- Page 1 45t ruby 50t ruby 50bh ruby 55t 01 2015 Use and maintenance Attention! Please read the instructions before use. COD. 65301008...
- Page 2 TECHNICAL DESCRIPTION ruby 45t ruby 50t ruby 50bh ruby 55t Cleaning width Squeegee width 1800 2000 2000 2200 Working capacity, up to sqft/h 19.375 21.528 21.528 23.681 2x235 1x508 1x508 2x285 Brushes diameter 1x20 1x20 2x11 giri/min Brushes rpm (rpm)
-
Page 3: Table Of Contents
INTRODUCTORY COMMENT Thank you for having chosen our machine. This floor cleaning machine is used for the industrial and civil cleaning and is able to clean any type of floor. During its advance movement, the combined action of the brushes and the detergent solution removes the dirt which is aspirated through the rear suction assembly, giving a perfectly dry surface. -
Page 4: Transfer
GENERAL RULES OF SAFETY − Use only ORIGINAL brushes indicated paragraph “RECOMMENDED BRUSHES". − Do not take off the protections which require the use of tools for The rules below have to be followed carefully in order to avoid injury to the operator and damage to the machine. -
Page 5: Legend Instrument Board And Controls
LEGEND INSTRUMENT BOARD AND CONTROLS DISPLAY CHARGE LEVEL BATTERIES/HOUR METER PUSH BUTTON VISUALIZATION HOUR METER (DISPLAY) SWITCH SUCTION MOTOR SIGNAL LAMP SOLUTION VALVE OPEN/ SWITCH 3S SYSTEM (OPTIONAL) SWITCH BRUSH/ES MOTOR PUSH BUTTON BRUSH RELEASE GENERAL SWITCH (ABSENT IN CASE OF OPTIONAL KEY) LEGEND MACHINE 11. -
Page 6: Symbology On The Machine
SYMBOLOGY ON THE MACHINE Symbol denoting the solution valve. Symbol denoting the brush. Indicates the solution valve lever. Indicates the switch of the brushes motor. Symbol denoting the suction motor. Symbol denoting the charge level of the Indicates the switch of the suction motor. batteries. -
Page 7: Optional Accessories
OPTIONAL ACCESSORIES The optional accessories are: Switch with key (1); Brush/es motor overload protection device (2); 3S – Solution Saving System (3); Solenoid valve (4); Emptying device of the solution tank (5): On-board battery charger (6). -
Page 8: Before Use
BEFORE USE HANDLING OF THE PACKED MACHINE The machine is supplied with suitable packing foreseen for fork lift truck handling. The total weight is 105 kg (231,5 lbs.) Packing dimensions: Base: 118 cm x 67 cm (46.5” x 26.4”) Height: 119 cm (46.8”) Do not place more than 2 packings on top of each other. -
Page 9: Battery Recharger
BATTERY RECHARGER Never charge a GEL battery with a non suitable recharger. Strictly Be sure that the battery recharger is suitable for the installed follow the instructions supplied by the batteries and recharger batteries both for their capacities and type (lead/acid or GEL and manufacturer. -
Page 10: Hour Meter
Acting counterclockwise it is possible to decrease the rubber bending. A label placed near the two registers (5) indicates rotation sense to increase or reduce the height. Note: The wheels of the squeegee support must be adjusted through the registers (5) at the same height so that the squeegee works parallel to the floor. -
Page 11: Brush/Es Assembly
The following figure shows the rotating sense for the brushes coupling with brushes base 45 and 55. BRUSH/ES ASSEMBLY For a longer life of the brushes we suggest to invert daily their position. Whenever brushes were deformed we suggest to reassemble them in the same position, avoiding that the different inclination of the bristles causes excessive motor overload or troublesome vibrations. -
Page 12: Recovery Tank
RECOVERY TANK Check that the cover of the suction filter (1) is correctly secured, after rotating the levers and that the suction motor hose (2) is correctly connected. Verify also that the squeegee hose is correctly inserted into the seats (3 and 4) and that the exhaust hose plug (5) placed in the front part of the machine, is closed. -
Page 13: Starting Of The Machine
STARTING OF THE MACHINE Switch on the machine acting upon the general switch (12). For machines equipped with key switch (see under "OPTIONAL ACCESSORIES”), turn the key (6) clockwise. Press the brushes motor switch (5). Check the battery type and the charge level on the display (1). Press the suction motor switch (3). -
Page 14: Brush/Es Motor Overload Protection Device (Optional)
BRUSH/ES MOTOR OVERLOAD PROTECTION DEVICE (OPTIONAL) If the machine is equipped with the amperemetric protection device (see under "OPTIONAL ACCESSORIES"), this, in case of extended overload of the brush/es motor, intervenes shutting it off. Furthermore, on the display (1) appears an alarm ”AL01”. In case of intervention of this device, check the brush/es pressure adjustment in connection with the type of floor to be cleaned and if necessary, reduce it. -
Page 15: Daily Maintenance
MANUAL DISASSEMBLY OF THE BRUSHES With the brushes base in lifted position, turn the brush in the rotating sense as indicated in the figure, until it is released from the brush holder plate seat. The figure shows the rotating sense for the release. DAILY MAINTENANCE RECOVERY TANK CLEANING Hold the exhaust hose placed in the front part of the machine. -
Page 16: Squeegee Cleaning
SQUEEGEE CLEANING SQUEEGEE HOSE CLEANING Keeping the squeegee clean guarantees always the best drying action. Weekly or in case of insufficient suction, it is necessary to check that For the cleaning it is necessary to: the squeegee hose is not obstructed. Eventually, to clean it, proceed as Take off the squeegee hose (3) from its coupling. -
Page 17: Two-Monthly Maintenance
TWO-MONTHLY MAINTENANCE Slip off the lower part (6) of the squeegee body, so to take off the front rubber (7). FRONT SQUEEGEE RUBBER CHECK Check the wear of the squeegee rubber and eventually replace it. For the replacement it is necessary to: Take off the squeegee hose (3) from its coupling. -
Page 18: Introductory Comment 3 The Motors Do Not Function
THE MOTORS DO NOT FUNCTION If the machine is supplied with the on-board battery recharger (optional), check: if the recharging of the batteries is being carried out. In this case the machine is not connected. that the switches are on. that the general switch (12) is on or that the key switch (see under "OPTIONAL ACCESSORIES”) is in the correct position (clockwise). - Page 19 Brush PPL 0,9 Ø 235 Smooth floors with small joints and persistent dirt. 48801010 Pad holder Ø 230 For pads of 9”, for smooth surfaces cleaning. ruby 50t ruby 50bh 48902010 Brush PPL 0,3 Ø 508 Irregular floors with large joints.
