Physical Specification; Environmental Specification - Optelecom 9525A Installation And Operation Manual

The unit operates from a 9 to 15 VDC supply. The unit contains a built in battery charger compatible with a 6-
volt lead-acid gel cell battery (1.2 Amp-hour to 7 Amp-hour capacity). This battery allows from 6 to 35 hours
of emergency battery backup operation. A screw terminal connector allows the unit to connect the battery to
the unit.
The package is an anodized aluminum extrusion with painted aluminum front and rear panels. An optional
mounting kit is available for mounting in a System 9000 chassis (Model 9000KIT-5).
Table 1 - Models Available
MODELS OPTIC
PORT
9525A-S-ST ST
9525A-L-ST ST
9525A -LD-ST ST
9525A-LD-FC FC
9525A-LD3-ST ST

1.2 Physical Specification

DIMENSIONS
INCHES
WEIGHT
INDICATORS

1.3 Environmental Specification

TEMPERATURE
Operating
Storage
HUMIDITY
FIBER
62.5/125 µm
62.5/125 µm
09/125 µm
09/125 µm
09/125 µm
Height
1.5
0.875 lb. 0.4 kg
POWER, TD/TX1, RD/RX1, RTS/TX2, CTS/RX2, TDEXP/RX1
PRIORITY, RDEXP/RX2 PRIORITY, BERT, and FAULT.
Fahrenheit
-40 to 165° F
-40 to 185° F
0 to 95% RH noncondensing
WAVELENGTH OPTICAL
BUDGET
850 nm
1310 nm
1310 nm
1310 nm
1550 nm
Width Length
3.17 5.0
Celsius
-40 to 74° C
-40 to 85° C
10
22 dB
21 dB
23 dB
23 dB
23 dB
