Summary of Contents for Haier HCI905FTB4
- Page 1 Induction Cooktops INDUCTION COOKTOPS HCI905FTB4, HCI905FTG4, HCI905TPB4, HCI905TB4, HCI604FTB4, HCI604FTPB4, HCI604FTG4 USER GUIDE NZ AU...
- Page 2 CONTENTS Safety and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cooktop overview HCI905FT4 .
- Page 3 SAFETY AND WARNINGS WARNING! Electric Shock Hazard Failure to follow this advice may result in electric shock or death. • Do not cook on a broken or cracked cooktop . If the cooktop surface should break or crack, switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician .
- Page 4 SAFETY AND WARNINGS WARNING! Cut Hazard Failure to follow this advise could result in injury and cuts. • Take care - panel edges are sharp . • The razor-sharp blade of a cooktop scraper is exposed when the safety cover is retracted . Use with extreme care and always store safely and out of reach of children .
- Page 5 SAFETY AND WARNINGS READ AND SAVE THIS GUIDE General Use Never leave the appliance unattended when in use. Boilover causes smoking and greasy spillovers that may ignite. Never use your appliance as a work or storage surface. Never leave any objects or utensils on the appliance. Never use your appliance for warming or heating the room.
- Page 6 SAFETY AND WARNINGS Please make this information available to the person responsible for installing the appliance as it could reduce your installation costs. In order to avoid a hazard, this appliance must be installed according to these instructions for installation. This appliance should be connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply.
- Page 7 COOKTOP OVERVIEW HCI905FT4 FEATURES AND ACCESSORIES Cook zone 2000W to 2600W (boost) MaxZone 2300W to 3500W (boost) Cook zone 1500W to 2000W (boost) FlexZone Cook zone 2000W to 2600W (boost) Control Panel Cook zone 1500W to 1800W (boost) 1 2 3 FEATURES AND ACCESSORIES Power on/off Start/pause all cooking...
- Page 8 COOKTOP OVERVIEW HCI604FT4 FEATURES AND ACCESSORIES Cook zone 2000W to 2600W (boost) FlexZone Cook zone 1500W to 2000W (boost) Control Panel Cook zone 2000W to 2600W (boost) Cook zone 1500W to 1800W (boost) 1 2 3 FEATURES AND ACCESSORIES Power on/off Start/pause all cooking Key Lock FlexZone...
- Page 9 COOKTOP OVERVIEW HCI905TPB4, HCI905TPB4, HCI905TB4 FEATURES AND ACCESSORIES Cook zone 2000W to 2600W (boost) Max zone 2300W to 3000W (boost) Cook zone 1500W to 2000W (boost) Control Panel Cook zone 2000W to 2600W (boost) Cook zone 1500W to 1800W (boost) 1 2 3 FEATURES AND ACCESSORIES Power on/off...
- Page 10 COOKWARE Induction cookware The quality of your cookware can affect cooking performance . Only use induction-compatible cookware that has been specifically designed for induction cooking . Look for the induction symbol on the packaging or the bottom of the pan . Ensure the base of your cookware is smooth, sits flat against the glass, and is similar in size than the cooking zone .
- Page 11 FIRST USE Display overview ZONE DISPLAY DESCRIPTION Cooktop off (not activated) Cooking zone on (activated but not operating) Power levels Touch display Your cooktop is operated using an Hot surface indicator intuitive touch display . Use the control panel to navigate cooking settings . Pan not detected indicator Pan not suitable for induction Using the touch controls...
- Page 12 KEY LOCK Key Lock When the cooktop is locked any zones in use will remain on and the power levels cannot be changed . Activating Key Lock 1. Hold the keylock control for 3 seconds until is displayed . Disabling Key Lock 2.
- Page 13 INDUCTION COOK ZONES To begin cooking Always place pans in the centre of the cooking zone . If the pan is not correctly placed will flash . If the pan is too small or not suitable will flash . 1. Place a suitable pan on the desired cooking zone .
- Page 14 INDUCTION COOK ZONES To pause cooking 1. Hold start/pause for 3 seconds to pause all cooking functions, will illuminate in all cooking zones . To re-start, hold for 3 seconds . To stop cooking 2. To turn the cooking zone off, press the left end of the power control until the display shows HCI905T Models:...
- Page 15 FLEXZONES The FlexZone function allows you to use two zones together for a larger cooking area . There may be a cooler area in the centre of the cooktop between the cooking zones . You may need to move food around the pan to ensure even cooking . When using FlexZone it is not possible to use the PowerBoost function .
- Page 16 FEATURES WARM FUNCTION Use the warm function to maintain a gentle heat . When the selected induction zone has heated, hold the end of the slider bar for 3 seconds until the display cycles through to and then To exit Warm select any power level using the cook zone control .
- Page 17 USING THE TIMER Setting the timer for a single cookzone 1. Select the cook zone and choose a power level . Press or control . Minutes will show in the timer display and the selected cook zone will flash . The timer will start after 30 seconds .
- Page 18 WIFI/APP CONNECT The SmartHQ app connects to your cooktop and contains useful information and tips . The app ensures your Wi-Fi module firmware stays up to date, providing security and compatibility with your connected appliances . Getting started Connecting the cooktop to Wi-Fi for the first time may take up to 10 minutes . To prevent the cooktop automatically powering off while connecting, put a pot of water on one of the cooking zones and set it to power level 1 .
- Page 19 HOB-TO-HOOD CONNECT This feature enables a compatible Haier rangehood to be paired with your cooktop . The rangehood extraction speed automatically adjusts based on your cooktop power level . Getting started 1. On your cook top press and hold until you hear a beep . Then press and hold on your rangehood .
- Page 20 COOKING GUIDE Induction heat settings HEAT SETTING SUITABILITY Melting chocolate, butter, and foods that burn quickly Warm 1 - 2 Gentle simmering Slow warming 3 - 4 Reheating Rapid simmering Cooking rice 5 - 6 Pancakes 7 - 8 Pan-frying Cooking pasta Stir-frying Searing...
- Page 21 CARE AND CLEANING WHAT? HOW? IMPORTANT! Everyday soiling on glass 1. Switch the power to the cooktop When the power to the cooktop (fingerprints, marks, off at the wall . is switched off, there will be no stains left by food or ‘hot surface’...
- Page 22 TROUBLESHOOTING PROBLEM POSSIBLE CAUSES WHAT TO DO The induction cooktop No power . Make sure the induction cooktop is connected to the power supply and that it is switched on . Check cannot be turned on. whether there is a power outage in your home or area .
- Page 23 TROUBLESHOOTING PROBLEM POSSIBLE CAUSES WHAT TO DO The induction hob or a Technical fault . Check the alert codes section in this guide . cooking zone has turned If a solution can not be found in the alert codes itself off unexpectedly, section, switch the power to the induction hob off a tone sounds and an at the wall, and contact a qualified technician.
- Page 24 ALERT CODES If an abnormality comes up, the induction cooktop will enter a protective state automatically and display corresponding fault codes: PROBLEM POSSIBLE CAUSES WHAT TO DO Temperature sensor of the induction Please contact customer care . coil failure Temperature sensor of the induction Please contact customer care .
- Page 25 . You must produce both warranty card and proof of purchase in the event of a warranty repair being required . When you purchase any new Haier Product you automatically receive a two year Manufacturer's Warranty covering parts and labour for servicing .
- Page 26 MANUFACTURER'S WARRANTY Note: This Warranty is an extra benefit and does not affect your legal rights and applies only to product purchased in New Zealand and Australia . Please keep this Warranty Card in a safe place . For Australian customers: Our goods come with guarantees that cannot be excluded under the Australian Consumer Law .
- Page 27 CUSTOMER SERVICE We recommend our Haier Customer Service and the use of original spare parts . If you have a problem with your appliance, please first check TROUBLESHOOTING . If you cannot find a solution there, please contact: Your local dealer .
- Page 28 WWW .HAIER .COM .AU 条形码尺寸40*8mm， 由厂家生成。 WWW .HAIER .CO .NZ 432499A 10.24...
