Symbology On The Machine; Symbology On The Manual - ADIATEK ruby 50t Use And Maintenance

Symbol denoting the solution valve.
Indicates the solution valve lever.
Symbol denoting the suction motor.
Indicates the switch of the suction motor.
Symbol denoting up – down of the squeegee.
Indicates the squeegee lever.
Indication of the maximum temperature of the
solution detergent.
It is placed near the charging hole of the
solution tank.
Symbol denoting the brush release.
Indicates the push button used to release
automatically the brush.
Symbol denoting the open book.
Indicates that the operator has to read the
manual before the use of the machine.
Symbol denoting the open book.
For the good functioning of the on-board
battery charger (optional), read the manual of
the constructor.
Warning symbol.
Read carefully the sections marked with this
symbol, for the security of both the operator
and the machine.
Symbol that indicates the obligations of
disconnecting the system from the batteries by
disconnecting the connector before operating
on the machine.

SYMBOLOGY ON THE MACHINE

SYMBOLOGY ON THE MANUAL

6
Symbol denoting the brush.
Indicates the switch of the brushes motor.
Symbol denoting the charge level of the
batteries.
Symbol denoting the hour meter.
Indicates the exhaust hose of the recovery tank.
Symbol denoting switching on.
Indicates the general switch of the machine.
Symbol denoting the crossed bin. Indicates that
at the end of its activity, the machine has to be
disposed conforming to the laws in force.
Symbol that indicates the obligation of wearing
safety glasses.
Symbol that indicates the obligation of wearing
safety gloves.
Symbol that precedes an important information
about the proper use of the machine.
Symbol that indicates operations that have to
be carried out only by qualified personnel.
