Summary of Contents for Eaton Aeroquip Rynglok Fitting System

  • Page 1 ® Aeroquip Rynglok ® Fittings Rynglok Fitting System Installation Guide...
  • Page 2 6.3 Special Considerations When Using The -20 and -24 Tools 7 .0 Tube Cut Dimensions ................9 7 .1 Female Arcseal™ Fitting 7 .2 Female Flareless Fitting 7 .3 Female Flared Fitting 8.0 Fitting Selection Chart ................10 – 11 EATON Aerospace Group TF100-67A March 2013...
  • Page 3 It will be necessary to reclean and remark tube ends. It is recommended to repaint the exposed tubing after installation. Please contact Eaton’s Jackson, MI facility at (517) 787-8121 if there are any questions regarding this procedure.
  • Page 4 Refer to section 7 .0 when install- ing fittings of this type. Figure 4 End fitting tube positioning. Note: Tube is bottomed into fitting. EATON Aerospace Group TF100-67A March 2013...
  • Page 5 8000-8500 psig (551.58-586.05 bar) is reached. When the pressure is released, the movable jaw will return to its original position. EATON Aerospace Group TF100-67A March 2013...
  • Page 6 Figure 6A to ensure proper inspection procedures. Note: It is necessary that tube marking procedures be adhered to for all Rynglok fittings. Figure 6B Complete ring advancement inspection. Figure 8 Fittings with over insertion conditions EATON Aerospace Group TF100-67A March 2013...
  • Page 7 “butted” condition since the tube insertion inspection marks are made from the end of the tube, not from the 1.0000 4.15 ends of the defect. 1.2500 4.81 1.5000 5.42 EATON Aerospace Group TF100-67A March 2013...
  • Page 8 Warning: The swage pressures listed on the special “Reversed Tools” must be strictly adhered to, in order to prevent excessive tonnage applied to the fitting which may result in a damaged fitting or fitting failure. EATON Aerospace Group TF100-67A March 2013...
  • Page 9 Female flareless tube cut dimensions Table 7 Part No. “A” +.030 in. Part No. “A” +.030 in. R82101T03 0.602 R82101T10 .979 R82101T04 0.616 R82101T12 1.004 R82101T05 0.695 R82101T16 1.135 R82101T06 0.726 R82101T20 1.165 R82101T08 0.837 R82101T24 1.395 EATON Aerospace Group TF100-67A March 2013...
  • Page 10 R81174T( )( )( ) R81194T( )( )( ) R81154T( )( )( ) (Separable on Side) Non-Reducer R81126T( ) R81146T( ) R81106T( ) Reducer R81176T( )( )( ) R81196T( )( )( ) R81156T( )( )( ) EATON Aerospace Group TF100-67A March 2013...
  • Page 11 R82146T( ) R82106T( ) R83126T( ) R83146T( ) R83106T( ) R82176T( )( )( ) R82196T( )( )( ) R82156T( )( )( ) R83176T( )( )( ) R83196T( )( )( ) R83156T( )( )( ) EATON Aerospace Group TF100-67A March 2013...
  • Page 12 Jackson, Michigan 49203-1972 Phone: (517) 787 8121 Fax: (517) 789 2947 Eaton Aerospace Group 9650 Jeronimo Road Copyright © 2013 Eaton Irvine, California 92618 All Rights Reserved Ph (949) 452 9500 Form No. TF100-67A Fax (949) 452 9555 (Supersedes AB7) www.eaton.com/aerospace...
