Maintenance Manual
Chapter 2
2.1

Overview

This section describes the removal and installation procedures of the major printer parts.
Danger notices warn against personal injury that is lethal or extremely hazardous.
Caution notices warn against personal injury that is neither lethal nor extremely hazardous.
Attention notices warn against damage to machine, equipment or programs.
Remark notices warm against some particular procedure to be run.
Necessary Tools:
• Assortment of cross-head and blade screwdrivers.
• Wrench allen type.
• Pliers.
• Set of fastener loop-self lock.
• Cutting nippers.
• Fork wrench 10mm.
• Feeler Gauge.
List of the removal and installation parts:
- ch 2.2 Covers
- ch 2.3 Print Head
- ch 2.4 Mechanical Assy
- ch 2.5 Boards
- ch 2.5 Power Supply
- ch 2.6 Operator Panel
- ch 2.7 Motors Assy
- ch 2.8 Home Sensor Assy
- ch 2.9 Ribbon Sensor Assy
- ch 2.10 Ribbon Drive Assy
- ch 2.11 Carriage Assy
- ch 2.12 Mylar Bar
- ch 2.13 Rear Roller Assy
- ch 2.14 Front Roller Assy
- ch 2.15 Selector Cam
- ch 2.16 Lower Roller Assy
- ch 2.17 Lower Roller Assy
- ch 2.18 Sensor Board, Sensor Cable
- ch 2.19 Platen Assy
- ch 2.20 Print Head Cables
- Cariage Belt (see ch 2.11)
- Paper Belt (see ch 2.7 or 2.16 or 2.17)
- Open Lever (see ch 2.11)
- Mylar Protection Cable (see ch 2.20)
- Print Head Safety Cover (see ch 2.3)
- Switch Lever P.S. (see ch 2.5)
Rev. 005

Removals

(Top Cover and Main Cover)
(Optional I/F, Backpanel, Engine, Controller and Power Supply Boards)
(Carriage Motor, Carriage Pulley, Selector Motor, Paper Motor)
(Rear Side)
(Front Side)
13
SP 40
Chapter 2
Removals
