Summary of Contents for Pixio PX245c
-
Page 2: Table Of Contents
Content Table of Contents Warnings ------------------------------------------- 2 Instructions ------------------------------------------- 3 Content ------------------------------------------- 3 Installation ------------------------------------------- 4 Inputs Guide ----------------------------------- 5 Operating ------------------------------------------- 6 OSD Guide ------------------------------------------- 8 Tech Support ------------------------------------ 9 Specification ------------------------------------10... -
Page 3: Warnings
Warning Make sure the monitor is not near a water source, such as: the bathroom, kitchen, dish-washer, swimming pool, or a humid basement. Do not place the monitor on an uneven surface, as the curvature of the monitor makes it more susceptible to damage by tipping over or dropping flat. - Page 4 Do not use abrasive materials as it will cause permanent damage to the panel. Be careful of liquid exposure to the monitor, as it will likely destroy the components. Instruction before use Packing List Package contains the following items: LED Monitor Power Adapter User Manual DisplayPort Cable Stand Set Pixio Sticker...
-
Page 5: Instructions
Installation Instructions 1. Open the package and lay the foam flat down on the side without the accessories 2. Remove the top foam piece, with the accessories, and let the monitor sit in the bottom foam 3. Place the stand neck on top of the metal bracket and secure it with two of the screws provided 4. -
Page 6: Installation
Installation & disassembly instructions 5. When moving the monitor, hold it by the stand neck and support it by the bottom of the screen. Power: 1. Please make sure the power adapter is compatible with your local power standards. 2. The voltage of the LED monitor is wide and can be applied to 100/120 VAC or 220/240 VAC standards. -
Page 7: Operating
Operating Instructions On Screen Display Buttons Monitor Button Operation Function Description Button Menu Button Show OSD and select menu item Direct the cursor down or decrease the OSD item / double click to Down Button toggle through crosshairs Direct the cursor up or increase the OSD item / double click to Up Button toggle through pre-set modes Exit Button... - Page 8 BRIGHTNESS B R I G H T N E S S C O N T R A S T E C O S TA N D A R D D C R O F F OSD window Factory preset mode table Resolution H-Freq (KHz) V-Freq(Hz)
- Page 9 OSD Interface Main Menu Item Main Menu Icon Sub-menu Options Description Brightness 0-100 Adjust display brightness Contrast 0-100 Adjust display contrast ratio Standard Normal use mode Game Game application mode Brightness Movie Movie application mode Text Text application mode First person shooter application mode Real time strategy application mode On / Off Dynamic contrast ratio...
- Page 10 Plug and Use The monitor conforms to VESA DDC2B under VESA DDC. The monitor will provide a model number to the connected PC and transfer other data under DDC standards. DDC2B conforms to the dual data channel communication of I²C. PC’s can get the EDID information through a DDC2B channel. If there is no input signal, the monitor will not function.
-
Page 11: Specification
Specification Product code S3C7G Screen size 23.6'' 60.96cm diagonal line Visual size Viewign angle 178° (H)/ 178° (V) Dot pitch 0.27156(H)x0.27156(V) Display area 521.3952(H)mm*293.2848(V)mm Max resolution 1920*1080@144Hz Display colour 16.7M Signal Input DP; HDMI*2 Power DC 12 Speaker Power consumption Normal work≤60W, Power≤0.5W Plug and use DDC1/2B... - Page 12 Certification of Qualification Product: Monitor Inspector: Manufacturing date: The monitor passed the inspection by quality department, and the performance confirms to technical standards. Delivery from factory is allowed...
