Kramer PA-120Z Quick Start Manual

PA-120Z / PA-240Z Quick Start Guide
This guide helps you install and use your PA-120Z / PA-240Z for the first time.
Go to
upgrades are available.
Scan for full manual
Step 1: Check what's in the box
PA-120Z / PA-240Z 120W / 240W Power Amplifier
1 Power cord
Step 2: Get to know your PA-120Z / PA-240Z
# Feature
1 ON LED
2 INPUT 1 LED
3 INPUT 2 LED
4 MUTE
5 CLIP LED
6 PROTECT LED
PA-120Z / PA-240Z Quick Start (P/N: 2900-300802QS REV 2)
www.kramerav.com/downloads/PA-240Z
Function
Lights green when powered on, orange when in standby.
Lights green when a signal is present on input 1.
Lights green when a signal is present on input 2.
Lights red when the output is muted, off when unmuted.
Lights red when the signal is clipped on the output and creating distortion.
(When clipping is detected, lower the volume until the LED turns off.)
Lights red in case of over current / short / over heat.
The device powers down until operation conditions are corrected and then powers up again.
to download the latest user manual and check if firmware
4 Rubber feet
1 Quick start guide
P/N: 2 9 0 0 - 3 0 0 8 0 2 QS Rev: 2
