Functions of the Deskmaster PC Application*
Phone book/ Database entries mapped on direct dialing keys.
Address Database Configurable address/phone book database. Additional phone
books can be created or existing ones can be linked (e.g. from a
LAN). Up to 100 entries can be downloaded into the Deskmaster.
Communication Registration of:
Journal Call status, call type, incoming/outgoing calls,
calling partners' numbers/names, duration, charges,
notes associated to the phone call.
Several filter/sort/search criteria.
Call List • Programming future phone calls;
Scheduler • Reminder/alarm;
• Rescheduling of phone calls (dayly/weekly/monthly).
Dialing from • Dialing from Windows™-/Office documents;
the PC • Automatic redial facility (power dialer, programmable intervals);
• Extended redial facility (list of the last 20 call attempts to differ-
ent subscribers);
• Direct dialing from journal, phone books, etc.
Caller • Opening external applications or documents (e.g. WORD,
Identification EXCEL) on incoming calls, before the call is answered;
(ISDN calls) • Automatically generate notes on incoming and outgoing
calls with date/time stamp and caller information from
the internal database;
• Transmit call information to external applications.
Group Listening, With the ISDN phone controlled from the PC screen,
Hands Free the hands free facility is automatically switched on at call estab-
lishment.
Call Diversions Diversion of the calls addressed at your phone to another sub-
scriber or extension.
Call Hold (Broker, During a conversation, you can put your call on hold to start a
Conference) second call with another subscriber. You can then switch
between both calls or establish a 3 party conference.
* Not all functions are available in the supplied basic version.
54
Deskmaster

Data Access with Modem Commands

The Deskmaster may be controlled with AT commands, similiar to an analog modem. This
may control call setup and also data/file transfers with a variety of standard PC programs
(such as HyperTerminal, provided with Windows '95).
Except for the commands "A/" and the Escape sequence "+++", all commands will start with
the characters AT . The command A/ may be used to repeat the last command.
The maximum length of a command line contains 40 characters, including the line separa-
tors (CR/LF). An invalid character in a command line will be ignored.
Several AT commands may be transmitted within one command line:
ATZX1D1234<CR>
has the same effect as
ATZ<CR>
ATX1<CR>
ATD1234<CR>
The AT command set of the Deskmaster has been extended by some commands. This is
mainly applicable for voice functions.
The Deskmaster will respond to most commands with a result code.
(See Appendix for a list of supported commands.)
