Vicon PILOT SELECT V1566 Programming Manual

Digital control and matrix switching system
Hide thumbs Also See for PILOT SELECT V1566:
Table of Contents

Advertisement

Quick Links

Download this manual
XX190-10-01
V1566 DIGITAL CONTROL AND
MATRIX SWITCHING SYSTEM
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet
your requirements or that the operation will be entirely error free or perform precisely as
described in the documentation. This system has not been designed to be used in life-critical
situations and must not be used for this purpose.
Copyright © 2008 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
ViconNet and its logo are trademarks of Vicon Industries Inc.
Pilot Select and its logo are trademarks of Vicon Industries Inc.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 WEB: www.vicon-cctv.com
Vicon Part No. 8006-8190-10-01
Rev 0508 Section 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PILOT SELECT V1566 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vicon PILOT SELECT V1566

Summary of Contents for Vicon PILOT SELECT V1566

  • Page 1 V1566 DIGITAL CONTROL AND MATRIX SWITCHING SYSTEM Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
  • Page 3 The product shows a significant change in performance. 6. Attachments - Use only Vicon recommended attachments to 20. Replacement Parts - Use only Vicon specified replacement prevent unit damage and personal injury.
  • Page 4 FCC Notice NOTE: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class A digital device. WARNING This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception.
  • Page 5 Important Notice This manual is delivered subject to the following conditions and restrictions: This manual contains proprietary information belonging to Vicon. Such information is supplied solely for the purpose of assisting explicitly and properly authorized users of the Vicon system.
  • Page 6 vi • XX190-10-XX Pilot Select...

  • Page 7: Table Of Contents

    Contents CONTENTS ........................VII INTRODUCTION........................1 Related Publications ............................2 Glossary ................................3 PRELIMINARY OPERATIONS REQUIRED TO PROGRAM THE SYSTEM......4 Required Connections ...........................4 NTSC/PAL Selection.............................5 Entering and Exiting the Programming Screens ..................5 SYSTEM PROGRAMMING ....................6 Common Keys and Commands Used for Programming ................6 Main Menu ...............................6 Administration ..............................7 Set User Profiles ............................8...
  • Page 8 Day of Week............................14 Monitor Number............................14 Receiver Number ............................15 Set Triggered Events ..........................15 Set Triggered Inputs..........................16 Program Triggered Events ........................16 Input Number ............................17 Event Type............................17 Pattern/Number ...........................17 Receiver Number..........................18 Monitor Number ...........................18 Keypad/Receiver............................18 Keypad Menus ............................19 Set Keypad Profiles..........................19 Keypad Number...........................19 Baud Rate............................20 Communications Delay........................20 Online State ............................20...
  • Page 9 Acknowledge Time ..........................39 Set Acknowledge Controls ........................40 Set Receiver Action ............................40 Set Alarm Enable/Disable ........................41 Set Home Acknowledge Control ......................41 Set Aux 1 Controls ..........................42 Set Input Controls ............................42 Enable Alarm Inputs ..........................43 X-IA Input Pattern ..........................43 X-IA Alarm Inputs..........................43 Set Momentary Inputs ..........................44 Momentary Pattern ..........................44 Momentary/Latching Alarms........................45...
  • Page 10 Preset Fade.............................60 Fade Time ...............................60 Video Switch Action .............................61 Edit Sequential Tour ...........................61 Tour Number ............................61 Select Tour Type .............................62 Edit Tour..............................62 Define a Monitor Tour ..........................62 Define a Salvo Tour ..........................64 Set Last Step Action..........................65 Chain To Tour............................65 Edit Salvo Switch ............................65 Assign Dial-Up Numbers ..........................66 Video Inputs ............................67 Tours ...............................68...

  • Page 11: Introduction

    Monitors per salvo - 16 Number of timed events - 64 * Tours may be chained together. The Pilot Select may be controlled by up to 16 operator keypads. The keypads may include the following Vicon products: • 1 XX190-10-XX Pilot Select...

  • Page 12: Related Publications

    Related Publications This following list of manuals provide additional information required to use the Pilot Select. Pilot Select V1566 Digital Control and Matrix Switching System Installation and Operation Manual XX190-00- XX, Part Number 8009-7190-00-XX Pilot Select V1566 Digital Control and Matrix Switching System Configurator Manual XX190-20-XX, Part...

  • Page 13: Glossary

    Glossary Keypad Input device used to control cameras, monitors …… Receiver A device used to communicate with PTZ cameras and Pan and Tilt devices. Salvo Simultaneous display of video from various camera stations on various monitors. Tour Series of preprogrammed video displays from various camera stations. Alarm Interface A device that senses a change in status from an alarm input and communicates that information to the Pilot Select.

  • Page 14: Preliminary Operations Required To Program The System

    Preliminary Operations Required to Program the System Required Connections You must connect a keyboard and monitor to the Pilot Select and power it in order to program the Pilot Select. To make the connections to the Pilot Select, refer to Figure 7 and proceed as follows: Figure 7: Pilot Select Card Cage, Programming Connections 1.

  • Page 15: Ntsc/Pal Selection

    After connecting the keyboard, monitor and power cord to the Pilot Select, apply power to the system by turning the POWER switch on the front panel on. The following screen will display: Vicon Industries Inc. Matrix-66 PowerPlus System Editor Pilot Select...

  • Page 16: System Programming

    System Programming System programming is performed from five major menus: Administration, Keypad/Receiver, Alarm Actions, Time/Date/Titler and Video Switch Action. There is also an Install Defaults menu provided for Administrator use. From the Administration menus, up to 32 users may be defined to the system by a unique login identification number.

  • Page 17: Administration

    Note: On many of the programming screens, you will see “x / -” at the bottom of the screen. The “x / -” instructions refer to the plus (+) and minus (-) keys, respectively, on your programming keyboard. Administration The Administration Menus are used to specify supervisory parameters such as user privileges, host computer configuration and timed events.

  • Page 18: Set User Profiles

    Set User Profiles User profiles contain the information necessary to identify each user in the system. The three privilege levels are Operator, Manager, and Administrator. Operator privileges allow a user to operate the system but do not allow access to programming screens. Typically, a configuration will contain more users with operator privileges than with manager or administrator privileges.

  • Page 19: Privilege

    Privilege A privilege level must be specified for each user login ID. The system accepts up to 64 users, 3 of which may have administrator privilege. Administrators may access all programming screens. Managers may access all programming screens except for the Administration, System Diagnostics, and Install Default Menus. Users with operator privilege are denied access to all programming screens.

  • Page 20: Passcode

    Passcode A login ID must be entered each time the system is accessed. If the user has administrator privilege, a passcode must also be entered. The passcode is used to provide a second level of access security to the programming menus and must be 10 digits or less. Passcodes are not required for Managers or Operators. Settings: 10-digit number Keys:...

  • Page 21: Configure Host Port

    Configure Host Port The HOST port located on the rear connector of the Pilot Select is typically connected to a personal computer (the “host computer”). Unless the PC is running software that automatically detects the communication settings, the PC’s communication settings must be defined. The settings for the host computer and the Pilot Select must agree.

  • Page 22: Stop Bits

    Stop Bits The stop bit is the number of bits used to signal the last bit in a data character. The setting chosen here must be the number of stop bits specified at the host computer. Settings: Keys: Numeric keypad’s + (plus) key or - (minus) key Default: Parity The parity setting chosen here and at the host computer must agree.

  • Page 23: Program Timed Events

    Program Timed Events Five timed event types are programmable in the software: Tours, Salvos, Presets, Alarm Enable, and Alarm Type. The first three event types specify the method of video switching to be performed. Alarm enable and alarm type events control which alarm patterns are enabled and which will operate as momentary. →...

  • Page 24: Pattern/Number

    Pattern/Number Events are identified using the event number setting. Events are further differentiated using a pattern or number identifier. Alarms may be grouped in patterns A, B, or C. Tours, salvos, and presets are identified using a number. For example, preset 01 may be event 10. Settings: Presets: 001 to 080...

  • Page 25: Receiver Number

    Note: Receiver Number setting is only displayed when the event type is Preset. Receiver Number Preset numbers are not unique within the CCTV system. For example, every receiver might include ten presets numbered 01 to 10. Therefore, in order to identify a particular preset position, both preset number and receiver number must be specified.

  • Page 26: Set Triggered Inputs

    Set Triggered Inputs Select the X-IA inputs that will be used to activate triggered events. These inputs may not be used to activate alarms and will be unavailable on the Edit Alarm Call-Up screen. Use the ↑ or ↓ key to access all inputs; 256 X-IA inputs are available.

  • Page 27: Input Number

    PROGRAM TRIGGER EVENTS INPUT NUMBER PRESET EVENT TYPE PATTERN/NMBR RECEIVER NO. CURSOR UP/DWN x /- CYCLE CHOICE ENTR/ESC STORE/ABORT Input Number The X-IA input numbers available for this menu item are the inputs that were enabled. The event type and other items on this screen must be defined for each X-IA input number.

  • Page 28: Receiver Number

    Receiver Number The maximum number of receivers in the system is 256. You must define the receiver to be used when the Event Type is set to Preset. For example, each receiver will typically have at least one programmed preset position and you need to differentiate between the preset 1 for each of the receivers.

  • Page 29: Keypad Menus

    Keypad Menus Baud rate, priority level, partitioning, and other required settings must be defined for each keypad in the CCTV system. Using the programming keyboard, enter the number of a selection. → → Menu Path: Main Menu Keypad/Receiver Keypad Menus KEYPAD MENUS 1) SET KEYPAD PROFILES 2) SET KYPD PARTITIONS...

  • Page 30: Baud Rate

    Baud Rate The baud rate defines the speed of data transmission between the keypad and the system. The baud rate for the HOST RS-232 port is 19.2K BPS unless it was defined differently. “N/A” will display if keypad 17 is selected).

  • Page 31: Priority Level

    Priority Level A priority level should be assigned to each keypad in the system. The system uses priority levels to rank the ability of each keypad to seize control of a camera station from another keypad. If the Seize Enable setting is set to Enabled, any keypad may take control of a camera station currently being controlled by a keypad with a lower priority level.

  • Page 32: Set Keypad Partitions

    Set Keypad Partitions Monitor-to-keypad partitioning assigns selected monitors to the keypad specified in the Keypad Number setting at the top of the screen. Monitor numbers (01-64) are listed onscreen. The cameras which are partitioned to a monitor may be controlled from keypads which include this monitor number in the partition list of numbers.

  • Page 33: View Keypad Status

    View Keypad Status The status of all remote keypads may be viewed in the Current Keypad Status screen. The currently-selected monitor (MON) and camera (CAM) are listed to the right of the keypad (KYPD) identifier. The possible status (STAT) displays are listed in Table 2. The user (USR) number is identified on the extreme right of the screen. This screen displays only the current status of all remote keypads.

  • Page 34: Receiver Menus

    Receiver Menus Communication parameters may be set for every receiver in the system or the defaults may be used. A Receiver is a device used to communicate with PTZ cameras and Pan and Tilt devices. Receiver profiles may be defined by entering “1” from the programming keyboard. To view the status of all receivers in the system, enter “2”.

  • Page 35: Baud Rate

    Baud Rate The baud rate is the speed of data transfer between the receiver and the system. The baud rate specified at the receiver and on this programming screen must agree. At the receiver, baud rates are set using the appropriate DIP switch on a printed circuit board.

  • Page 36: Communications Delay

    Communications Delay The communications delay (COMM. DELAY) time is the length of time that the system will wait before assuming that a receiver is off-line. This provides the delay time needed if a modem is connected to the receiver jack. Settings: 000 to 990 msec, in 10 msec increments Keys:...

  • Page 37: View Receiver Status

    View Receiver Status The status of all receivers is shown on this screen. Table 3 lists the three status descriptors. A list of the monitor(s) displaying video from the receivers is also available onscreen. Press Escape to return to the previous menu.

  • Page 38: Alarm Actions

    Alarm Actions The alarm actions available with the system provide versatile responses to activated alarms while maintaining simple alarm programming procedures. There are 256 alarms available from receivers and 256 alarms available from alarm interface devices (V1200X-IA or V1300X-IA). If either alarm, associated with a particular input number activate, both will activate.

  • Page 39: Monitor Stack Mode

    Monitor Stack Mode An alarm monitor stack is a list of active alarms. The order in which alarms are added to the stack is defined in Alarm Input Order (Common Stack Mode Only) or Alarm Order (Independent Stack Mode Only). The monitor stack mode chosen determines whether one stack will be used for all monitors or if each monitor will have its own stack.
  • Page 40 Video from Video from Video from camera station camera station camera station 01 at preset 01 20 at preset 02 10 at preset 01 Video from Video from Video from camera station camera station camera station 15 at preset 02 20 at preset 01 25 at preset 14 1 2 3...

  • Page 41: Independent Stack Mode Only (Alarm Order)

    Independent Stack Mode Only (Alarm Order) In independent stack mode, each monitor has its own stack, as shown in Figure 8. Functions that affect display order act upon individual alarm monitors. For example, acknowledging alarm video removes it from the stack of the alarm monitor that is displaying the alarm video, but does not affect the stacks of any other alarm monitors unless specifically programmed to do so.
  • Page 42 Video from Video from Video from camera station camera station camera station 01 at preset 01 20 at preset 02 10 at preset 01 Video from Video from Video from camera station camera station camera station 15 at preset 02 20 at preset 01 25 at preset 14 ALARM...

  • Page 43: Alarm Input Order (Common Stack Mode Only)

    Alarm Input Order (Common Stack Mode Only) If common stack mode is chosen for the monitor stack mode, there is only one stack for all alarm monitors. The order in which alarms are added to the stack may be FIFO (first in, first out), which adds alarm video to the stack in the order in which the alarms were activated, or Sort By Priority, which adds alarm video to the stack in an order defined by priority.

  • Page 44: Set Alarm Acknowledge Mode

    Set Alarm Acknowledge Mode If common stack mode was chosen, acknowledging an active alarm will remove that alarm from the common stack. Therefore, the following screen will display if Set Alarm Ack. Mode is chosen from the menu shown in Set Alarm Actions.

  • Page 45: Set Alarm Priority

    Set Alarm Priority Priority levels are used to define a relative scale of importance to alarms, allowing alarms to be added to the monitor stack in order of priority level. → → → Menu Path: Main Menu Alarm Actions Set Alarm Actions Set Alarm Priority SET ALARM ACTIONS ALARM INPUT NO.: 001...

  • Page 46: Set Monitor Actions

    → → → Menu Path: Main Menu Alarm Actions Set Alarm Actions Edit Alarm Call-Up ALARM INPUT NO.: 001 PRE. AUX 1 CAM. ENTER/ESC - STORE/ABORT Settings: Cam: 000 to 256, NC Pre: 00 to 80 Aux 1: On, Off, NC Keys: Numeric keypad’s + (plus) key or - (minus) key Set Monitor Actions...

  • Page 47: Set Alarm Controls

    Note: Only 32 of the 64 available monitors may be selected as Alarm Monitors. Any of the 64 monitors may be designated as an Alarm Monitor with the exception of the monitor(s) selected for High Speed Switching. Use the cursor keys to scroll through the list. →...

  • Page 48: Alarm Monitor Number

    ALARM MONITOR CONTROLS ALARM MONITOR NO. FIFO ALARM ORDER SEQUENCE ENABLED DWELL TIME 004 SECS AUTO ACK. ENABLED ACK. TIME 010 SECS x / - CYCLE CHOICE CURSOR UP/DWN ENTR/ESC STORE/ABORT Alarm Monitor Number All settings on this screen refer to the alarm monitor specified at the top of the screen. For independent stack mode, the setting list will include all monitors that were enabled as alarm monitors.

  • Page 49: Sequence

    Sequence Alarm monitors may be set to sequence multiple active alarm video or to display an alarm steadily until acknowledged, in the order determined in Alarm Input Order (Common Stack Only) or Alarm Order (Independent Stack Only). Choose Enabled to sequence the video from multiple active alarms on the alarm monitor specified at the top of the screen.

  • Page 50: Set Acknowledge Controls

    Set Acknowledge Controls The acknowledge action specifies the action to take place after all alarms in the monitor stack are acknowledged. The Restore setting restores prealarm video. The Blank setting displays a blank monitor (no video signal) and the No Action setting leaves the video from the alarm site on the monitor. Use cursor keys to scroll through list.

  • Page 51: Set Alarm Enable/Disable

    Set Alarm Enable/Disable Receiver alarms must be enabled in order to be processed by the system. Note: Vicon recommends that X-IA alarms (not receiver alarms) be used for critical surveillance areas. → → → Menu Path: Main Menu Alarm Actions...

  • Page 52: Set Aux 1 Controls

    Set Aux 1 Controls When an active receiver alarm has been acknowledged, the receiver may be preprogrammed to return to the home position and to control AUX1. The settings are On (which turns AUX1 on), Off (which turns AUX1 off), Restore (restores AUX 1 to its prealarm state) and No Action (which leaves AUX 1 in the state defined in the Edit Alarm Call-Up screen.

  • Page 53: Enable Alarm Inputs

    Enable Alarm Inputs X-IA alarm inputs must be enabled in order to be processed. X-IA alarms may be enabled in groups referred to as patterns. Three patterns are available. The use of patterns allows X-IA alarms to operate as a group. For example, an Alarm Enable event using pattern A could be scheduled for daylight hours and pattern B could be reserved for night.

  • Page 54: Set Momentary Inputs

    Set Momentary Inputs A momentary alarm remains active only as long as the alarm switch contacts are in the position that defines an alarm. For example, some alarms are activated when the contacts close (normally open) and others when the contacts open (normally closed). If a normally-closed momentary alarm is connected to a door, the alarm is active only while the door is open.

  • Page 55: Momentary/Latching Alarms

    Momentary/Latching Alarms Define the X-IA alarms that will be part of the pattern shown in Momentary Pattern at the top of the screen. The Tab key is used to move back up to the Momentary Pattern setting so that the next pattern may be defined.

  • Page 56: Set Serial Port

    Set Serial Port The ALARM PRINTER PORT on the rear panel of the unit may be connected to a serial line printer in order to provide automatic alarm reports. → → Menu Path: Main Menu Alarm Actions Set Serial Port CONFIGURE ALARM 232 PORT BAUD RATE 19.2K BPS...

  • Page 57: Stop Bits

    Stop Bits This setting specifies the number of bits used to signal the end of a data character. The stop bits for the printer and the setting chosen in this screen must agree. Settings: Keys: Numeric keypad’s + (plus) key or - (minus) key Default: Parity The setting chosen for the parity must agree with the parity of the printer.

  • Page 58: Time/Date/Titler

    Time/Date/Titler Time, date, and titling functions are programmed using menus selected from the Display Titling Menu Titles are entered using the programming keyboard. → Menu Path: Main Menu Time/Date/Titler DISPLAY TITLING This menu item may be 1) CAMERA TITLES "Preset Titles" or "Sector 2) ALARM TITLES Titles", depending upon 3) PRESET TITLES...

  • Page 59: Camera Title Editor

    Camera Title Editor Type the title for the camera identified at the top of the screen. Camera titles usually identify the camera number and/or a description of the area viewed by the camera. Press the Enter key to store this title or Escape to abort and retain the default title.

  • Page 60: Alarm Title Editor

    Alarm Title Editor Type the title for the alarm identified at the top of the screen. Alarm titles usually identify the alarm number and/or a description of the area viewed by the camera that is in alarm. Press the Enter key to store this title or Escape to abort and retain the default title.

  • Page 61: Preset

    Preset After entering the camera number, continue to type in the number of the preset whose title is to be edited. Only the first sixteen of a camera’s presets may be titled. Settings: 01 to 16 Keys: Number keys across the top Preset Title Editor Type the title for the preset identified at the top of the screen.

  • Page 62: Sector Titles

    Sector Titles The system allows either preset or sector titles, but not both. Use the Preset -or- Sector Title Edit Enable screen to specify whether the configuration file will contain preset titles or sector titles. The wording of the third menu item on the Display Titling screen reflects the choice made in the Preset-or-Title Edit Enable screen;...

  • Page 63: Sector Title Editor

    Sector Title Editor Type the title for the sector identified at the top of the screen. Sector titles usually identify the sector number and/or a description of the area viewed by the camera as it pans through that sector. Press the Enter key to store this title or Escape to abort and retain the default title.

  • Page 64: Time/Date Controls

    Time/Date Controls The Time/Date Controls selection from the Display Titling Menu is used to perform the following functions: 1. Set the time and date. 2. Define the display format of the time and date. 3. Set the AM/PM indicator for 12-hour time format. 4.
  • Page 65 5. If the 12-hour time format was chosen in step 2 above, press the F3 key to change the AM/PM indicator (located to the right of the time; only the first letter is displayed) to the correct mode. 6. Press the Enter key to accept the specified time and date formats and set the clock. The second Set Date/Time screen will display.

  • Page 66: Display Controls

    Display Controls The Display Controls menus are used to specify the placement, size and fade of onscreen text. The time and date display, title display and seize status are also enabled or disabled. → → Menu Path: Main Menu Time/Date Controls Display Controls DISPLAY CONTROLS 1) EDIT SCREEN LAYOUT...

  • Page 67: Background/Border/None

    Small Keys: the “1” key Default: Large Background/Border/None Toggle the display of a background, a border, or the lack of background and border by pressing the “2” key on the programming keyboard. Choose the appropriate setting while viewing a title on the monitor specified in Monitor Number.

  • Page 68: Monitor Number

    Enable/Disable Displays The camera, sector and preset titles, seize status, and time/date display can be enabled or disabled for each monitor in the system. → → → Menu Path: Main Menu Time/Date Controls Display Controls Enable Displays ENABLE/DISABLE DISPLAYS MONITOR NUMBER: 03 1) DATE/TIME DISABLE 2) CAMERA TITLE...

  • Page 69: Sector Title

    Sector Title Press the “4” key to enable or disable the display of sector titles on the specified monitor. Either preset or sector titles will be available, depending upon the choice made in Preset -or- Sector. Settings: Enabled Disabled Keys: the “4”...

  • Page 70: Preset Fade

    Preset Fade Press the F2 key to enable or disable the preset title to fade from the selected monitor’s screen after the fade time elapses. Settings: Enabled Disabled Keys: Fade Time Use the programming keyboard to enter the fade time. The fade time may be 00 to 99 seconds. The same fade time applies to the camera, alarm, and preset titles if they are enabled.

  • Page 71: Video Switch Action

    Video Switch Action The Video Switch Menus are used to define tours and salvos, assign dial-up numbers and default call-up actions, and define camera-to-monitor partitioning. Although tours and salvos may be specified as settings in other menus, they must be defined in the submenus of the Video Switch Menus before any tour or salvo actions may take place.

  • Page 72: Select Tour Type

    Select Tour Type Two tour types are available, monitor and salvo. In a monitor tour, video from various cameras and various preset positions display on a selected monitor in a predefined order. Monitor selection is performed at the keypad. For example, monitor tour 1 might be defined as camera 1 preset 10 (step 1) then camera 44 preset 1 (second step).
  • Page 73 → → → Menu Path: Main Menu Video Switch Action Edit Sequential Tour Edit Tour Use cursor keys to scroll through the list. TOUR NUMBER : 001 PRE. SPD. DWL. STEP CAM. Settings: Step: 00 to 32 Camera: 000 to 256 Preset: 00 to 80 Speed:...

  • Page 74: Define A Salvo Tour

    Define a Salvo Tour Salvo tours must be defined by specifying the salvo to be activated for each step in the tour. Each step of the tour defines the actions to take place at a relative time in the tour. For example, step 3 is performed after step 2 and before step 4.

  • Page 75: Set Last Step Action

    Set Last Step Action The action that will take place when the final step in a tour has been performed is defined as the last step action. Three last step actions are possible: another tour may activate (Chain), all touring may cease (Halt), or the tour may repeat (Repeat).

  • Page 76: Assign Dial-Up Numbers

    Pilot Select systems with only one card cage have two possible configurations: 256 cameras and 16 monitors, or 256 cameras and 32 monitors. A two card cage Pilot Select system has a maximum size of 512 cameras and 64 monitors. Any of these 64 monitors may be used in each salvo, for a total of 16 monitors per salvo. A maximum of 64 salvos may be defined.

  • Page 77: Video Inputs

    ASSIGN DIAL-UP NUMBERS SET DIAL-UP ASSIGNMENTS FOR: 1) VIDEO INPUTS 2) TOURS 3) SALVOS ENTER SELECTION ESC - PREVIOUS MENU Video Inputs The system limits the programmer to the range of numbers between 001 and 512 for camera station identification. It may be convenient to use a number which is outside that range during operation (non- programming).

  • Page 78: Tours

    Tours The maximum number of tours is 128. Any dial-up number may be assigned in order to identify tours with a customized numbering scheme. → → → Menu Path: Main Menu Video Switch Action Assign Dial-Up Nmbrs Tours ASSIGN DIAL-UP NUMBERS ASSIGN DIAL-UP NUMBERS INPUT SOURCE DIAL-UP...

  • Page 79: Set Default Call-Up

    Set Default Call-Up The default call-up specifies the condition of each monitor in the CCTV system when power is applied. → → Menu Path: Main Menu Video Switch Action Set Default Call-Up MONITOR DEFAULT CALLUP MONITOR NUMB. ACTION CAMERA SELECT NUMB. HOME RECALL ENABLED x / -...

  • Page 80: Home Recall

    Home Recall Camera stations may be directed to the home position when the system is powered or rebooted, by enabling the home recall function in this screen. The home position is preset position 01 for all camera stations. Note that this setting is only onscreen if Action is set to Camera. Settings: Disabled Enabled...

  • Page 81: Partitioning Cameras To Monitors

    Partitioning Cameras to Monitors By default, all cameras are assigned to all monitors. Video from camera stations may not be displayed on monitors unless the camera stations are partitioned to those monitors. The monitor number is identified in the Cameras For Monitor setting. All 512 cameras are enabled as default, which partitions all of them to the specified monitor.

  • Page 82: Select Monitors

    Select Monitors As described in the following screen, the monitor dedicated to high-speed switching output is not available as a surveillance monitor for the system. → → → Menu Path: Main Menu Video Switch Action Set Hi Spd Sw Output Select Monitors SET HI SPEED MONITORS REMINDER:...

  • Page 83: Select Cameras

    SET HI SPEED MONITORS SELECT A MONITOR FOR EACH VIDEO SWT. GROUP: SWT. GROUP 1: SWT. GROUP 2: PLUS/MINUS – CHNG MONITOR ARROWS – CURSOR UP/DOWN ENTR/ESC – STORE/ABORT Note: If only 1 monitor was selected for High-Speed Switching in the previous step, SWT. Group 2 will not be available.
  • Page 84 Note: Up to two monitors may be selected for High-Speed Switching, therefore any cameras selected will only cycle through those monitors. 74 • Video Switch Action XX190-10-XX Pilot Select...

  • Page 85: Install Defaults

    Install Defaults Administrators may install system or titling factory default settings at any time using submenus of the Install Defaults Menu. → Menu Path: Main Menu Install Defaults INSTALL DEFAULTS SYSTEM DEFAULTS AFTER FACTORY DEFAULTS HAVE BEEN INSTALLED THE SYSTEM WILL RESET AND WARM-BOOT RESTART PRESE ENTR TO CONTINUE PRESS ESC TO ABORT...

  • Page 86: Install Tdt Defaults

    INSTALL DEFAULTS SYSTEM DEFAULTS AFTER FACTORY DEFAULTS HAVE BEEN INSTALLED THE SYSTEM WILL RESET AND WARM-BOOT RESTART PRESS ENTR TO CONTINUE PRESS ESC TO ABORT The system will re-boot after factory defaults have been installed. To customize the configuration file to your particular CCTV system, you must program the Pilot Select as described in this manual.
  • Page 87 Press Enter to begin installation of factory default settings or press Escape to abort. The following screen will display. INSTALL DEFAULTS TDT DEFAULTS ALL CAMERA, PRESET, SECTOR, AND ALARM TITLES WILL BE RESET TO FACTORY DEFAULTS PRESE ENTR TO CONTINUE PRESS ESC TO ABORT During installation of the time, date, titling defaults, the following screen will display.

  • Page 89: Error Messages

    Keypad Communication Problems Vicon recommends that all keypads be set to the same baud rate. If communication problems occur, check connections to each keypad. Also check the Set Keypad Profiles Menu to ensure that all keypads are set to the same baud rate, as described here: 1.

  • Page 90: Number Out Of Range

    Receiver Communication Problems Vicon recommends that all receivers be set to the same baud rate. If communication problems occur, check connections to each receiver. Also check the Set Receiver Profiles Menu to ensure that all receivers are set to the same baud rate, as described here: 1.
  • Page 91 Software supplied either separately or in hardware is furnished on an “As Is” basis. Vicon does not warrant that such software shall be error (bug) free. Software support via telephone, if provided at no cost, may be discontinued at any time without notice at Vicon’s sole discretion.

  • Page 93: Index

    Cameras Partitioning 77–78 Titles 55 Chain To Tour 72 Index Character Size 63 Closure Type 52 Common Stack Mode 36 Communications Keypads 26, 85 Receivers 33, 86 Computer 18 Data Bits Host Computer 18 Acknowledge 41, 46 Printer 53 Home 48–49 Date 61, 65 Administration Menus 14 Day 21, 62...
  • Page 94 Number 21, 25 Partitioning 77–78 Fade 66–67 Tours 69 High Speed Switching 78 Online State 27 Home 48–49 Host Port 18 Baud Rate 18 Parity Parity 19 Host Computer 19 Passcode 19 Printer 54 Stop Bits 19 Partitioning Cameras-to-Monitors 77 Monitor-to-Keypad 29 Input Order Passcode 19...
  • Page 95 Sequence 46 Stack Mode Common 36 Status Keypads 30 Receivers 31, 34 Stop Bits Host Computer 19 Printer 54 Time 21, 61, 65 Time/Date/Titling 55 Defaults 83 Timed Events 20 Day of Week 21 Event Number 20 Event Type 20 Monitor Number 21 Receiver Number 22 Schedule 21...
