bintec elmeg GmbH
bintec RS Series
Property
SAFERNET TM Security Technology
Antennas and sockets
bintec RS353j
Property
WLAN interface -
(antennas)
LTE - UMTS anten- -
nas
GPS antennas -
Available sockets:
Ethernet interface RJ45 socket (yellow)
Ethernet interface RJ45 socket (white)
VDSL/ADSL RJ45 socket (gray)
ISDN BRI interface RJ45 socket (black)
USB USB-Anschluss type A
USB Console USB socket type B

1.1.6 Reset

If the configuration is incorrect or if your device cannot be accessed, you can reset the
device to the ex works standard settings using the Reset button on the back of the device.
All the existing data will be deleted if you do this.
Proceed as follows:
(1) Switch off your device.
(2) Press the Reset button on your device.
(3) Keep the Reset button on your device pressed down and switch the device back on.
(4) After the LED has flashed five times, release the Reset button.
bintec RS353j bintec RS353jw
,
RS353j-4G
CE symbol for all EU states
Community passwords, PAP, CHAP, MS-CHAP, MS-
CHAP v.2, PPTP, PPPoE, PPPoA, Callback, Access Con-
trol Lists, CLID, NAT, SIF, MPPE Encryption, PPTP En-
cryption, VPN with PPTP or IPSec
bintec RS353jw
802.11a/b/g/h; 802.11n
2.4 GHz and 5 GHz;
2 TX, 2 RX (2x2)
Channel level (2.4 GHz /
5GHz)
RSMA socket
-
-
RJ45 socket (yellow)
RJ45 socket (white)
RJ45 socket (gray)
RJ45 socket (black)
USB-Anschluss type A
USB socket type B
1 Installation
bintec
and
bintec RS353j-4G
-
SMA socket
SMA socket
RJ45 socket (yellow)
RJ45 socket (white)
RJ45 socket (gray)
RJ45 socket (black)
USB-Anschluss type A
USB socket type B
