Sony KP-FX432M31 Service Manual

Ax-1 chassis, crt projection tv.
Hide thumbs

Advertisement

When clicking an item, it's detail is displayed.
Version
Date
No.
2004.02
1.0
2004.03
2.0
2004.12
3.0
HISTORY
Serial
No.
NEW
6000001
Manufacture plant have been changed to STM.
and higher
Addition of S model. ( P.1, P.125, P.126, P.127, P.128,
P.129, P.130, P.131,
New model addition KP-FX432M91(India) &
FP-FX532M91(India), STT Plant. Supplement made
by VP(M) (Pg167)
Model Name :KP-FX432/FX532M31,M91
SERVICE MANUAL
Part No.
Description of SUP/COR
P.164
)
: 9-872-714-03
Change of
main text
-
YES
YES

Advertisement

Table of Contents

   Also See for Sony KP-FX432M31

   Related Manuals for Sony KP-FX432M31

   Summary of Contents for Sony KP-FX432M31

  • Page 1 HISTORY Model Name :KP-FX432/FX532M31,M91 SERVICE MANUAL Part No. : 9-872-714-03 When clicking an item, it’s detail is displayed. Version Serial Change of Date Description of SUP/COR main text 2004.02 2004.03 6000001 Manufacture plant have been changed to STM. and higher Addition of S model.
  • Page 2 SERVICE MANUAL AX-1 CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. KP-FX432M31 KP-FX532M91 RM-998 SCC-M22C-A RM-998 SCC-M15E-A KP-FX432M91 KP-FX532M91 RM-998 SCC-M15D-A RM-998 SCC-M24C-A KP-FX432M91 KP-FX532M91 RM-998 SCC-M24B-A RM-998 INDIA SCC-V33A-A KP-FX432M91 RM-998 SCC-M23F-A KP-FX432M91 RM-998 INDIA SCC-V23B-A...
  • Page 3 VD: 0.7 Vp-p, 75 ohms i (Headphones) Output: 1 Stereo minijack Power requirements 110 -240 V AC, 50/60Hz (KP-FX432/532M91) 220 -240 V AC, 50/60Hz (KP-FX432M31) Power consumption (W) 250 W 926 × 1255× 534 1136 × 1438 × 666 Dimensions (w/h/d,mm) Mass (kg) Design and specifications are subject to change without notice.
  • Page 4: Table Of Contents

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 TABLE OF CONTENTS Section Title Page Section Title Page 1. SELF DIAGNOSIS FUNCTION 3-8. ADJUSTMENTS WITH COMMANDER ..1-1. DIAGNOSTIC TEST INDICATORS ....3-8-1. How to Select Each Mode ......1-2. DISPLAY OF STANDBY/ 3-8-2. How to Enter Service Mode ......
  • Page 5: Section Title Page

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 Section Title Page Section Title Page 6-2. FRAME SCHEMATIC DIAGRAM ....6-3. CIRCUIT BOARDS LOCATION ..... 6-4. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS ......(1) Schematic Diagram of A Board ....(2) Schematic Diagram of AD Board ....
  • Page 6: Self Diagnosis Function

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 SECTION 1 SELF DIAGNOSIS FUNCTION The unit in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER LED will automatically begin to flash. The number of times the LED flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER LED flash indicators is listed in the instruction manual for the user's knowledge and reference.
  • Page 7: Display Of Standby/timer Light Flash Count

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 1-2. DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT Diagnostic items Flash count +B Overcurrent 2 tims Low +B Overvoltage 3 tims Vert. deflection stopped 4 tims White balance failure 5 tims Low +B OVP/OCP 6 tims Horiz. deflection stopped...
  • Page 8: Self-diagnostic Screen Display

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 1-4. SELF-DIAGNOSTIC SCREEN DISPLAY For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past occurrences of failure for confirmation on the screen:...
  • Page 9 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 1-6. SELF-DIAGNOSTIC CIRCUIT MG BOARD AKB 24 IC0001 V PROT 56 VDY- MAIN MICRO +12V STBY-LED HG PROT 57 Q5202 22 STBY-LED +15V CLKO 14 53 SCL < H PLS DATO 13 52 SDA 5 OCP...
  • Page 10: Disassembly

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 SECTION 2 DISASSEMBLY 2-1. REAR BOARD REMOVAL (1) KP-FX432 (2) KP-FX532 2 Rear board 2 Rear board 1 Thirteen screws 1 Fourteen screws (Tapping screw Hexagon head) (Tapping screw Hexagon head) 2-2. MAIN BRACKET REMOVAL 2-3. SERVICE POSITION...
  • Page 11: Front Panel Assy Removal

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 2-4. FRONT PANEL ASSY REMOVAL (1) KP-FX432 2 Three screws (tapping screw hexagon head) 2 Two screws 3 Side panel (43L) assy (tapping screw hexagon head) 1 Three screws (BVTP 4x16) 5 Two screws (tapping screw...
  • Page 12: Hc, Ha And Hb1 Boards Removal

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 2-5. HC, HA AND HB1 BOARDS REMOVAL 2 HC bracket 4 Three screws (BVTP 3x12) 1 Two screws 3 HC board (BVTP 3x12) 6 Two screws 8 Two screws (BVTP 3x12) 5 HA board (BVTP 3x12)
  • Page 13: Beznet Assy Removal

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (2) KP-FX532 1 Six screws (BVTP 4X16 ) 3 Mirror cover 1 Six screws (BVTP 4X16) 2 Four screws (Hexagon head) 5 Beznet block 1 Six screws (BVTP 4X16) 4 Six screws (Hexagon head) 2-7. BEZNET ASSY REMOVAL...
  • Page 14: Terminal Bracket Andt Boards Removal

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (2) KP-FX532 Mirror cover 1 Six screws (BVTP 4X16) 2 Screen 3 Screen holder (SIDE) holder (TOP) 1 Fourteens screws (BVTP 4X16) 6 Diffusion plate (F) 7 Diffusion plate (L) 1 Six screws 8 Contrast screen...
  • Page 15: Ug Board Removal

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 2-9. UG BOARD REMOVAL 1 Two screws (PSW 3x8) 2 B bracket 3 UG board Main bracket section 2-10. AD, BM, DS AND MG BOARDS REMOVAL 3 Two screws (BVTP 3x12) 4 AD Board 4 DS board...
  • Page 16: A, D And G1 Boards Removal

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 2-11. A, D AND G1 BOARDS REMOVAL 1 Two screws (BVTP 3x12) 2 G1 board 3 Three screws (BVTP 3x12) 5 Six screws (BVTP 3x12) 7 Six screws 4 G1 bracket (BVTP 3x12) 6 A board...
  • Page 17: High-voltage Cable Installation And Removal

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (2) KP-FX532 1 Two screws (BVTP 4X16) 2 Three screws 2 Three screws (Hexagon head) (Hexagon head) (4X20) (4X20) 1 Two screws (BVTP 4X16) 3 Picture tube block assy 2 Two screws (Hexagon head) (4X20) PWB block assy 2-13 HIGH-VOLTAGE CABLE 2-14.
  • Page 18: Set-up Adjustments

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 SECTION 3 SET-UP ADJUSTMENTS 3-1. SCREEN VOLTAGE ADJUSTMENT 3-3. FOCUS ROUGH ADJUSTMENT (ROUGH ALIGNMENT) 1. Connect VIDEO-1 terminal. 2. Receive video dot hatch pattern. 1. Receive the Monoscope signal. 3. Use lens-cover to red and blue.
  • Page 19: 2-pole And 4-pole Magnet Adjustment

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 3-5. 2-POLE AND 4-POLE MAGNET 3-6. BLUE DEFOCUS ADJUSTMENT ADJUSTMENT 1. Receive 1080i/50Hz dot signal from HD/DVD 1 terminal. 2. Set “Hi Fine” and PICTURE 100%, other 50% and white 3-5-1. Adjustment of 2-pole magnets balance “COOL”. (VM OFF) 1.
  • Page 20: Adjustments With Commander

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 3-8. ADJUSTMENTS WITH COMMANDER 3-8-1. How to Select Each Mode 50 Hz 60 Hz WIDE 60 Hz WIDE 50 Hz Service adjustment to this model can performed with the supplied (PAL) (NTSC) (NTSC) (PAL) remote commander RM-998.
  • Page 21: Method Of Cancellation From Service Mode

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 3-8-3. Method of Cancellation from Service Mode 3-8-5. How to Write the Data 1. Set in the service mode. 1. Set the standby mode (Press “ (TV STANDBY)” button on the commander), then press “ (TV STANDBY)” button 2.
  • Page 68: Registration Adjustment

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 3-10. REGISTRATION ADJUSTMENT 3-10-2. Setup for Adjustment 1. Marking 3-10-1. Adjustment Flow 1) At the 4 insides of the screen, locate the middle. Use a tape measure to identify the middle. START Turn on the power and wait for 10 minutes ×...
  • Page 69: Operation Method For

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 6. Write “VPS, VSZ and HSZ” adjusted data to other mode ser- 1. Functions of Keys on Commander • 1 vice data. : Changes adjustment item. (item No. moves up) : Marker moves clockwise from center to outside.
  • Page 70: Method Of Projector Engine Adjustment

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 4) In the GRN, BLU, or RED mode, move “ ” up or down to • Fine adjustment can be made on the basis of marker posi- change the data in vertical direction, or move “...
  • Page 71 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 6) Select “GRN SKEW”, and correct the tilt of horizontal lines 9) Select “GRN MSIZ”, and correct the space intervals for the and vertical lines. horizontal section of the screen are equal. • GRN SKEW (horizontally/vertically) •...
  • Page 72 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 2. Red Adjustment 5. Confirm registration of each mode and touch-up. 1) Place a cap on the blue lens so that green and red colors are 1) Receive PAL signal. Select DRC1250 50Hz normal mode. displayed.
  • Page 73: Auto Convergence Setting

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 3-11. AUTO CONVERGENCE SETTING 3-13. WHITE BALANCE ADJUSTMENT This adjustment must be performed after the registration adjust- Connect the W/B adjustment jig(12C BUS). ment was made or after readjustment was made by any reason. 2-1. Set “PICTURE MODE” TO “DYNAMIC”, and adjust.
  • Page 74: Auto Convergence Error Code List

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 3-14. AUTO CONVERGENCE ERROR CODE LIST If an error code is displayed after the set has been fully adjusted, correctly, plese check the following items : position, tilt and sizing. If either of these adjustments are off, even slightli, the auto registration pattern will not hit the four sensors properly. This occurs when the internal generator patterns is being flashed on the screen for the sensor to read.
  • Page 75: Adjustment

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 SECTION 4 ADJUSTMENT 4-1. HV REGULATION ADJUSTMENT 4-2. +B MAX VOLTAGE CONFIRMATION (D Board) The following adjustments should always be performed When replacing the following components marked with ] on the when replacing IC6801, R6809 schematic diagram, always check hold-down voltage and if necessary re-adjust.
  • Page 76: Electrical Adjustments

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 SECTION 5 ELECTRICAL ADJUSTMENTS 5-1. PICTURE QUALITY ADJUSTMENT Original Condition DRC-MF : DRC1250 5-1-1. Preparation PICTURE MODE : HI-FINE 1. Set in the service mode. 3D-NR MODE : OFF 2. Set respective items as follows. ECO MODE...
  • Page 77: Ntsc Video Input (main Picture)

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 5-1-2. NTSC Video Input (Main Picture) 5-1-3. NTSC RF Input (Main Picture) 1. Enter the NTSC video color bar (White & color 75%) signal. 1. Enter the NTSC RF color bar (White & color 75%) signal.
  • Page 78: Pal Video Input (main Picture)

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 2 If still “Sub HUE” can not adjust, 5-1-5. PAL RF Input (Main Picture) Change HUOF data from “2” to “1”. 1. Enter the PAL RF color bar (White & color 75%) signal. Repeat (ii). (i) SUB CONTRAST If “Sub HUE”...
  • Page 79: Diagrams

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 SECTION 6 DIAGRAMS 6-1. BLOCK DIAGRAMS (1) A (1/2), D (1/2) AND HC BOARDS BLOCK DIAGRAMS EXCEPT AUS MODEL CN6010 RECT + AUS MODEL SUR 2 SUR 1 TO G1 BOARD CN6301 CN6008 D6113 AC IN2...
  • Page 80: A (2/2) Board Block Diagram

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (2) A (2/2) BOARD BLOCK DIAGRAM TO D(2/2)BOARD TO D(2/2)BOARD TO MG BOARD TO BM BOARD TO MG BOARD CN5004 CN5005 CN0001 CN3001 CN0002 CN2015(2/2) VIDEO MT_CV MT_VIDEO M_SDAT M_SDAT M_SCLK M_SCLK ST_CV ST_VIDEO AUDIO L/R...
  • Page 81: D (2/2) Board Block Diagram

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (3) D (2/2) BOARD BLOCK DIAGRAM HV BLOCK IC8002 T8001 DRIVE Q8014 PICTURE TUBE V901,V902,V903 CONVERTER L8002 Q8011 Q8021 Q8028 Q8034 Q8035 HV PROT SOFT START D8015 Q8013 AC HOP VCC IC8004 CONVERTER BS9V BUFFER TO 1/2...
  • Page 82: Ad And Sr Boards Block Diagrams

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (4) AD AND SR BOARDS BLOCK DIAGRAMS IC9613 (PJED-CPU,PHOTO SENSOR BUFFER) -5V REG -17V IC9607 IC9606 PJED-CPU CONV DSP IC9601(1/2) CN9601 Q9605 CN9600 RE-R BUFF I SEN U UPPER SENSOR IC9415(1/2) Q9607 Q9603 RE-G BUFF LOWER...
  • Page 83: Bm Board Block Diagram

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (5) BM BOARD BLOCK DIAGRAM IC3104 IC3101 CN3001 OP AMP. AD CONV. MS3.3V DET(NC) Q3112 Q3101 ,Q3102 FF SW BUFFER IC3201 IC3301 IC3303 FFSW FL3101 LINE W -128 DRC MF CONVERTER L.P.F DRC LW (MY0-MY7) FILM...
  • Page 84: Ds,g1 And T Boards Block Diagram

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (6) DS,G1 AND T BOARDS BLOCK DIAGRAM IC5801 CN9400 TELTEXT DECODER IC9400 -17VB -17V CONV.OUT1 +17VB +17V CN5801 BUFFER /REGI MUTE CN9405 Q5808 XTAL OUT Q5807 BH-OUT X5801 Q5806 12HMz BV-OUT Q5801 TO DY(B) XTAL IN...
  • Page 85: Ha And Hb1 Boards Block Diagrams

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (7) HA AND HB1 BOARDS BLOCK DIAGRAMS (SIRCS,KEY) J1101 CN1100 CN1000 STBY5V S1000-1005 KEY1 S-VIDEO -SSW D1006 KEY2 D1007 SIRCS VIDEO 4 J1102 TO UG BOARD INPUT LED G TO MG(1/2)BOARD VIDEO CN1501 LED R CN0004...
  • Page 86: Mg (1/2) Board Block Diagram

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (8) MG (1/2) BOARD BLOCK DIAGRAM CN0002 MAIN R CN0004 MAIN L KEY1 L MUTE KEY2 SUB BYPASS SW SIRCS IC0001 M SCLK M SCLK POWER-LED M SDAT M SDAT STBY-LED TO HA BOARD MT AGE...
  • Page 87: Mg (2/2), Cr, Cg, Cb And Vm Boards Block Diagrams

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (9) MG (2/2), CR, CG, CB AND VM BOARDS BLOCK DIAGRAMS MG(2/2) (R OUTPUT) ( Y/C/J) CN9107 Q0411-0412 IC9101 CLAMP TO FOCUS IC0401 VIDEO OUT BLOCK J9101 CN9103 CN0001(2/2) CN0401 Q9105 V IN V OUT Q0419...
  • Page 88: Ug Board Block Diagram

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (10) UG BOARD BLOCK DIAGRAM IC1501 IC1701 AV SW MAIN COLOR DECODER Q1713,Q1714 YOUT3 CVBS/V2 COUT3 IN6-CV J1502 IN9-CR CrOUT Q1707 (VIDEO IN 2) Q1711 BUFF IN9-CB CbOUT Q1502 ,Q5124 Q1705 Q1712 IN5-S IN9-Y YOUT BUFFER...
  • Page 89: Frame Schematic Diagram

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 6-2. FRAME SCHEMATIC DIAGRAM (R)CRT (G)CRT (B)CRT FOCUS 07MVC31 07MVC31 07MVC31 +12V +12V +12V +12V CN9103 PACK CN9205 CN9204 CN9203 CN9309 CN9102 :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO +210V CN9303 CN9209 CN9107 CN9308 :ONE TOUCH :ONE TOUCH...
  • Page 90: Circuit Boards Location

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 6-3. CIRCUIT BOARDS LOCATION 6-4. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS Note: Terminal name of semiconductors in silk screen • All capacitors are in µF unless otherwise noted. (pF: µµF) printed circuit ( Capacitors without voltage indication are all 50 V.
  • Page 91: Schematic Diagram Of A Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (1) Schematic Diagram of A Board TO G1 BOARD CN6011 CN6100 CN6010 TO G1 BOARD CN6301 :S-MICRO CN6000 TO D(3/3)BOARD CN6400 L6002 100µH RECT+ RECT- R6117 1/10W STBY7V :CHIP C6002 STBY 7V 1000p R6120 CN6001 250V...
  • Page 92 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 CN6000 TO D(3/3)BOARD CN6400 L6002 100µH RECT+ RECT- D6113 KBP153G C6127 0.0022 STBY7V B:1608 C6002 STBY 7V 2200p C6115 R6120 CN6001 250V TO(3/3) 1000 F6000 Q6110 1/10W T6.3A MSB709-RT1 :CHIP ZERO_DET 250V .BLK05FA JW6021 FH6000 FH6001 17.5MM...
  • Page 93 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 CN2019 TU2000 TU2001 WG442(30) LG434(20) R2085 R2066 IC2002 R2102 C2091 C2092 C2090 C2029 S-80843CLUA 470p C2023 R2101 R2057 C2058 R2063 :1608 R2114 B:1608 0.0022 R2108 C2076 :1608 B:1608 :1608 C2066 1 6.3V R2084 C2089 :1608 B:1608...
  • Page 94 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 CN2004 CN2006 CN2007 CN2005 :BTOB :BTOB :BTOB :B TO B TO D(3/3)BOARD TO D(3/3)BOARD TO MG(1/3)BOARD TO BM(1/4)BOARD CN5004 CN5005 CN0001 CN3001 CN2015 :B TO B TO UG(2/2)BOARD CN1502 TO(2/3) VIDEO TO(2/3) MT_CV MT_VIDEO M_SIIC CN2003...
  • Page 95 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 • A (3/3) BOARD WAVE FORMS NTSC SECAM NTSC SECAM [POWER SUPPLY, TUNER, AUDIO AMP] — A BOARD (CONDUCTOR SIDE) — 2.5V 2.5V 2.5V 2.5V NTSC SECAM NTSC SECAM 0.6V 0.6V 0.6V 0.6V Q6109 Q6104 R6119 4.0V...
  • Page 96: Schematic Diagram Of Ad Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (2) Schematic Diagram of AD Board IC9603 NJM2391DL1-33(TE1) C9622 3.3V REG +3.3V C9618 C9621 C9709 R9662 R9658 R9666 1608 6.3V 1608 +3.3V 1/10W 1/10W 1/10W 1608 C9657 CHIP CHIP CHIP 6.3V FB9617 FB9602 C9649 C9650 R9607...
  • Page 97 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 [CONV DSP, PJED-CPU] — AD BOARD (COMPONENT SIDE) — — AD BOARD (CONDUCTOR SIDE) — • AD BOARD SEMICONDUCTOR LOCATION TRANSISTER DIODE Component Conductor Component Conductor Component Conductor Side Side Side Side Side Side Q9602 IC9600...
  • Page 98: Schematic Diagram Of Bm Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (3) Schematic Diagram of BM Board CN3402 R3481 R3482 :1608 :1608 C3412 B:1608 9V-1 FL3401 FB3402 FB3401 R3023 :1608 MS_VDD 9V-2 CN3401 C3032 CN3001 TO MS2(3/3)BOARD F:1608 TO A(3/3)BOARD CN4000 CN2004 C3036 C3035 FL3000 C3039 R3430...
  • Page 99 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 C3186 100p CH:CHIP L3101 RB3101 10µH C3100 :CHIP 1000p B:1608 FB3101 BK2125HM601 C3101 R3181 R3182 1000p R3187 R3191 B:1608 1/10W 1/10W RB3114 RB3115 RB3116 RB3117 :CHIP :CHIP C3102 R3101 R3102 47 1/10W :CHIP :AL-CP 1/10W R3190...
  • Page 100 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 FL3200 CKD510JB1A105ST C3206 C3256 L3204 0.01 3.3V TO(2/4)(4/4) 1µH +3.3V B:1608 MAIN_CCP :CHIP :AL-CP M-VS C3208 IC3205 0.01 PQ70XZ01ZP M-HS D3201 2.5V REG B:1608 M-CLK C3211 C3212 C3213 C3215 C3214 0.01 0.01 0.01 0.01 C3209 0.01...
  • Page 101 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 IC3310 PQ70XZ01ZP 2.5V REG C3304 Q3301 R3302 R3303 0.01 FL3304 MSD601 CKD510JB1A105ST 3.3V 1/10W C3392 1/10W Y_CL :CHIP B:1608 C3354 C3358 0.01 :CHIP 3.3V L3317 FL3306 C3305 0.01 6.3V 1µH CKD510JB1A105ST C3306 C3398 Y_CL C3308 6.3V...
  • Page 102 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 [DRC, MID] — BM BOARD (COMPONENT SIDE) — — BM BOARD (CONDUCTORSIDE) — • BM (4/4) IC3303 : CXD2309AQ R3481 (LSB) R0 CN3402 4LSB’S R3482 FB3402 FB3401 CURRENT CELLS A3401 C3330 R3403 D3301 C3367 R3404 L3312...
  • Page 103: Schematic Diagram Of Cr Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (4) Schematic Diagram of CR Board [R OUTPUT] — CR BOARD (CONDUCTOR SIDE) — V901 • CR BOARD PICTURE TUBE SEMICONDUCTOR LOCATION TO HV BLOCK Component Conductor Side Side IC9101 TO FOCUS BLOCK TRANSISTORQ Component Conductor...
  • Page 104: Schematic Diagram Of Cb Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (5) Schematic Diagram of CB Board [B OUTPUT] — CB BOARD (CONDUCTOR SIDE) — V903 PICTURE • CB BOARD TUBE SEMICONDUCTOR LOCATION HV BLOCK Component Conductor Side Side IC9301 TO FOCUS BLOCK TRANSISTORQ Component Conductor (B OUTPUT)
  • Page 105: Schematic Diagram Of Cg Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (6) Schematic Diagram of CG Board [G OUTPUT] — CG BOARD (CONDUCTOR SIDE) — V902 PICTURE TUBE • CG BOARD SEMICONDUCTOR LOCATION TO HV BLOCK Component Conductor Side Side IC9201 TO FOCUS BLOCK TO FOCUS BLOCK...
  • Page 106: Schematic Diagram Of D Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (7) Schematic Diagram of D Board R5243 1/10W R5247 :CHIP 4.7k 1/10W Q5203 :CHIP Q5201 C5223 R5241 MSD601RT1 FQPF12P20YDTU 1/10W BUFF R5202 +135V SW D5209 R5201 B:1608 :CHIP C5201 R5203 R5204 1PS184-115 0.01 TO(2/3)(3/3) 1/10W H_PLS...
  • Page 107 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 +135V TO(1/3)(3/3) +135V R8166 C8037 0.056 +12V 1/10W 800V MAIN :CHIP :MPP TP8001 CN8001 FB8002 FB8003 Q8003 0.45UH 0.45UH MSD601RT1 T8001 (CONTACT) RHT(NX-6030) D8038 IC8002 Q8014 JL8016 MM3Z15VT1 FB8001 D8024 MCZ3001DA 2SK2842 R8056 0.45UH MM3Z6V2ST1 JL8021 DRIVER 279.4...
  • Page 108 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 CN5017 :S-MICRO TO A(3/3)BOARD CN2017 AUDIO-14V-22V -22V AUDIO-14V-22V AUDIO_GND AUDIO_GND AUDIO+14V+22V +22V AUDIO+14V+22V CN5004 CN5016 :B TO B TO A(3/3)BOARD :S-MICRO CN2006 DF_PARA DF_PARA TO(2/3) DF_DRV DF_DRV H DRV H_DRV TO(1/3) V_SHIFT V_SHIFT TO(1/3) HC_PARA HC_PARA...
  • Page 109 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 [H/V OUTPUT, H CENTER, HV REG, POWER SUPPLY] — D BOARD (CONDUCTOR SIDE) — • D BOARD SEMICONDUCTOR LOCATION Q5528 D6408 R5577 Component Conductor Q5701 D6409 Side Side Q5702 D6410 Q5521 R5576 IC5101 Q5703 D6411 JR1003...
  • Page 110: Schematic Diagram Of Ds Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (8) Schematic Diagram of DS Board CN9407 CN9405 CN9406 CN9408 :S-MICRO :S-MICRO :S-MICRO :S-MICRO TO DY(R) TO DY(G) CN9401 :S-MICRO -17V R9473 TO D(1/3)BOARD -17VB DY(RED) CN5015 R9471 DS-GND +17V R9466 +17VB R9472 R9474 R9467 V DEF...
  • Page 111 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 [HV/ CONV. OUT] — DS BOARD (CONDUCTOR SIDE) — R9410 R9409 R9417 R9414 • DS BOARD SEMICONDUCTOR LOCATION • DS BOARD WAVE FORMS DIODE Component Conductor Component Conductor Side Side Side Side IC9400 D9407 IC9401 D9409 2.0V...
  • Page 112: Schematic Diagram Of G1 Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (9) Schematic Diagram of G1 Board [POWER SUPPLY] TO A(1/3)BOARD CN6010 — G1 BOARD (CONDUCTOR SIDE) — CN6301 VD6301 270V RY6301 0.25W L6301 JW(5) :LHL08 R6301 C6301 1/2W D6309 D6301 :FPRD D1NS6 D1NS6 D6302 10ERA60-TP C6302 0.47...
  • Page 113: Schematic Diagram Of Ha And Hb1 Boards

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (10) Schematic Diagram of HA and HB1 Boards C1105 R1013 IC1000 RPM7140-H8 ST5V 1/4W SIRCS R1107 D1104 D1008 MM3Z10VT1 CN1000 1/10W PROTECT R1003 R1008 :RN-CP PROTECT R1005 WHT-L 1/10W 1/10W :S-MICRO :CHIP 1/10W :CHIP R1012 :CHIP...
  • Page 114: Schematic Diagram Of Hc Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (11) Schematic Diagram of HC Board [P. SWITCH] — HC BOARD (CONDUCTOR SIDE) — CN1050 CN1051 WHT-L WHT-L TO A(1/3)BOARD TO A(1/3)BOARD CN6005 CN6006 S1050 (POWER) (P.SWITCH) B-SS997<CH.>-HC. – 113 –...
  • Page 115: Schematic Diagrams Of Mg Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (12) Schematic Diagrams of MG Board CN0004 CN0007 :S-MICRO :S-MICRO TO HA BOARD TO DS BOARD CN1000 CN9403 JR1001 0 :1608 JR1002 0 :1608 JR1005 FB0005 0 :1608 BK1608TS601 JR1006 0 :1608 JR1007 R0084 0 :1608...
  • Page 116 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 PF_IIC TO (1/3)(3/3) FB0301 BK1608TS601 PF_SCLK PF_SDAT C0316 R0333 C0345 R0340 C0339 2200 :1608 R0332 F:1608 C0323 C0327 C0331 R0327 C0317 0.0033 0.001 R0325 2.2k B:1608 B:1608 1/10W C0320 C0333 C0325 C0329 1/10W :CHIP AUDIO R...
  • Page 117 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 R0513 R0520 1/10W 1/10W :CHIP :CHIP C0462 TEXT_CV FB0401 BK1608TS601 TO (1/3) M_SCLK B:1608 M_SDATA FB0402 TO (1/3) BK1608TS601 REGI_SIGNAL Q0431 MSD601-RT1 BUFF R/G/B R0519 R0512 1/10W 1/10W :CHIP :CHIP R0521 L0401 10µH R0440 L0405 :GLF2012 10µH...
  • Page 118 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 [CPU, PF MICRO, AUDIO PROCESSOR, Y/C/J] — MG BOARD (COMPONENT SIDE) — — MG BOARD (CODUCTOR SIDE)— R0577 CN0006 CN0007 CN0401 CN1164 JR1027 R0576 D0008 JR1028 R0105 C0467 R0555 R0556 R0557 R0528 R0406 R0104 R0579 D0502...
  • Page 119: Schematic Diagram Of Sr Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (13) Schematic Diagram of SR Board (14) Schematic Diagrams of VM Board VM(R) VM(G) (VELOCITY MODULATION) (VELOCITY MODULATION) CN9001 CN9001 R9001 R9001 :S-MICRO :S-MICRO CN9003 CN9003 1/4W FB9001 1/4W FB9001 TO VM(G)BOARD TO VM(R)BOARD +135V :FPRD...
  • Page 120: Schematic Diagram Of T Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (15) Schematic Diagram of T Board D5801 D5802 DAP202K-T-146 R5830 47k 1/10W :CHIP P2.7/PWM6 VDDP P3.0/ADC0 MOVX_R0 R5829 100 1/10W :CHIP A17_LN RESET FB5805 P3.1/ADC1 RESET X5801 C5854 R5828 100 1/10W :CHIP BK1608TS601 12MHz P3.2/ADC2 XTALOUT 3.3V...
  • Page 121: Schematic Diagrams Of Ug Board

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 (16) Schematic Diagrams of UG Board VD1534 VD1535 VD1536 JR1502 VD1537 :CHIP J1509 L1508 R1634 VD1538 (COMPONENT IN1) 10µH C1590 R1633 2.2M VD1533 +5VA L1501 2.2M 1/10W VD1539 V5 Y 10µH 1/10W :CHIP B:1608 :CHIP VD1540...
  • Page 122 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 R1751 4.7M R1745 1/10W C1599 T1501 :CHIP 1/16W 470pF ZTA0012Z :RN-CP CH:1608 J1505 VD1543 JL1501 CENTER R1747 R1748 JL1502 1/4W 1/4W :FPRD :FPRD C1600 470pF R1749 R1750 CH:1608 R1746 1/4W 1/4W 1/16W R1752 :FPRD :FPRD :CHIP 4.7M...
  • Page 123 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 [AV SW, INPUT TERMINAL, MAIN COLOR DECODER, SUB COLOR DECODER] — UG BOARD (COMPONENT SIDE) — — UG BOARD (CONDUCTOR SIDE) — CN1503 CN1501 JR1508 R1584 R1525 Q1501 R1583 R1585 R1589 R1523 R1692 C1582 C1519 R1588...
  • Page 124: Semiconductors

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 6-5. SEMICONDUCTORS CXP961048-013Q LMH6658MMX/J5000172 PQ12RF21 2SA1358-Y 2SK2251-01-F19 TRANSISTOR DIODE M306VSMG-535FP M24128-BWMN6T(A) PQ30RV2B 2SC3421-Y M24C32-WMN6T(A) M24C32-WMN6T(B) MM1482BFBE BD4729GTR DTC114TUA-T106 DAN202K-T-146 NJM2068V-TE2 NJM2870F25-TE2 DTC123JUA-T106 INDEX NJM2903M NJM2870F33(TE2) 2SC5778-RB NJM2903M-TE2 PST9129NL NJM2904M PST9143NL NJM2904M(TE2) TC7SET02FU(TE85R) TOP VIEW NJM4558V-TE2 TC7SET08FU(TE85L)
  • Page 125 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 D1NS4 D5LC20U-4012 1PS184-115 D2L20U D2L20U-F D2L20U-TA (~) 2 MTZJ-33C MTZJ-T-77-10B MTZJ-T-77-15B (~) 2 MTZJ-T-77-33C – RB441Q-40T-77 RD10ESB2 RD15ESB1 EC31QS03L-TE12L RD15ESB2 SPR-325MVW RD15ES-T1B ANODE RD33EB3J RD33ES-T1B3 RD5.1ESB2 CATHODE CATHODE F10P04Q ANODE ANODE (GREEN) (RED) CATHODE ANODE D1NS4-TR2...
  • Page 126: Exploded Views

    7-685-663-71 SCREW +BVTP 4X16 TYPE2 TT(B) * 4-095-685-01 BRACKET, HC (KP-FX432M91) (S) * A-1410-443-A HA BOARD, MOUNT 4-086-335-02 PANEL, SIDE (53L) (KP-FX532M91) 4-089-124-01 HANDLE (KP-FX532M91) 4-378-522-01 SCREW, TAPPING, HEXAGON HEAD 4-086-642-01 PANEL (43L), SIDE (KP-FX432M31/M91) 4-086-643-01 PANEL (43R), SIDE (KP-FX432M31/M91) – 125 –...
  • Page 127: Cabinet Block (kp-fx532)

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 7-2. CABINET BLOCK (KP-FX532) The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. PICTURE TUBE BLOCK ASSY MAIN BLOCK ASSY REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO.
  • Page 128: Cabinet Block (kp-fx432)

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 7-3. CABINET BLOCK (KP-FX432) The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. PICTURE TUBE BLOCK ASSY MAIN BLOCK ASSY REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO.
  • Page 129: Bezenet And Mirror Cover Block (kp-fx532)

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 7-4. BEZENET AND MIRROR COVER BLOCK (KP-FX532) REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK 4-089-284-11 SCREEN (53), CONTRAST * 4-086-645-01 HOLDER (SL), MIRROR 4-091-898-11 PLATE (53L), DIFFUSION 4-378-522-01 SCREW, TAPPING, HEXAGON HEAD 4-089-286-11 PLATE (53F), DIFFUSION...
  • Page 130: Bezenet And Mirror Cover Block (kp-fx432)

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 7-5. BEZENET AND MIRROR COVER BLOCK (KP-FX432) REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK 4-089-287-11 SCREEN (43), CONTRAST * 4-086-648-01 HOLDER (TOP), MIRROR 4-091-897-11 PLATE (43L), DIFFUSION 4-089-324-01 MIRROR (43) (AUS/GE/E) 4-089-289-11 PLATE (43F), DIFFUSION...
  • Page 131: Main Bracket And Picture Tube Block

    * A-1302-676-A A BOARD, COMPLETE ! 8-598-875-00 BLOCK ASSY, HV HVB-1032//C (KP-FX432M91/FX532M91) 4-373-137-01 CAP (Z), RUBBER * A-1302-594-A A BOARD, COMPLETE (KP-FX432M31) * A-1410-432-A CB BOARD, MOUNT ! 1-451-537-14 DEFLECTION YOKE * A-1410-431-A CG BOARD, MOUNT ! 1-451-535-13 COIL ASSY, VM...
  • Page 132: Electrical Parts List

    KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 SECTION 8 ELECTRICAL PARTS LIST • The components identified by in this manual RESISTORS NOTE: have been carefully factory-selected for each set in • All resistors are in ohms order to satisfy regulations regarding X-ray • F : nonflammable The components identified by shading radiation.
  • Page 133 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C6604 1-165-728-31 ELECT 330UF CN5010 * 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P CN5011 * 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P C6607 1-165-729-31 ELECT 470UF...
  • Page 134 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK D8015 8-719-081-97 DIODE MMDL914T1 JR1008 1-216-864-11 SHORT CHIP...
  • Page 135 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK Q5005 8-729-010-25 TRANSISTOR MSD601-RT1 R5109 1-216-833-11 METAL CHIP 1/10W Q5006 8-729-038-83 TRANSISTOR 2SK2251-01-F19 R5110 1-216-833-11 METAL CHIP 1/10W Q5008 8-729-010-25 TRANSISTOR MSD601-RT1 R5111 1-249-383-11 CARBON...
  • Page 136 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R5587 1-260-328-11 CARBON 1/2W R6813 1-216-833-11 METAL CHIP...
  • Page 137 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 • The components identified by in this manual The components identified by shading have been carefully factory-selected for each set in and mark ! are criti-cal for safety. order to satisfy regulations regarding X-ray D AD Replace only with part number specified.
  • Page 138 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C9710 1-125-837-91 CERAMIC CHIP 1UF 6.3V IC9601 8-759-278-58 IC NJM4558V-TE2 C9711 1-125-837-91 CERAMIC CHIP 1UF 6.3V IC9602 8-759-278-58 IC NJM4558V-TE2 C9712 1-164-218-11 CERAMIC CHIP 180PF 5.00% 50V...
  • Page 139 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R9644 1-216-833-11 METAL CHIP 1/10W R9718 1-218-887-11 METAL CHIP 0.5% 1/10W R9719 1-218-887-11 METAL CHIP 0.5% 1/10W R9645 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W...
  • Page 140 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C0049 1-128-945-31 ELECT 1000UF C0340 1-165-908-11 CERAMIC CHIP 1UF C0050 1-128-949-31 ELECT 470UF C0341 1-165-908-11 CERAMIC CHIP 1UF C0051 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V C0052 1-107-826-11 CERAMIC CHIP 0.1UF...
  • Page 141 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C0460 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V <IC> C0461 1-165-733-31 ELECT 100UF C0462 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V IC0001 8-753-213-34 IC CXP961048-013Q C0466 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V...
  • Page 142 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK L0409 1-400-397-11 INDUCTOR 10UH <RESISTOR> L0410 1-400-397-11 INDUCTOR 10UH R0005 1-216-835-11 METAL CHIP 1/10W R0006 1-216-835-11 METAL CHIP 1/10W <TRANSISTOR> R0007 1-216-857-11 METAL CHIP...
  • Page 143 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R0095 1-216-837-11 METAL CHIP 1/10W R0206 1-216-833-11 METAL CHIP 1/10W R0096 1-216-837-11 METAL CHIP 1/10W R0097 1-216-864-11 SHORT CHIP R0207 1-216-809-11 METAL CHIP 1/10W...
  • Page 144 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R0359 1-216-837-11 METAL CHIP 1/10W R0482 1-216-833-11 METAL CHIP 1/10W R0360 1-216-864-11 SHORT CHIP R0401 1-216-809-11 METAL CHIP 1/10W R0484 1-216-809-11 METAL CHIP 1/10W...
  • Page 145 ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1302-594-A A BOARD, COMPL (KP-FX432M31) C2068 1-164-217-11 CERAMIC CHIP 150PF 5.00% 50V ********************** C2069 1-126-933-11 ELECT 100UF 20.00% 16V...
  • Page 146 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C6204 1-164-156-11 CERAMIC CHIP 0.1UF D6200...
  • Page 147 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK JR30 1-216-864-11 SHORT CHIP L6210 1-412-525-31 INDUCTOR...
  • Page 148 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. A BM Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R2043 1-216-821-11 METAL CHIP...
  • Page 149 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C3037 1-126-206-11 ELECT CHIP 100UF 20.00% 6.3V C3159 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C3038 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C3160 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V...
  • Page 150 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C3245 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C3369 1-124-779-00 ELECT CHIP 10UF 20.00% 16V C3246 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C3370 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V...
  • Page 151 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <FILTER> L3308 1-412-029-11 INDUCTOR 10UH L3311 1-469-555-21 INDUCTOR 10UH FL3000 1-234-177-21 FERRITE FL3001 1-234-177-21 FERRITE L3312 1-412-026-11 INDUCTOR FL3003 1-234-177-21 FERRITE L3313 1-412-029-11 INDUCTOR...
  • Page 152 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R3046 1-543-949-22 FERRITE R3160 1-216-819-11 METAL CHIP 1/10W R3047 1-543-949-22 FERRITE R3161 1-216-819-11 METAL CHIP 1/10W R3048 1-543-949-22 FERRITE R3049 1-543-949-22 FERRITE R3162 1-216-864-11 SHORT CHIP...
  • Page 153 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R3257 1-216-809-11 METAL CHIP 1/10W R3360 1-216-805-11 METAL CHIP 1/10W R3259 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W R3362 1-216-817-11 METAL CHIP 1/10W R3262 1-216-809-11 METAL CHIP...
  • Page 154 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 BM UG REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R3462 1-218-825-11 METAL CHIP 0.5% 1/10W X3301 1-781-887-21 VIBRATOR, CRYSTAL (18.543956MHz) R3463 1-218-833-11 METAL CHIP 0.5% 1/10W R3464 1-218-825-11 METAL CHIP 0.5%...
  • Page 155 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C1576 1-164-505-11 CERAMIC CHIP 2.2UF C1811 1-126-925-91 ELECT 470UF 20.00% 10V C1812 1-126-947-11 ELECT 47UF 20.00% 35V C1577 1-164-505-11 CERAMIC CHIP 2.2UF C1813 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V...
  • Page 156 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <FERRITE BEAD> Q1506 8-729-010-05 TRANSISTOR MSB709-RT1 Q1507 8-729-010-05 TRANSISTOR MSB709-RT1 FB1701 1-469-179-21 FERRITE Q1508 8-729-010-25 TRANSISTOR MSD601-RT1 FB1702 1-469-179-21 FERRITE Q1510 8-729-010-25 TRANSISTOR MSD601-RT1...
  • Page 157 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R1541 1-216-825-11 METAL CHIP 2.2K 1/10W R1610 1-216-821-11 METAL CHIP 1/10W R1542 1-216-817-11 METAL CHIP 1/10W R1611 1-216-821-11 METAL CHIP 1/10W R1612 1-216-821-11 METAL CHIP...
  • Page 158 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R1739 1-216-817-11 METAL CHIP 1/10W C9409...
  • Page 159 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 DS G1 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R9404 1-216-809-11 METAL CHIP 1/10W * A-1410-441-A G1 BOARD, MOUNT (KP-FX432/532M91) ************************ R9405 1-216-809-11 METAL CHIP 1/10W R9406 1-216-809-11 METAL CHIP 1/10W...
  • Page 160 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 G1 T CR REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <TRANSFORMER> <TRANSISTOR> T6301 1-437-851-11 TRANSFORMER ASSY, POWER (HST) Q5801 8-729-010-05 TRANSISTOR MSB709-RT1 Q5803 8-729-010-25 TRANSISTOR MSD601-RT1 Q5806 8-729-010-05 TRANSISTOR MSB709-RT1 <THERMISTOR>...
  • Page 161 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C9108 1-126-935-11 ELECT 470UF 20.00% 16V...
  • Page 162 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK D9206 8-719-970-83 DIODE HSS82-TJ * A-1410-432-A CB BOARD, MOUNT...
  • Page 163 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 CB VM REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <NEON LAMP> SG9302 1-519-422-11 GAP, SPARK SG9303 1-519-422-11 GAP, SPARK NL9302 1-517-778-21 LAMP, NEON NL9303 1-517-778-21 LAMP, NEON ************************************************************************************* <TRANSISTOR> * A-1410-453-A VM BOARD, MOUNT...
  • Page 164 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 VM HA HC HB1 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R9006 1-216-811-11 METAL CHIP 1/10W R1005 1-216-809-11 METAL CHIP 1/10W R9008 1-216-815-11 METAL CHIP 1/10W R1006 1-216-825-11 METAL CHIP 2.2K...
  • Page 165 <VARISTOR> ! A-1604-485-A MECHA SEAL (R) ASSY (KP-FX532M91) ! A-1604-487-A MECHA SEAL (B) ASSY (KP-FX532M91) VD1100 1-803-974-21 VARISTOR, CHIP (1608) ! A-1604-504-A MECHA SEAL (R) ASSY (KP-FX432M31/M91) ! A-1604-506-A MECHA SEAL (B) ASSY (KP-FX432M31/M91) ************************************************************************************* ************************************************************************************* * A-1410-447-A SR BOARD, MOUNT...
  • Page 166 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK REMOTE COMMANDER ***************************** 1-477-377-11 REMOTE COMMANDER (RM-998) 9-885-019-97 COVER, BATTERY (FOR RM-998) – 165 –...
  • Page 167 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 Sony EMCS Corporation English 2004CR08-1 Ichinomiya Tec 9-872-714-02 © 2004. 3 – 166 –...
  • Page 168 SUPPLEMENT-2 CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. KV-FX432M31 KV-FX532M91 RM-998 SCC-M22C-A RM-998 SCC-M15E-A KV-FX432M91 KV-FX532M91 RM-998 SCC-M24C-A RM-998 SCC-M15D-A KV-FX432M91 RM-998 SCC-M24B-A KV-FX432M91 RM-998 SCC-M23F-A SUBJECT : NEW MODEL ADDITION KP-FX432M91 (India) and KP-FX532M91 (India) MODEL COMMANDER DEST.
  • Page 169 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 SECTION 2 DISASSEMBLY 2-10. AD, BH, DS AND MG BOARDS REMOVAL Note: Previous BM Board change to BH Board. 3 Two screws (BVTP 3x12) 4 AD Board 4 DS Board 2 BH Board 1 MG Board Main bracket section –...
  • Page 170 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 6-3. CIRCUIT BOARDS LOCATION Note: Previous BM Board change to BH Board. SR board SR board VM board CR board HA board HB1 board HC board BH board VM board G1 board CG board DS board...
  • Page 171 KP-FX432M31/FX432M91/FX532M91 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 RM-998 RM-998 RM-998 6-4-1. BH Board— CCP2 (Block 001) L3101 C3102 10uh 0.01 :LB2016 FB3101 B:1608 BK1608MH601 R3101 C3101 R3181 R3182 1/10W 1000P :CHIP RB3116 B:1608 RB3114 RB3115 RB3117 1/10W 1/10W 10kX4 10kX4 10kX4 10kX4...
  • Page 172 KP-FX432M31/FX432M91/FX532M91 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 RM-998 RM-998 RM-998 6-4-2. BH Board— DRC MF, MID (Block 002) C3305 C3306 IC3302 0.01 IS42S32200B-6TL C3307 6.3V 64M-SDRAM 0.01 RB3304 B:2012 B:1608 47x4 B:1608 RB3303 47x4 RB3305 R3322 R3407 R3403 47x4 1/10W :1608 1/10W...
  • Page 173 KP-FX432M31/FX432M91/FX532M91 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 RM-998 RM-998 RM-998 6-4-3. BH Board— LVDS (Block 003) FB3401 # FL3401 # C3412 FB3402 # R3429 # R3431 # L3404 # L3405 # L3403 # L3401 # L3402 # FB3413 # FB3405 # FB3412 # FB3406 #...
  • Page 174 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 PRINTED WIRING BOARDS [CCP2, DRC MF, MID, LVDS] Note: Previous BM board change to BH board – BH Board – (Component Side) – BH Board – (Conductor Side) – 176 –...
  • Page 175 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 SECTION 7 EXPLODED VIEWS NOTE: • Items marked " * " are not stocked since The components identified by shading • Items with no part number and no they are seldom required for routine service. and mark ! are critical for safety.
  • Page 176 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 7-2. CABINET BLOCK (KP-FX532) The components identified by shading and mark are critical for safety. ¡ Replace only with part number specified. PICTURE TUBE BLOCK ASSY MAIN BLOCK REF.NO. PART NO. DESCRIPTION REMARK Note: The numbers that not indicated below are similiar to the...
  • Page 177 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 7-3. CABINET BLOCK (KP-FX432) The components identified by shading and mark are critical for safety. ¡ Replace only with part number specified. PICTURE TUBE BLOCK ASSY MAIN BLOCK ASSY REF.NO. PART NO. DESCRIPTION REMARK Note: The numbers that not indicated below are similiar to the...
  • Page 178 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 7-4. BEZENET AND MIRROR COVER BLOCK (KP-FX532) REF.NO. PART NO. DESCRIPTION REMARK Note: The numbers that not indicated below are similiar to the previous KP-FX532 series 2-342-785-01 SCREEN(53), CONTRAST 2-342-784-01 PLATE(53L), DIFFUSION * X-2050-284-1 BEZEL(53), ASSY...
  • Page 179 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 7-5. BEZENET AND MIRROR COVER BLOCK (KP-FX432) REF.NO. PART NO. DESCRIPTION REMARK Note: The numbers that not indicated below are similiar to the previous KP-FX432 series 2-067-340-21 SCREEN(43), CONTRAST 2-342-783-01 PLATE(43L), DIFFUSION * X-2023-271-1 BEZEL(43), ASSY...
  • Page 180 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 7-6. MAIN BRACKET AND PICTURE TUBE BLOCK The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK Note: The numbers that not indicated below are similiar to the...
  • Page 181 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 SECTION 8 ELECTRICAL PARTS LIST RESISTORS • The components identified by in this manual NOTE: • All resistors are in ohms have been carefully factory-selected for each set in • F : nonflammable order to satisfy regulations regarding X-ray The components identified by shading radiation.
  • Page 182 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C6203 1-164-156-11 CERAMIC CHIP 0.1UF D6204...
  • Page 183 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading The components identified by shading and mark ! are criti-cal for safety. and mark ! are criti-cal for safety. Replace only with part number specified. Replace only with part number specified.
  • Page 184 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK L2005 1-456-621-11 INDUCTOR 35UH R2024 1-216-817-11 METAL CHIP...
  • Page 185 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading The components identified by shading A AD and mark ! are criti-cal for safety. and mark ! are criti-cal for safety. Replace only with part number specified. Replace only with part number specified.
  • Page 186 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading The components identified by shading and mark ! are criti-cal for safety. and mark ! are criti-cal for safety. Replace only with part number specified. Replace only with part number specified.
  • Page 187 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R9633 1-216-821-11 METAL CHIP 1/10W R9702 1-218-863-11 METAL CHIP 4.7K...
  • Page 188 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C3115 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V...
  • Page 189 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C3379 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V <COIL>...
  • Page 190 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading BH CB and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R3122 1-216-819-11 METAL CHIP...
  • Page 191 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C9306 1-164-156-11 CERAMIC CHIP 0.1UF <TRANSISTOR>...
  • Page 192 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading CG CR and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1410-431-A CG BOARD, MOUNTED <NEON LAMP>...
  • Page 193 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading CR D and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C9114 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V...
  • Page 194 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading The components identified by shading and mark ! are criti-cal for safety. and mark ! are criti-cal for safety. Replace only with part number specified. Replace only with part number specified.
  • Page 195 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading The components identified by shading and mark ! are criti-cal for safety. and mark ! are criti-cal for safety. Replace only with part number specified. Replace only with part number specified.
  • Page 196 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading The components identified by shading and mark ! are criti-cal for safety. and mark ! are criti-cal for safety. Replace only with part number specified. Replace only with part number specified.
  • Page 197 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading The components identified by shading and mark ! are criti-cal for safety. and mark ! are criti-cal for safety. Replace only with part number specified. Replace only with part number specified.
  • Page 198 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R5430 1-216-833-11 METAL CHIP 1/10W R6602 1-249-380-11 CARBON 0.82...
  • Page 199 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading D DS and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R8055 1-245-478-21 METAL 470K...
  • Page 200 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading DS G1 and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK JW54 1-535-143-11 LEAD, JUMPER (10.0MM)
  • Page 201 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading G1 HA and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C6305 1-126-965-91 ELECT 22UF 20.00% 50V...
  • Page 202 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading HA HC MG and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <SWITCH> <VARISTOR> S1000...
  • Page 203 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C0055 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V C0345 1-164-156-11 CERAMIC CHIP 0.1UF...
  • Page 204 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <CONNECTOR> IC0008 6-801-375-01 IC PST9129NL IC0050...
  • Page 205 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <TRANSISTOR> R0015 1-216-809-11 METAL CHIP 1/10W...
  • Page 206 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R0101 1-216-864-11 SHORT CHIP R0214 1-216-813-11 METAL CHIP...
  • Page 207 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading The components identified by shading and mark ! are criti-cal for safety. and mark ! are criti-cal for safety. Replace only with part number specified. Replace only with part number specified.
  • Page 208 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading SR T UG and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <SWITCH> Q5809 8-729-010-25 TRANSISTOR MSD601-RT1...
  • Page 209 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C1516 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V...
  • Page 210 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading The components identified by shading and mark ! are criti-cal for safety. and mark ! are criti-cal for safety. Replace only with part number specified. Replace only with part number specified.
  • Page 211 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading The components identified by shading and mark ! are criti-cal for safety. and mark ! are criti-cal for safety. Replace only with part number specified. Replace only with part number specified.
  • Page 212 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading UG VM and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R1628 1-216-853-11 METAL CHIP...
  • Page 213 KP-FX432M31/FX432M91/FX532M91 RM-998 RM-998 RM-998 The components identified by shading and mark ! are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <FERRITE BEAD> ********************************************************************************* FB9001 1-469-869-21 FERRITE...
  • Page 214 English Sony EMCS Corporation 2004CR08-1 © 2004. 3 Ichinomiya Tec 9-872-714-03 ® 2004. 12 – 216 –...

This manual is also suitable for:

Kp-fx532m91Kp-fx432m91

Comments to this Manuals

Symbols: 0
Latest comments:
