  • Page 1 ET1280 Crimp Machine Set Up and Operating Manual...

  • Page 2: Table Of Contents

    Do not allow anyone, tions for each specified hose other than the operator, assembly are not followed. close to the equipment while it is in operation. EATON ET1280 Crimp Machine Set Up and Operating Manual E-EQCR-TM003-E September 2005...

  • Page 3: Specifications And Equipment

    * Included in the 5 die cage package. Fitting Locators † Included in the 8 die cage package. FT1330-XL For easy positioning of fittings into FT1380 “M” series die cages. EATON ET1280 Crimp Machine Set Up and Operating Manual E-EQCR-TM003-E September 2005...

  • Page 4: Set-Up And Operating Instructions

    (Figure 1). The die cage may be inserted or removed in this position. Figure 1 EATON ET1280 Crimp Machine Set Up and Operating Manual E-EQCR-TM003-E September 2005...

  • Page 5: Crimping Procedures

    (rotate the adjustment resultant crimp diameter can machine setting (250-134=116) to the machine setting. knob upward) by the same be measured. amount in thousandths of an EATON ET1280 Crimp Machine Set Up and Operating Manual E-EQCR-TM003-E September 2005...

  • Page 6: Calibration

    Every 500 crimps Remove old 1. Lubricate the die cage. grease and For maximum service. FT1380 die cages require lubrication at 50-crimp intervals with NEVER-SEEZ (Eaton relube part number FT1092). FT1092 is an 8-ounce container that will provide sufficient lubricant for approximately 5,000 crimps.

  • Page 7: Crimp Machine Components

    1/4-20 x 3/8" Button Head Cap Screw Steel ET1280C-0014 5/16-18 Button Head Cap Screw Steel FF90626 Set Screw Steel FF90627 229 O-Ring Neoprene ET1280C-0015/ET1280C-0017 Red Shroud/Yellow Shroud Steel EATON ET1280 Crimp Machine Set Up and Operating Manual E-EQCR-TM003-E September 2005...

  • Page 8: Die Cage Components

    Spring Plate FT1330-2-9-55 FT1330-2-9-5 Button head Cap Screw FT1330-2-9-66 FT1330-2-9-6 Spacers FT1380-2-9-1 FT1380-2-9-1 Back Plate *The FT1380-200-NO. (FT1380-2-9) requires 16 springs and the FT1380-201-NO. (FT-1380-2-9A) requires 8 springs. EATON ET1280 Crimp Machine Set Up and Operating Manual E-EQCR-TM003-E September 2005...

  • Page 9: Eaton Et1280 Crimp Machine Set Up And Operating Manual E-Eqcr-Tm003-E September

    EATON ET1280 Crimp Machine Set Up and Operating Manual E-EQCR-TM003-E September 2005...

  • Page 10: Et1280C

    EATON ET1280 Crimp Machine Set Up and Operating Manual E-EQCR-TM003-E September 2005...
  • Page 11 Tel: 952 937-9800 Australia Tel: (49) 7221 682-0 Fax: 952 974-7722 Tel: (61) 3 9319 8222 Fax: (49) 7221 682-788 www.hydraulics.eaton.com Fax: (61) 3 9318 5714 © 2005 Eaton Corporation All Rights Reserved Printed in USA Document No. E-EQCR-TM003-E September 2005...
