No combustible material or products should be placed on this product at any time.
Do not spray aerosols in the vicinity of this product while it is in operation.
Installation must be carried out according to the manufacturer's instructions.
Incorrect installation may cause harm and damage to people, animals or property, for which
the manufacturer accepts no responsibility.
If the installation requires alterations to the domestic electrical system, call a qualified
electrician. The electrician should also check that the socket cable section is suitable for the
power drawn by the appliance.
Before carrying out any work on the electrical section of the appliance, it must be
disconnected from the mains.
The manufacturer accepts no responsibility for any inconvenience caused by failure to
comply with this rule.

Electrical requirements

The appliance must be connected to the mains checking that the voltage corresponds to the
value given in the rating plate and that the power supply cable sections can withstand the load
specified on the plate.
The plug must be connected to an earthed socket in compliance with safety standards.
If the appliance is supplied without plug, fit a standard plug which is suitable for the power
consumed by the appliance.
The wires in the power supply cable are coloured in accordance with the following code:
Green/Yellow = Earth, Blue = Neutral, Brown = Active.
If the colours of the wires in the power cable to the appliance do not correspond with the coloured
markings identifying the terminals in the terminal block, proceed as follows:
1 The wire which is coloured green and yellow must be connected to the terminal marked E (Earth)
or coloured Green.
2 The wire which is coloured blue must be connected to the terminal marked N (Neutral) or
coloured Black.
3 The wire which is coloured brown must be connected to the terminal marked L (Live) or A (Active)
or coloured Red.
A suitable disconnection switch must be incorporated in the permanent wiring, mounted and
positioned to comply with the local wiring rules and regulations. The switch must be of an approved
type installed in the fixed wiring and provide a 3 mm air gap contact separation in all poles in
accordance with the local wiring rules.
In New Zealand and Australia, a switch of the approved type with a 3 mm air gap must be installed in
the active (phase) conductor of the fixed wiring.
The power supply cable must not touch the hot parts and must be positioned so that it does not
exceed 50°C above ambient.
Once the appliance has been installed, the switch or socket must always be accessible.
If the power supply cable is damaged, it must be replaced by the manufacturer or its Service
Agent or a similarly qualified person in order to avoid a hazard.
Safety and warnings
3
