Instruction Manual
AUR2K-SW AurorA2000 Switcher
Warning: To reduce a risk of fire or electric shock, do not
expose this product to rain or moisture.
Vicon Industries Inc. does not warrant that the functions contained in this
equipment will meet your requirements or that the operation will be entirely
error free or perform precisely as described in the documentation. This
system has not been designed to be used in life-critical situations and
must not be used for this purpose.
Copyright © 2003 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com
Vicon Part No. 8009-8097-00-02
XX097
Rev 803 Section 5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vicon AurorA2000
Summary of Contents for Vicon AurorA2000
- Page 1 Warning: To reduce a risk of fire or electric shock, do not expose this product to rain or moisture. Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation.
-
Page 3: Table Of Contents
Wiring to the “To A2K-KBD Keypad” Connector ..................3 Wiring to the “To AurorANet” Connector ......................4 Operation ..........................6 Troubleshooting ........................6 LED Indications.............................6 Maintenance ........................6 Fuse Replacement............................6 Storage ................................7 Reference..........................7 Coaxial Cable Recommendations ........................7 Technical Information ......................8 Shipping Instructions ......................9 Contents • i XX097-00-02 Rev 803 AurorA2000 Switcher... -
Page 4: Quick Installation
(not end-of-line) AurorA2000 Up to 16 AurorA2000s and Resistors Installed (As Is) AurorAcorDs connected in any order DATA– DATA + COM1 or COM2 MECHANICAL PAN TILT ZOOM AurorANet Termination Box AurorA2000 (end-of-line) ii • Quick Installation XX097-00-02 Rev 803 AurorA2000 Switcher... -
Page 5: Introduction
Introduction The information in this manual covers installation of the AUR2K-SW AurorA2000 Switcher. Each switcher allows 4 keypad operators to view the monitor output (main display and spot monitors) of up to 16 AurorA2000 Digital Multiplexers and/or AurorAcorD Digital Recorders. Keypads available for use with the switcher are the A2K-KBD AurorA2000 Remote Keyboard and V1400X-DVC-3 System Console. -
Page 6: Keypad Power Requirements
Connect the spot and main display BNCs of AurorA2000 1 to the switcher spot monitor BNC 1 and main display BNC 1. Spot and main display BNCs of AurorA2000 2 must be connected to the switcher spot monitor BNC 2 and main display BNC 2, and so forth. -
Page 7: Wiring To The "To A2K-Kbd Keypad" Connector
“To AurorANet” connector. External power is supplied to the local A2K-KBD (or A2K-KBD-230) keyboard from the switcher. Refer to Instruction Manual XX081 for more information on the A2K-KBD. Installation • 3 XX097-00-02 Rev 803 AurorA2000 Switcher... -
Page 8: Wiring To The "To Auroranet" Connector
Make connections between AurorANet devices by connecting like signals together (all RS-485 Data+ lines together and all RS-485 Data- lines together). Wiring from the switcher to the AurorAcord, AurorA2000 and A2K-KBD keyboards is performed using the AurorANet termination box (supplied with AurorA2000 and AurorAcorD units) and the A2K-KBD termination box (supplied with the A2K-KBD). - Page 9 Up to 16 AurorA2000s and Resistors Installed (As Is) AurorAcorDs connected in any order DATA– DATA + COM1 or COM2 MECHANICAL PAN TILT ZOOM AurorANet Termination Box AurorA2000 (end-of-line) Sample System Configuration Installation • 5 XX097-00-02 Rev 803 AurorA2000 Switcher...
-
Page 10: Operation
You must reselect AurorA2000/AurorAcorDs after power fails or is initially applied to the switcher. This is required because the default routing is AurorAcorD 1 (or AurorA2000 1) to spot monitor 1 and main display 1, AurorAcorD 2 (or AurorA2000 2) to spot monitor 2 and main display monitor 2, and so forth. •... -
Page 11: Storage
Coaxial Cable Recommendations Caution: Careful selection of proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended, or equivalent, are installed. In all cases, coaxial cable impedance should be 75 ohms. -
Page 12: Technical Information
IEC320 recessed three-pin male connector with built-in fuse tray. Fuse holder orientation dictates input voltage. Video Input: 32 BNC connectors (16 for AurorA2000/AurorAcorD spot monitors, 16 for AurorA2000/AurorAcorD main display monitors). Video (Monitor) Outputs: 8 BNC connectors (4 for spot monitors, 4 for main display monitors). -
Page 13: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. - Page 14 Vicon Industries Inc. Offices Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Infofax: 800-287-1207 Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322...
