Maintenance Manual SP 40
3.4 Printer Set-Up Mode by Web Browser (NIC board)
If the printer has the LAN interface board installed, using an Internet Browser, it is possible monitoring the status of
the printer (a virtual operator panel with display shows the messages) and do the remote configuration Setup.
The printer has buitl-in html pages. It can be reached by prompt the IP address on the browser.
Before install the printer in LAN environment, it is necessary to configure the LAN parameters.
See chapter 4 and the User Manual of the LAN interface for details.
The html pages are the following:
HOME PAGE, PRINTER CONFIGURATION PAGES (Configuration Setup, Program1 with Offset Setup , Program2
with Offset Setup, NIC Setup, System) PRINTER STATUS PAGE (current ribbon and print head life), PRINTER
RESET PAGE, PRODUCT SUPPORT PAGE.
Figure 3.11a - Home Page of SP40 using a web browser
Rev. 005 Chapter 3
63 Operabilty and Configuration
