- Page 1 Optelecom 9000 Series Installation and Operation Manual Model 9525AY Single Fiber Dual Optics RS232, RS422, or RS485 Drop and Insert Modem UM50236, Manual 9525AY, Rev. B...
-
Page 3: Table Of Contents
Table of Contents Section Page Safety Instructions 1 - INTRODUCTION 1.1 General description Physical Specification Environmental Specification Functional Specifications 2 - INSTALLATION System Architecture Modes of Operation Operational Features and Considerations Set-Up Procedures Mounting Optical Cabling Electrical Cabling Power Wiring 3 - OPERATION Turn on Procedure Indicator Light Interpretation... -
Page 4: Safety Instructions
Safety Instructions NOTE 1 THIS PRODUCT CONTAINS A CLASS 1 LASER OR LED FIBER OPTIC EMITTER. THE FOLLOWING SAFETY PRECAUTIONS APPLY. WARNING: Do not disconnect the fiber optic connector while the unit is powered up. Exposure to Class I invisible optical radiation is possible when the internal fiber optic connector is disconnected while the unit is powered up. -
Page 5: Introduction
1 - INTRODUCTION 1.1 General description The TKH Security USA Model 9525AY is an RS232, RS422, and RS485 compatible standalone fiber optic modem with dual optics for drop and insert applications that can be configured in a wide range of poll/response network architectures. -
Page 6: Physical Specification
TX2/RX2 9525AY/SM-ST 09/125 1310 nm 1550 nm 26 dB 9525AY/SM-FC 09/125 1310 nm 1550 nm 26dB Range based on 0.5 dB/km at 1310 nm and for 9/125 um fiber. Range includes a 3 dB safety margin. Substitute 9521 for 9525 to order the rack mount card version. - Page 7 1.4.3 SYSTEM PERFORMANCE Data rates 150, 300, 600, 1.2k, 2.4k, 3.6k, 4.8k, 7.2k, 9.6k, 14.4k, 19.2k, 28.8k, 38.4k, 57.6k, and 115.2k baud (auto baud) Re-timing accuracy 0.02% of pulse width for repeated signals Electrical anti-streaming timeout selections DISABLED, 4, 8, 16, 32, and 64 sec 1.4.4 ALARM Contact Rating 15 VDC @ 15 mA...
- Page 8 1 — 9525AY D IGURE IMENSIONS...
-
Page 9: Installation
2 - INSTALLATION 2.1 System Architecture The Model 9525AY can be configured into three basic network architectures with almost unlimited variations. Typically the rack mountable Model 9521Y is used at the central hub. The standalone Model 9525AYs are used at the remote (local) locations. However, either modem can be used in either installation if so desired. - Page 10 3 – M IGURE ULTIPLE AISY HAIN RUNKS WITH ASTER ONTROLLER...
- Page 11 The same cable and the Model 9525AY may be installed into the expansion port of any modem along the trunk in order to establish a single or double branch from that trunk. Additional branches can be made off of these branches, etc., without limit. NOTE: IN ALL THESE INSTALLATIONS, THE TX1/RX1 PORT WILL BE CONNECTED TO THE FIBER GOING UPSTREAM TO THE CONTROLLER AND THE TX2/RX2 PORT WILL BE CONNECTED TO THE FIBER GOING TOWARDS THE FAR END OF THE TRUNKS OR BRANCHES.
- Page 12 4 – F IGURE AULT OLERANT ING WITH AISY HAIN BRANCHES...
-
Page 13: Modes Of Operation
2.1.3 Fault Tolerant Redundant Ring With the architecture of Figure 4, all modems are arranged along a dual fiber ring, starting with the master controller modem (operating in Master Fault Tolerant mode), looping through an indeterminate number of local terminal modems (operating in Local Fault Tolerant mode), and terminating back into the second set of optical ports of the master controller modem, completing the ring. - Page 14 5 – I IGURE NTERNAL IGNAL OUTING FOR 2.2.2 Local Daisy Chain Mode In this mode, there is a specific "upstream" and "downstream" data direction, because data is only transmitted to or from the master and not both directions on a ring. Specifically, the TX1/RX1 port communicates upstream to the master controller and the TX2/RX2 port communicates downstream to the next modem on the daisy chain.
-
Page 15: Operational Features And Considerations
2.2.3 Master Fault Tolerant Mode This mode is virtually the same as the master daisy chain mode explained in Section 2.2 with these exceptions: Because this is a fault tolerant mode, data will normally be received via both optical ports, skewed slightly in time of arrival. - Page 16 2.3.2 Optical Side Anti-streaming The optical side anti-streaming feature, when enabled, disconnects an optical receiver from the circuit in the event that the receiver's output goes high for a period longer than would be expected in normal data flow. This may occur due to a receiver failure, a transmitter or terminal equipment failure, or if the receiver input is left open to strong ambient light (850 nm versions only).
- Page 17 prevented from seizing the priority. This feature will allow guaranteed priority for the shortest transmission path around the ring as long as the propagation time around the ring is less than 12 ms. This is equivalent to a ring 500 km long with 500 repeating modems in the path. In the event of a failure of the data path with has current priority, a wait of at least 12 ms must occur before the other transmission path is selected.
-
Page 18: Set-Up Procedures
2.4 Set-Up Procedures The Model 9525AY has an 8-position and a 10-position dipswitch accessible via the rear panel. Program each of these switches upon installation as required for your chosen network configuration and feature set. Note that all optional operational features controlled by the TIMEOUT dipswitch are disabled when switches 1 through 6 are in the down position. -
Page 19: Mounting
Table 3 – Mode and Interface Select Switches 2.5 Mounting 2.5.1 Standalone Mounting The model 9525AY can be mounted directly to a flat surface using the attached mounting plate. The mounting plate attaches to the bottom of the unit using four screws. Use the oval holes in the plate to mount the unit to the flat surface. -
Page 20: Optical Cabling
2.5.2 System 9000 chassis mounting The 9252AY can alternately be mounted in a Model 9001 chassis. Nine units will fit in one 9001-0 chassis, eight will fit in a 9001-1 chassis and seven will fit in a 9001-2 chassis. Remove and save the 4 screws holding the surface mounting plate to extrusion. -
Page 21: Electrical Cabling
ST OPTICAL CONNECTION Align the key and the bayonet slots on the ST connector with the keyway and the bayonets of the ST optical port. Slide the connector ferrule into the port until the key and bayonets are engaged. Push the coupling nut forward until it can be turned clockwise to lock the connector into the port. - Page 22 Table 4 – RS232 Pinouts on DB25S Connector Pin # Identification Input/Output to modem and auxiliary information. Transmit Data (TD) Input to model 9525AY Receive Data (RD) Output from model 9525AY Request to Send (RTS) Input to model 9525AY Clear to Send (CTS) Output from model 9525AY Normally high, goes low if there is a fault (FAULT Data Set Ready (DSR)
-
Page 23: Power Wiring
Table 6 – RJ12 Expansion Port Pinouts Signal Ground Transmit Data (TD) Input Receive Data (RD) Output +1 vdc output under primary power. Output Battery voltage if operating under battery back-up. 2.8 Power Wiring 2.8.1 DC POWER SOURCE CONNECTION Connect the DC power source as required per the Specification, Section 1.4, to the two PWR screw terminals on the front panel. -
Page 24: Operation
3 - OPERATION 3.1 Turn on Procedure Supply primary power to the unit. Enable the internal battery if applicable. 3.2 Indicator Light Interpretation Table 7 – Indicator Light Interpretation Indicator Color INDCTR Function Switch POWER AMBER This indicator is steadily ON in the presence of primary DC or AC power, if your unit has an optional battery, this indicator will blink while being powered by the battery (discharge mode). - Page 26 TKH Security Solutions www.tkhsecurity.com Siqura B.V. TKH Security Solutions USA Zuidelijk Halfrond 4 • 2801 DD Gouda 12920 Cloverleaf Center Drive • Germantown The Netherlands Maryland 20874 USA Telephone: +31 182 592 333 Telephone: +1 301 444 2200 Fax: +31 182 592 123 Toll Free: +1 800 293 4237 E-mail: sales.nl@tkhsecurity.com...
