Maintenance Manual
2.18

Sensor Board and Sensor Cable

DANGER :
To prevent serious personal injury from electrical shock always turn the printer off and unplug
the power cable before to remove the sensor board or its cable.
Sensor board and sensor cable are respectively item 10 and 98 of figure 2.21.
They are installed under the front bed of the printer.
To Remove:
1)
Remove the lower roller assy (front side) following all the removal operations described in the chapter
2.17.
2)
Remove the two screws and related washers (item 13 and 14 of figure 2.21) and remove the sensor
board with the cable pugged on it.
3)
Unplug the sensor cable from the sensor board.
To Install:
To install, follow the removal step in reverse order.
REMARK:
Before to install the sensor board, check for the presence of the insulating mylar (item 12 of figure 2.21) stiked
under the connector area of the board. This is important to avoid electrical short circuit touching the metal bed.
Rev. 005
44
SP 40
Chapter 2
Removals
