descriptive way...

  • Page 2: Table Of Contents

    FR - freeze switching state 2.3.2.24 VS - software version no. 2.3.2.25 DT - software validation date 2.3.2.26 NR - serial number of the Trans-O-Prox III 2.3.2.27 RS - system reset (cold boot) 2.3.2.28 QU - return from programming to normal operation 2.3.2.29 IS - disabling / enabling of signal inputs 2.3.2.30...

  • Page 3: Summary

    (three types suited for use with Trans-O-Prox III: wms-251/RT, wms-501/RT and wms-800/RT , a mixed operation of both sensor types is allowed). Therefore four groups of terminal blocks for connecting the sensors can be found on Trans-O-Prox III ( sensor power supply + , GND, sender, echo).

  • Page 4: Transponder Mode

    RS232 with each measurement cycle to a host computer. The echo mode is selected, when Trans-O-Prox III has been activated and when there is a GND signal on MODE or when it is left open (unconnected). The echo mode can also be selected by a command via the serial interface.

  • Page 5: Programming Mode

    2.3.1 Manual programming During normal operation (Trans-O-Prox III activated) the switching distances (trip points) of the currently active mode (echo or transponder) can be adjusted by the buttons on the front panel. To enter manual programming press the ENTER button for 3 sec, until both yellow LEDs A1 and A2 start to blink.

  • Page 6: Command Set

    Manual Trans-O-Prox III page 28 of 42 must be terminated by a <cr> (carriage return, ASCII code 13 If the command is directly followed by a <cr>, the current parameters associated with this command will be output. Entering a parameter value after a command overwrites the pre- viously valid parameters, if parameters are entered in the correct format.

  • Page 7: Sp - Choice Of Used Language

    By the SA command the permanent inner switching distances (near trip points) are selected for the echo mode. SA<cr> subsequently outputs all trip points of sensor channels 1 to 4 (channel 4 is irrelevant for Trans-O-Prox III however, see chap. 3 ). Command format: SAx:y , x = channel no.

  • Page 8: Ta - Temporary Inner Switching Distance For Echo Mode

    Manual Trans-O-Prox III page 30 of 42 switching distance too low , decrease near switching distance first´ appears. The SB command stores the distances values within a non volatile memory (EEPROM), so that switching distances are memorized, when switching off the power supply.

  • Page 9: Hb - Hysteresis Of Switching Output A2 For Echo Mode

    Manual Trans-O-Prox III page 31 of 42 2.3.2.8 HB - hysteresis of switching output A2 for echo mode A switching hysteresis of output A2 for the far trip distance may be specified by the HB command, valid for the echo mode. Allowed values are 0 to 15 (equivalent 0 to 30 cm). If the approach of an object has led to a switching, the output will not be reset until the object distance has gone above TB + HB again.

  • Page 10: Yb - Temporary Outer Switching Distance For Transponder Mode

    Manual Trans-O-Prox III page 32 of 42 ,y = distance value 2.3.2.12 YB - temporary outer switching distance for transponder mode If during normal operation the outer switching distance for transponder mode is altered very frequently, one should better use the YB command instead of the XB command. YB changes the outer switching distance only temporarily without storing it in the EEPROM.

  • Page 11: Si - Transmitted Pulse Length

    , x = 1 variable transmitted pulse length depending on measured distance 2.3.2.17 MD - Selection of pure echo mode By the MD command can be determined, whether the Trans-O-Prox III should operate in a pure echo mode on all four channels, or if it should also have the transponder function with channel 4 being the active reflector.

  • Page 12: Ph - Peakhold Of Switching Outputs

    Manual Trans-O-Prox III page 34 of 42 2.3.2.20 PH - peakhold of switching outputs If an object approach has led to a switching of output A1 or A2, the on-state of the switch- ing output is maintained for a specified number of measurement cycles given by PH, after the switching criteria has vanished, i.e.

  • Page 13: Dt - Software Validation Date

    The DT command outputs the software validation date. 2.3.2.26 NR - serial number of the Trans-O-Prox III Every Trans-O-Prox III is identified by a serial number, when can be called by the NR com- mand. 2.3.2.27 RS - system reset (cold boot) A software cold boot is performed as if there were a reset impulse, when switching on the power supply.

  • Page 14: It - Logical Signal State, When Signal Input Disabled

    Manual Trans-O-Prox III page 36 of 42 2.3.2.30 IT - logical signal state, when signal input disabled If a signal input has been disabled by the IS command, the logical state must be specified by the IT command. After a reset the value for IT is undefined.

  • Page 15: Pc - Choice Of Data Protocol

    Manual Trans-O-Prox III page 37 of 42 501/RT can be used. Command format: TYwxyz ,w = channel 4 ... z = channel 1 Parameter 0 = wms-251/RT or wms-501/RT, 1 = wms-800/RT Example: TY1001, wms-800/RT at channel 4 und 1, wms-251/RT at channel 3 and 2.

  • Page 16: Ec - End Characters For Text Transmission

    Manual Trans-O-Prox III page 38 of 42 to a worse reaction time of Trans-O-Prox III; safe value for all protocols without affecting the reaction: 9600 Baud+. To enter programming mode when it is unknown, which baud rate has been selected previously by BD, fixed baud rates can be forced by keeping the UP or DOWN button pressed, while switching on the power supply.

  • Page 17: Further Informations

    XOFF (ASCII code 19dec). 3. Further informations Using the MD command Trans-O-Prox III can be adjusted in a way, that it operates in a pure echo mode. There is no transponder mode in this case; the function as active reflector on channel no.4 is void.
  • Page 18 Manual Trans-O-Prox III page 40 of 42 ZA: hysteresis near switching distance ZB: hysteresis far switching distance In transponder mode all values of sensor on channel no.1 *5 cm H06: Distances in echo mode: SA: near switching distance (EEPROM) SB: far switching distance (EEPROM)
  • Page 19 Manual Trans-O-Prox III page 41 of 42 disabled the logical input status set by the IL command is valid. Example: IS100: external input on EXT signal, MODE & ENABLE inputs disabled IT: sets logical states of EXT, MODE & ENABLE, when correspondent external inputs are disabled (by IS), 1 equals a high level, 0 equals a low level.

  • Page 20: Front Panel And Sensor Connector

    Manual Trans-O-Prox III page 42 of 42 5. Front panel and sensor connector + Tacho - Tacho Mode Output A2 RS232 RS232 Enable Ext. Output A1 RS232 Echo- Transp.- -Mode Prog Trans-O-Prox Enter Sender Echo Sender Echo Sender Echo Sender...
