Summary of Contents for Nice TITAN12L
- Page 1 Gate Opener TITAN12L TITAN12L1 Vehicular Swing Gate Opener The TITAN12L/ TITAN12L1 Gate Operator is intended for use with vehicular swing gates. The TITAN12L/TITAN12L1 Gate Operator can be used in Class I, Class II and Class III applications. Revision 5.1.0.0_6-2017 Part #10001700...
- Page 2 This page intentionally left blank.
-
Page 3: Table Of Contents
FIGURE 5 - 8 Manual release handle 2.5 - General requirements FIGURE 5 - 9 Wire harness insertion FIGURE 5 - 10 TITAN12L/12L1 actuator wiring 5.6 - Control board wiring SAFETY AND CAUTIONS FIGURE 5 - 11 Wiring diagram for 1050 control board 3.1 - Properly installed safety devices... -
Page 4: Cautions And Notes
Swing or slide gate systems are not necessarily from Nice. With a maximum gate capacity of 600 lbs and 20 ft, this completely autonomous systems, and require regular maintenance operator has a key lockable manual release, easily accessible limit and inspection on a periodic schedule. -
Page 5: General Requirements
2.5 - General requirements • Safety and security are obviously a number one priority for both the AUTOMATIC GATES ARE manufacturer and the end user. As a result this manual has been NOT FOR PEDESTRIANS! written to make all persons fully aware of the responsibilities required to ensure constant safety, security and longevity are acquired Automatic gate openers are designed throughout the life of the system. -
Page 6: The Gate System Safety Devices
3.3 - The gate system safety devices • Install keypad controls where users cannot touch, or reach through gate while operating controls, which is a minimum of 8 feet from the Automatic gate operators are designed to move a heavy steel gate. Great gate. - Page 7 Care should be taken to prevent pedestrian usage under any specific to the application in question, with absolute safety in all circumstances. considerations. 4.3.13 One or more non-contact sensors must be used in any situation 4.3.35 Never mount any device that operates the gate opener where the or area where entrapment may have the possibility of occurring.
-
Page 8: Installation Procedures
5 - INSTALLATION PROCEDURES 5.1 - Pivot Arm Installation IMPORTANT - Never weld parts to the gate or posts when the operator circuit board is powered. Doing so may damage the board beyond repair. PULL TO OPEN INSTALLATION - PIVOT ARM INSTALLATION - Location of Pivot Point The following instructions provide up to 105°... -
Page 9: Push To Open Installation
5.2 - Push to open installation PIVOT ARM INSTALLATION - Location of Pivot Point Measurements are taken from the center of pivot of the gate hinge. The pivot arm needs to be securely mounted to the hinge post or equivalent mounting surface. It is recommended to weld the pivot arm to a metal post. -
Page 10: Manual Release/Manual Operation
5.4 - Manual release / manual operation MANUAL RELEASE DISENGAGE 1. Lift rubber key cover and insert key into lock and rotate 90° clockwise. 2. Lift handle 3. Actuator is now Disengaged (manual operation is possible). FIGURE 5-6 MANUAL RELEASE DISENGAGE MANUAL RELEASE RE-ENGAGE 1. -
Page 11: Titan12L/12L1 Actuator Wiring
The connections are on the top of the actuator behind the limit assembly. Terminal block for harness connections FIGURE 5 - 9 WIRE HARNESS INSERTION Connect the wiring to the actuator terminal block as shown. FIGURE 5 - 10 TITAN12L/12L1 ACTUATOR WIRING www.niceforyou.us... -
Page 12: Control Board Wiring
5.6 - Control board wiring 1050 Control Board WHITE ORANGE GREEN BLUE YELLOW PULL TO OPEN BLACK ORANGE WHITE GREEN BLUE YELLOW PUSH TO OPEN BLACK Figure 5 - 11 WIRING DIAGRAM FOR 1050 CONTROL BOARD 936 Control Board Figure 5 - 12 WIRING DIAGRAM FOR 936 CONTROL BOARD PULL TO OPEN PUSH TO OPEN... -
Page 13: Limit Switch Adjustment
5.7 - Limit switch adjustment b. With the 936 control board BEFORE continuing with this section, make sure to i. The LED marked Limit 1 Close (or Limit 2 Close if using motor have the MANUAL for the control board specific to this 2) illuminate red indicating the Close limit is active for a pull to installation in hand. -
Page 14: General Layout And Safety Access
6 - GENERAL LAYOUT AND SAFETY ACCESS Entrapment Protection Inputs - Typical Installation Diagram Utilizing Loop Sensors and Photocells Loop (Safety) Outside Gate 4’ Min. from closed gate 4’ Min. from closed gate Loop (Shadow) Photo 2 Photo 2 4’ Min. from open gate Loop (Safety) Loop (Exit) Figure 6-1 LAYOUT FOR IN-GROUND LOOPS... -
Page 15: Accessories And Sensors
7 - ACCESSORIES AND SENSORS EXTERNAL ENTRAPMENT PROTECTION Non-contact and contact sensors must be installed individually or in combination with each other to provide external entrapment protection. Care should be exercised to reduce the risk of nuisance tripping, such as when a vehicle trips the sensor while the gate is still moving, and one or more non-contact sensors shall be located where the risk of entrapment or obstruction exists, such as the perimeter reachable by a moving gate or barrier. -
Page 16: Inspection And Operation
Ensure proper functionality of all safety devices as specified. Non-functioning or malfunctioning safety devices should be replaced immediately. Contact us Nice Group USA Inc. 12625 Wetmore Road Suite 218 San Antonio, TX 78247 Ph +1.210.545.2900 Fax +1.210.545.2915 www.niceforyou.us...
