- Page 1 FT1455-L2 Hand Launcher Operating Instructions...
-
Page 2: Specifications
80 P .s.iI. - 110 P .s.i. (5.5 - 7 .5 Bar) maximum. Clean, dry, filtered air or inert gas source is required. 5 micron filter and regulator with gauge are recommended. EATON FT1455-L2 Hand Launcher Operating Instructions E-HOAI-CC002-E May 2015... -
Page 3: General Information
General Information Preparation Step 1: Nozzle and projectile selection The Eaton’s FT1455-L2 Hand Held Launcher was designed to shoot a projectile through hose and tube assemblies to strip out Select nozzle and projectile from Nozzle and Projectile selection internal contamination such as rubber dust and metal particles chart on pages 6, 7 , 8 and 9. - Page 4 Connect a 1/2” I.D. air hose using the supplied Full Flow Quick Connect Coupling to the back of the launchers’ 5 micron air filter as shown. (See Figure 8). Figure 6 Figure 8 EATON FT1455-L2 Hand Launcher Operating Instructions E-HOAI-CC002-E May 2015...
-
Page 5: Step 5: Operation
Several projectiles may need to be fired to end of the hose, tube or pipe you are cleaning. (See Figure 9). thoroughly remove contaminates. See Figure 10). Figure 9 Figure 10 EATON FT1455-L2 Hand Launcher Operating Instructions E-HOAI-CC002-E May 2015... - Page 6 The above sizes are recommendations. Due to different types of fittings, and the amount of contamination in the line, the size projectile may need to be adjusted. EATON FT1455-L2 Hand Launcher Operating Instructions E-HOAI-CC002-E May 2015...
- Page 7 Always use an Eaton projectile after the use of an abrasive projectile. Tube projectiles should be used to remove mandrel lubricants, grease and oil.
- Page 8 Always use an Eaton projectile after the use of an abrasive projectile. EATON FT1455-L2 Hand Launcher Operating Instructions E-HOAI-CC002-E May 2015...
-
Page 9: Pipe Sizing Chart
NOTE: To ensure cleanliness, an Ultra Clean projectile must be used after abrasive and grinding projectiles. Please call if you need help in sizing your application for the correct nozzles and projectiles. EATON FT1455-L2 Hand Launcher Operating Instructions E-HOAI-CC002-E May 2015... - Page 10 Fax: 952-294-7722 Fax: +41 (0) 21 811 4601 Tel: (+86 21) 5200 0099 www.eaton.com/hydraulics Fax: (+86 21) 2230 7240 Assembly Equipment © 2015 Eaton Technical Support | Service | Spare Parts All Rights Reserved www.EatonCrimperSupport.com Printed in USA 1-888-AT-LOMAR Document No. E-HOAI-CC002-E...
