Physical Specification; Environmental Specification; Functional Specifications - Optelecom 9525AY/SM-FC Installation And Operation Manual

Table 1 - Models Available
MODELS OPTIC
PORT
9525AY/SM-ST ST
9525AY/SM-FC FC
1 Range based on 0.5 dB/km at 1310 nm and for 9/125 um fiber. Range includes a 3 dB safety margin.
2
Substitute 9521 for 9525 to order the rack mount card version.

1.2 Physical Specification

DIMENSIONS
INCHES
WEIGHT
INDICATORS

1.3 Environmental Specification

TEMPERATURE
Operating
Storage
HUMIDITY

1.4 Functional Specifications

1.4.1 OPTICAL
Wavelength
Minimum coupled power into:
Receiver input power for 19
Minimum
Maximum
1.4.2 ELECTRICAL (Tx and Rx)
Data Interface
Connector
FIBER
09/125
09/125
Height Width
1.5
0.81 lb. 0.37 kg
POWER, TD/TX1, RD/RX1, RTS/TX2, CTS/RX2, TDEXP/RX1
PRIORITY, RDEXP/RX2 PRIORITY, and FAULT.
Fahrenheit
-40 to 165° F
-40 to 185° F
0 to 95% RH noncondensing
1310 and 1550 nm
9/125 μm
-9
BER:
-36 dBm peak
-8 dBm peak
RS232, RS422, or RS485 (2- or 4-wire), switch selectable
DB25S (Primary Port)
RJ45 (Expansion Port)
Emitter Wavelength
TX1/RX1
1310 nm
1310 nm
Length
3.17 5.0
Celsius
-40 to 74° C
-40 to 85° C
-10 dBm Peak
6
OPTICAL
BUDGET
TX2/RX2
1550 nm 26 dB
1550 nm 26dB
