Fig. 5.9 Remote Mode Display (Sensor 2 Error During T&D9) - CPG Compuprint SP 40 Maintenance Manual

Maintenance Manual
The serial monitor is used also for showing the sensors PWM values and the memory dump with engine
configuration data (DoeConfig).
LOAD PAPER
csls_calibrate_pwm:
s1_pwm=60 s2_pwm=60
0 000000010 000000010
4 000000011 000000008
8 000002576 000000031
12 000004482 000000047
16 000006084 000000062
20 000007523 000000073
24 000007819 000000088
28 000007872 000000101
32 000007903 000000115
36 000007915 000000129
40 000007927 000000143
44 000007933 000000159
48 000007939 000000168
52 000007950 000000183
56 000007953 000000200
60 000007953 000000215
64 000007963 000000226
68 000007965 000000240
72 000007969 000000255
76 000007974 000000267
80 000007980 000000283
84 000007978 000000297
88 000007983 000000312
92 000007981 000000329
96 000007988 000000342
100 000007990 000000352
104 000007991 000000368
108 000007991 000000385
112 000007995 000000400
116 000007999 000000418
120 000007999 000000438
124 000008000 000000448
KO 09 ORU 02[01]
REPT ERR SKIP
Rev. 005
Fig. 5.9 Remote mode display (Sensor 2 error during T&D09)
109
SP 40
Chapter 5
Test & Diagnostic
