Matrix 44
Video Switch
Card & Associated
Components
The V4410S-1 video switch card can accommodate up to 8 video inputs per card. Each card
cage can accommodate up to 16 V14410S-HD cards, for 128 inputs by 8 outputs. Associated
components identified in this document include rear panels V4411RP-BNC and V4411RP-RIB,
terminators V75T-1 and V75TR-1, and coaxial ribbon cables V44RC-21-1 and V44RCB-12-1.
Warning: Disconnect power from all units. The Matrix 44 card cage power switch can be
accessed by loosening the four captive screws on the front panel of the card cage.
Do not apply power until all procedures are complete and all connections made.
Setting DIP Switches
1. Using a static-free work surface, loosen the captive screws on the front panel of the Matrix 44
card cage containing the expander card.
2. The video switch cards are located at the extreme left of the card cage, as viewed from the
front of the card cage. Locate DIP switch U7 on the video switch card.
3. Set the DIP switch on each card, using the following table. Reseat the cards in the cage and
tighten the captive screws to secure the front panel when finished.
X783-20-00 Rev 904
Refer to X783
V4410S-HD DIP Switch U7 Pole Settings
Cameras
1
2
1-8
OFF
OFF
9-16
ON
OFF
17-24
OFF
ON
25-32
ON
ON
33-40
OFF
OFF
41-48
ON
OFF
49-56
OFF
ON
57-64
ON
ON
65-72
OFF
OFF
73-80
ON
OFF
81-88
OFF
ON
89-96
ON
ON
97-104
OFF
OFF
105-112
ON
OFF
113-120
OFF
ON
121-128
ON
ON
129-136
OFF
OFF
137-144
ON
OFF
145-152
OFF
ON
153-160
ON
ON
161-168
OFF
OFF
169-176
ON
OFF
177-184
OFF
ON
185-192
ON
ON
193-200
OFF
OFF
201-208
ON
OFF
209-216
OFF
ON
217-224
ON
ON
225-232
OFF
OFF
233-240
ON
OFF
241-248
OFF
ON
249-256
ON
ON
Matrix 44 Video Switch Card & Associated Components • 1
NOTES
NO.
X783-20-00
3
4
5
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
ON
OFF
ON
ON
OFF
ON
ON
OFF
ON
ON
OFF
ON
ON
OFF
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
ON
ON
OFF
ON
ON
OFF
ON
ON
OFF
ON
ON
OFF
ON
OFF
ON
ON
OFF
ON
ON
OFF
ON
ON
OFF
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
REV.
SEC.
904
2
